Image preview - the first page of the document
![Panel_AUO_M170EG01_V7_0_[DS]](/pics/5c36ad956e488.gif)
>> Download Panel_AUO_M170EG01_V7_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
AU OPTRONICS CORPORATION
Product Specification
17.0" SXGA Color TFT-LCD Module
Model Name: M170EG01 V.7
Approved by Prepared by
CC Chiu
DDBU Marketing Division / AU Optronics
ti
Customer Checked & Approved by
Ver0.1 1/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
Product Specification
17.0" SXGA Color TFT-LCD Module
Model Name: M170EG01
V.7
( ) Preliminary Specifications
( ) Final Specifications
Note: This Specification is subject to change without notice.
Ver0.1 2/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
Contents
1.0 Handling Precautions ........................................................ 6
2.0 General Description ........................................................... 8
2.1 Display Characteristics................................................................................................... 8
2.2 Functional Block Diagram................................................................................................ 9
2.3 Optical Characteristics ..................................................................................................10
2.4 Pixel format image.......................................................................................................13
3.0 Electrical characteristics.................................................. 14
3.1 Absolute Maximum Ratings ............................................................................................14
3.2 Connectors ...............................................................................................................15
3.3 Signal Pin.................................................................................................................15
3.4 Signal Description .......................................................................................................16
3.5 Signal Electrical Characteristics .......................................................................................19
3.6 Interface Timings .........................................................................................................19
3.6.1 Timing Characteristics .........................................................................................19
3.6.2 Timing Definition.................................................................................................20
3.8 Power ON/OFF Sequence ..............................................................................................22
4.0 Backlight Characteristics ................................................. 23
4.1 Signal for Lamp connector ..............................................................................................23
4.2 Parameter guideline for CCFL Inverter .................................................................................23
5.0 Vibration, Shock, and Drop .............................................. 24
5.1 Vibration & Shock .......................................................................................................24
5.2 Drop test..................................................................................................................24
6.0 Environment .................................................................... 24
6.1 Temperature and Humidity ..............................................................................................24
6.1.1 Operating Conditions ...........................................................................................24
6.1.2 Shipping Conditions.............................................................................................24
6.2 Atmospheric Pressure...................................................................................................25
6.3 Thermal Shock ...........................................................................................................25
7.0 Reliability........................................................................ 25
7.1 Failure Criteria............................................................................................................25
7.2 Failure Rate ..............................................................................................................25
7.2.1 Usage ..............................................................................................................25
8.0 Safety.............................................................................. 26
8.1 Sharp Edge Requirements ..............................................................................................26
8.2 Materials..................................................................................................................26
8.2.1 Toxicity ............................................................................................................26
Ver0.1 3/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
8.2.2 Flammability ......................................................................................................26
8.3 Capacitors ................................................................................................................26
9.0 Other requirement........................................................... 27
9.1 National Test Lab Requirement .........................................................................................27
9.2 Label ......................................................................................................................27
10.0 Mechanical Characteristics ............................................ 28
Ver0.1 4/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2005/2/28 All First Edition for Customer All
Ver0.1 5/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a module has to be put back into the packing container slot after once it was taken out from the
container, do not press the center of the CCFL reflector edge. Instead, press at the far ends of the CCFL
reflector edge softly. Otherwise the TFT module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT module.
11) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for example), do not twist nor
bend the TFT Module even momentary. At designing the enclosure, it should be taken into consideration
that no bending/twisting forces are applied to the TFT module from outside. Otherwise the TFT module may
be damaged.
Ver0.1 6/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
2.0 General Description
This specification applies to the 17.0 inch Color TFT/LCD Module M170EG01 V7.
This module is designed for a display unit of personal computer.
The display supports the SXGA (1280(H) x 1024(V)) screen format and 16.2M colors (RGB 6-bits + FRC data).
All input signals are 2 Channel LVDS interface compatible.
This module does not contain an inverter card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 432(17.0")
Active Area [mm] 337.920 (H) x 270.336(V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.264 (per one triad) x 0.264
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance [cd/m2] 300 (Typ)
Contrast Ratio 500 : 1
Optical Rise Time/Fall Time [msec] 12 (Typ)
Color Saturation 72% NTSC
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption [Watt] 25.8 W(Typ)
(VDD line + CCFL line) (PDD=6 W, PCFL=19.8 W @Lamp=7.5mA)
Weight [Grams] 1900 (Typ)
Physical Size [mm] Min. Typ. Max.
