Image preview - the first page of the document
![Panel_AUO_M150XN07_V2_0_[DS]](/pics/5c36ad7371f16.gif)
>> Download Panel_AUO_M150XN07_V2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
AU OPTRONICS CORPORATION
Product Specification
15.0" XGA Color TFT-LCD Module
Model Name: M150XN07 V.2
Approved by Prepared by
CC Chiu TC Tsai
DDBU Marketing Division / AU Optronics corporation
Customer Checked & Approved by
ver 1.4 1/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
Product Specification
15.0" XGA Color TFT-LCD Module
Model Name: M150XN07
V.2
( ) Preliminary Specifications
( ) Final Specifications
Note: This Specification is subject to change without notice.
ver 1.4 2/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
Contents
1.0 Handling Precautions............................................................. 6
2.0 General Description ............................................................... 7
2.1 Display Characteristics .............................................................................................................. 7
2.2 Optical Characteristics ............................................................................................................... 8
3.0 Functional Block Diagram .................................................... 12
4.0 Absolute Maximum Ratings.................................................. 13
4.1 TFT LCD Module ...................................................................................................................... 13
4.2 Backlight Unit ............................................................................................................................ 13
4.3 Absolute Ratings of Environment ............................................................................................ 13
5.0 Electrical characteristics...................................................... 14
5.1 TFT LCD Module ...................................................................................................................... 14
5.1.1 Power Specification .............................................................................................................................14
5.1.2 Signal Electrical Characteristics...........................................................................................................15
5.2 Backlight Unit ............................................................................................................................ 16
6.0 Signal Characteristic............................................................ 17
6.1 Pixel Format Image................................................................................................................... 17
6.2 The input data format ............................................................................................................... 18
6.3 Signal Description .................................................................................................................... 19
6.4 Interface Timing ........................................................................................................................ 20
6.4.1 Timing Characteristics .........................................................................................................................20
6.4.2 Timing diagram....................................................................................................................................21
6.5 Power ON/OFF Sequence ....................................................................................................... 22
7.0 Connector & Pin Assignment................................................ 23
7.1 TFT LCD Module ...................................................................................................................... 23
7.2 Backlight Unit ............................................................................................................................ 24
7.3 Signal for Lamp connector ....................................................................................................... 24
8.0 Reliability ............................................................................ 25
9.0 Safety .................................................................................. 26
9.1 Sharp Edge Requirements ...................................................................................................... 26
9.2 Materials .................................................................................................................................... 26
9.2.1 Toxicity................................................................................................................................................26
9.2.2 Flammability........................................................................................................................................26
9.3 Capacitors ................................................................................................................................. 26
10.0 Other requirement ............................................................. 26
10.1 National Test Lab Requirement ............................................................................................. 26
10.2 Label ........................................................................................................................................ 26
10.3 Carton Package ...................................................................................................................... 27
11.0 Mechanical Characteristics................................................. 28
ver 1.4 3/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
Record of Revision
Version and Remar
Page Old description New Description
Date k
0.1 2005/02/14 All First Edition for Customer
0.2 2005/05/03 6 2.1 Display Characteristics 2.1 Display Characteristics Modify
13.3 W (Typ.) @8mA (All Black Pattern) 13.3 W (Typ.) @8mA (Gray Bar Pattern)
0.2 2005/05/03 7 2.2 Optical Characteristics 2.2 Optical Characteristics Added
Conditions Min. Typ. Max. Conditions Min. Typ. Max.
Horizontal (Right) 65 Horizontal(Right) 55 65
TBD - -
CR = 10 (Left) 65 CR = 10 (Left) 55 65
Vertical (Up) 65 Vertical (Up) 55 65
TBD - -
CR=10 (Down) 55 CR=10 (Down) 45 55
Horizontal (Right) Horizontal(Right) 65 75
TBD TBD - -
CR = 5 (Left) CR = 5 (Left) 65 75
Vertical (Up) Vertical (Up) 65 75
TBD TBD - -
CR= 5 (Down) CR=5 (Down) 65 75
Normal Direction TBD 500 Normal Direction 300 500
- -
Rising Time TBD TBD Rising Time -
- 8.5 11
Falling Time TBD Falling Time -
TBD - 3.5 5
Rising + Falling Rising + Falling
- 12 - 12 -
Red x Red x 0.612 0.672
0.61 0.64 0.67 0.642
Red y Red y 0.307 0.367
0.30 0.33 0.36 0.337
Green x Green x 0.276 0.336
0.27 0.30 0.33 0.306
Green y Green y 0.551 0.611
0.56 0.59 0.62 0.581
Blue x Blue x 0.114 0.174
0.12 0.15 0.18 0.144
Blue y Blue y
0.07 0.10 0.13 0.071 0.101 0.131
White x White x 0.283 0.343
0.28 0.31 0.34 0.313
White y White y 0.299 0.359
0.30 0.33 0.36 0.329
0.2 2005/05/03 8 Note 1: Definition of Response time Note 1: Definition of Response time Added
"Black" to "White" (rising time), "Full Black" to " Full White" (rising time),
"White" to "Black "(falling time) "Full White" to " Full Black "(falling time)
0.2 2005/05/03 15 5.2 Backlight Unit 5.2 Backlight Unit Added
Symbol Parameter Symbol Parameter
CCFL Discharge Voltage
VCFL CCFL Discharge Voltage VCFL
(only for reference)
0.2 2005/05/03 19 6.4.1 Timing Characteristics 6.4.1 Timing Characteristics Modify
Hsync Timing Hsync Timing
Horizontal blanking Min:40, Max:400 Horizontal blanking Min:30, Max:1024
Horizontal period Min:1064, Max:1424 Horizontal period Min:1054, Max:2048
Vsync Timing Vsync Timing
Horizontal blanking Max:75 Horizontal blanking Max:256
Horizontal period Max:843 Horizontal period Max:1024
ver 1.4 4/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
0.3 2005/09/09 7 Modify
Color Saturation: 65% NTSC Color Saturation: 65% NTSC (Typ)
8 Horizontal min: (Right) 55 Horizontal min: (Right) 60
Modify
CR = 10 min: (Left) 55 CR = 10 min: (Left) 60
typ:(Right)65 typ:(Right)70
typ:(Left)65 typ:(Left)70
8 Modify
Contrast ratio: min 300 Contrast ratio: min 400
1.0 2005/11/11 7 Added
RoHS Compliance
1.1 2005/12/07 7 Modify
Weight[Grams] 1100 (Typ) Weight[Grams] 1000 (Typ)
1.2 2006/04/21 22 6.5 Power ON/OFF Sequence 6.5 Power ON/OFF Sequence
Added
1.3 2006/08/28 28 Add carton package information
Added
1.4 2006/09/07 25 Drop Test Drop Test (With carton)
Added
ver 1.4 5/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press or pat the panel surface by fingers,hand or tooling.