Horizatal(H) 358 358.5 359.0
Vertical(V) 296 296.5 297
Depth(D) 16.5 17.0 17.5
Electrical Interface Dual Channel LVDS
Support Color 16.2M colors (RGB 6-bit + FRC data)
Temperature Range
Operating [oC] 0 to +50
Storage (Shipping) [oC] -20 to +60
Ver0.1 8/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
2.2 Functional Block Diagram
The following diagram shows the functional block of the 17.0 inches Color TFT/LCD Module:
AU ASIC
G1
Timing
LVDS
Controller TFT-LCD
Connector
LVDS
1280*(3)*1024
Pixels
RSDS
+ 5V
G1024
D1 D3840
4 CCFL
DC/DC Gamma
Converter Correction
DC POWER
Inverter
FI-XB30SRL-HF11 / MDF76LBRW-30S-1H JST-BHSR-02VS-1 ( 2pin 2 )
Mating Type: JAE FI-X30C2L / HRS MDF76G-30P-1SD SM02B-BHSS-1-TB
Ver0.1 9/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
2.3 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 60 70
CR = 10 (Left) 60 70 -
Vertical (Up) 60 70
CR = 10 (Down) 50 60 -
Viewing Angle [degree]
Horizontal (Right) 70 80
CR = 5 (Left) 70 80
Vertical (Up) 70 80
CR = 5 (Down) 70 80
Contrast ratio Normal Direction 300 500 -
Rising Time - 9 12
Response Time [msec] Falling Time - 3 4 Note 1
Rising + Falling - 12 16
Red x 0.61 0.64 0.67
Red y 0.31 0.34 0.37
Color / Chromaticity Green x 0.26 0.29 0.32
Coordinates (CIE) Green y 0.58 0.61 0.64
Blue x 0.11 0.14 0.17
Blue y 0.04 0.07 0.10
Color Coordinates (CIE) White x 0.28 0.31 0.34
White White y 0.30 0.33 0.36
White Luminance @ CCFL [cd/m2]
7.5mA (center) 250 300 -
Luminance Uniformity [%] 75 80 Note 2
Crosstalk (in 75Hz) [%] 1.5 Note 3
Flicker dB -20 Note 4
Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter
((PR 880, BM-5A / BM7, CS-1000, CA210, SR_3, EZ Contrast*, Optiscope& Westar TRD-100)
Aperture 1 with 100cm VD or 2 with 50cm viewing distance
Test Point Center (VESA point 9)
Environment < 1 lux
LCD Module
PR-880 /
BM5A /
BM7
measuring distance
Module Driving Equipment
* EZ Contrast is a different measurement tool with very close viewing distance.
Ver0.1 10/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
Note 1: Definition of Response time
The output signals of photodetector are measured when the input signals are changed from "
Full Black" to "
Full
White" (rising time), and from "Full White" to "Full Black " (falling time), respectively. The response time is interval
between the 10% and 90% of amplitudes.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
Note 2: Brightness uniformity of these 9 points is defined as below
90 % 50 % 10 %
10 %
50 %
90 %
Minimum Luminance in 9 points (1 - 9)
Uniformity =
Maximum Luminance in 9 Points (1 - 9)
Ver0.1 11/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
Note 3:
1/2 1/6 2/3 1/2 1/3 1/6
1/6
A A' 1/6
1/3
1/2 1/2
B B'
2/3
184 gray level 184 gray level
Unit: percentage of dimension of display area 0 gray level
l LA-LA' l / LA x 100%= 1.5% max., LA and LB are brightness at location A and B
l LB-LB' l / LB x 100%= 1.5% max., LA' and LB' are brightness at location A' and B'
Note4:
Test Paterm : Subchecker Pattern
R GB R GB
Gray Level = L127
R GB R GB
Gray Level = L0
R GB R GB
Method : Record dBV & DC value with (WESTAR)TRD-100
Amplitude
AC
DC
Time
AC Level(at 30 Hz)
Flicker (dB) = 20 log
DC Level
Ver0.1 12/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
2.4 Pixel format image
Following figure shows the relationship of the input signals and LCD pixel format.
ODD EVEN ODD EVEN ODD EVEN
1 ST R G B R G B R G B R G B R G B R G B
1024 TH R G B R G B R G B R G B R G B R G B
Ver0.1 13/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
3.0 Electrical characteristics
3.1 Absolute Maximum Ratings
Absolute maximum ratings of the module is as following:
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VIN -0.3 6 [Volt]
CCFL Current ICFL - 8.5 [mA] rms
Operating Temperature TOP 0 +50 [oC] Note
Operating Humidity HOP 5 90 [%RH] Note
Storage Temperature TST -20 +60 [oC] Note
Storage Humidity HST 5 90 [%RH] Note
Please refer the graph below for corresponding of Min/Max values of temperature and humidity.
Note : Maximum Wet-Bulb should be 39 and No condensation.
Ver0.1 14/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
3.2 Connectors
Physical interface is described as for the connector on module.
These connectors are capable of accommodating the following signals and will be following components.
Connector Name / Designation Interface Connector / Interface card
Manufacturer JAE or compatible
Type Part Number FI-XB30SRL-HF11 / MDF76LBRW-30S-1H
Mating Housing Part Number JAE FI-X30C2L / HRS MDF76G-30P-1SD
Connector Name / Designation Lamp Connector / Backlight lamp
Manufacturer JST
Type Part Number BHSR-02VS-1
Mating Type Part Number SM02B-BHSS-1-TB
3.3 Signal Pin
Pin# Signal Name Pin# Signal Name
1 RxOIN0- 2 RxOIN0+
3 RxOIN1- 4 RxOIN1+
5 RxOIN2- 6 RxOIN2+
7 VSS 8 RxOCLKIN-
9 RxOCLKIN+ 10 RxOIN3-
11 RxOIN3+ 12 RxEIN0-
13 RxEIN0+ 14 VSS
15 RxEIN1- 16 RxEIN1+
17 VSS 18 RxEIN2-
19 RxEIN2+ 20 RxECLKIN-
21 RxECLKIN+ 22 RxEIN3-
23 RxEIN3+ 24 VSS
25 VSS 26 NC
27 VSS 28 VCC
29 VCC 30 VCC
Ver0.1 15/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
3.4 Signal Description
The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a
differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be
SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while
the second LVDS port(RxExxx) transmits even pixels.
PIN # SIGNAL NAME DESCRIPTION
1 RxOIN0- Negative LVDS differential data input (Odd data)
2 RxOIN0+ Positive LVDS differential data input (Odd data)
3 RxOIN1- Negative LVDS differential data input (Odd data)
4 RxOIN1+ Positive LVDS differential data input (Odd data)
5 RxOIN2- Negative LVDS differential data input (Odd data,H-Sync,V-Sync,DSPTMG)
6 RxOIN2+ Positive LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG)
7 VSS Power Ground
8 RxOCLKIN- Negative LVDS differential clock input (Odd clock)
9 RxOCLKIN+ Positive LVDS differential clock input (Odd clock)
10 RxOIN3- Negative LVDS differential data input (Odd data)
11 RxOIN3+ Positive LVDS differential data input (Odd data)
12 RxEIN0- Negative LVDS differential data input (Even data)
13 RxEIN0+ Positive LVDS differential data input (Even data)
14 VSS Power Ground
15 RxEIN1- Positive LVDS differential data input (Even data)
16 RxEIN1+ Negative LVDS differential data input (Even data)
17 VSS Power Ground
18 RxEIN2- Negative LVDS differential data input (Even data)
19 RxEIN2+ Positive LVDS differential data input (Even data)
20 RxECLKIN- Negative LVDS differential clock input (Even clock)
21 RxECLKIN+ Positive LVDS differential clock input (Even clock)
22 RxEIN3- Negative LVDS differential data input (Even data)
23 RxEIN3+ Positive LVDS differential data input (Even data)
24 VSS Power Ground
25 VSS Power Ground
26 NC No Connection ( for AUO test)
27 VSS Power Ground
28 VCC +5.0V Power Supply
29 VCC +5.0V Power Supply
30 VCC +5.0V Power Supply
Ver0.1 16/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
Note1: Start from left side
Connector
1 30
RxOIN0-
VCC
Note2: Input signals of odd and even clock shall be the same timing.
Note3: Please follow PSWG.
Ver0.1 17/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
The input data format:
Note1: Normally, DE, VS, HS on EVEN channel are not used.
Note2: Please follow PSWG.
Note3: 8-bit in
Ver0.1 18/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EG01 V.7
Product Specification
3.5 Signal Electrical Characteristics
Each signal characteristics are as follows;
Symbol Parameter Min Typ Max Units Condition
Differential Input High
VTH - - 100 [mV] VICM = 1.2V Note
Threshold
Differential Input
VTL -100 - - [mV] VICM = 1.2V Note
Low Threshold
Input Differential
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