9) Do not press the reflector sheet at the back of the module to any directions.
10) In case if a module has to be put back into the packing container slot after once it was taken out from the
container, do not press the center of the CCFL reflector edge. Instead, press at the far ends of the CCFL
reflector edge softly. Otherwise the TFT module may be damaged.
11) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT module.
12) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for example), do not twist
nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise the
TFT module may be damaged.
ver 1.4 6/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
2.0 General Description
This specification applies to the 15.0 inch Color TFT/LCD Module M150XN07 V2.
This module is designed for a display unit of personal computer.
The display supports the XGA (1024 (H) x 768(V)) screen format and 16.2M colors (RGB 6-bits + FRC data).
All input signals are 1 Channel LVDS interface compatible.
This module does not contain an inverter card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 381 (15")
Active Area [mm] 304.128 (H) x 228.096
Pixels H x V 1024(x3) x 768
Pixel Pitch [mm] 0.297 (per one triad) x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN mode, Normally White
White Luminance [cd/m2] 250 (Typ) @ 8mA
Contrast Ratio 500 : 1 (Typ)
Optical Rise Time/Fall Time [msec] 12 (Typ) (Note 1)
Color Saturation 65% NTSC (Typ)
Nominal Input Voltage VDD [Volt] +3.3 V
Power Consumption [Watt] 13.3 W (Typ.) @8mA (Gray Bar Pattern)
(VDD line + CCFL line)
Weight [Grams] 1000 (Typ)
Physical Size [mm] Min. Typ. Max.
Horizatal(H) 326.0 326.5 327.0
Vertical(V) 253.0 253.5 254.0
Depth(D) - - 12.0
Electrical Interface 1 Channel LVDS
Support Color 16.2M colors (RGB 6-bit + FRC data)
Temperature Range
o
Operating [ C] 0 to +50
o
Storage (Shipping) [ C] -20 to +60
Surface Treatment Hard-coating (3H), anti-glare treatment
ROHS RoHS Compliance
Note 1 :System should warm up for at least one hour
ver 1.4 7/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 60 70
- -
CR = 10 (Left) 60 70
- keep total
Vertical (Up) 55 65
CR = 10 (Down) 45 55 120(Maybe
Viewing Angle [degree]
60,60)
Horizontal (Right) 65 75
-
CR = 5 (Left) 65 75
Vertical (Up) 65 75
-
CR = 5 (Down) 65 75
Contrast ratio Normal Direction 400 500 - -
Rising Time - 8.5 11
Response Time [msec] Falling Time - 3.5 5 Note 1
Rising + Falling - 12 -
Red x 0.612 0.642 0.672
Red y 0.307 0.337 0.367
Color / Chromaticity Green x 0.276 0.306 0.336
Coordinates (CIE) Green y 0.551 0.581 0.611
Blue x 0.114 0.144 0.174
Blue y 0.071 0.101 0.131
Color Coordinates (CIE) White x 0.283 0.313 0.343
White White y 0.299 0.329 0.359
White Luminance @ CCFL [cd/m ]
2
8mA (center) 200 250 -
Luminance Uniformity [%] 75 80 Note 2
Crosstalk (in 75Hz) [%] 1.2 1.5 Note 3
Flicker dB -20 Note 4
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (PR 880, BM-5A ,
BM 7 ,CS-1000, CA210, SR_3 & EZ Contrast(ELDIM)* )
Aperture 1 with 50cm viewing distance
Test Point Center (VESA point 9)
Environment < 1 lux
LCD Module
PR-880 /
BM5A /
BM7
measuring distance
Module Driving Equipment
*' EZ Contrast is different measurement tool with very close viewing distance.
ver 1.4 8/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M150XN07 V.2
Product Specification
Note 1: Definition of Response time
The output signals of photo detector are measured when the input signals are changed from"Full Black" to "Full
White" (rising time), and from "Full White" to "Full Black "(falling time), respectively. The response time is interval
between the 10% and 90% of amplitudes.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
Note 2: Brightness uniformity of these 9 points is defined as below
90 % 50 % 10 %
10 %
50 %
90 %
Minimum Luminance in 9 points (1 - 9)
Uniformity = ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
