Image preview - the first page of the document
![Panel_AUO_M170EG01_VH_0_[DS]](/pics/5c36ada5a43c2.gif)
>> Download Panel_AUO_M170EG01_VH_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M170EG01 VH
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 17.0" SXGA Color TFT-LCD
Model Name M170EG01 VH
Checked &
Customer Date Date
Approved by
Winnie Chang 2011/01/24
Approved by Prepared by
Archer Cheng 2011/01/24
Note: This Specification is subject to change without Desktop Display Business Group /
notice. AU Optronics corporation
document version 1.0 1/25
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M170EG01 VH
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .................................................................................................................. 4
2. General Description ..................................................................................................................... 5
2.1 Display Characteristics ........................................................................................................................ 5
3. Functional Block Diagram.........................................................................................................10
4. Absolute Maximum Ratings......................................................................................................11
4.1 TFT LCD Module ............................................................................................................................. 11
4.2 Backlight Unit.................................................................................................................................... 11
4.3 Absolute Ratings of Environment ...................................................................................................... 11
5. Electrical characteristics ..........................................................................................................12
5.1 TFT LCD Module ............................................................................................................................. 12
5.2 Backlight Unit.................................................................................................................................... 14
6. Signal Characteristic .................................................................................................................15
6.1 Pixel Format Image ........................................................................................................................... 15
6.2 The Input Data Format ...................................................................................................................... 15
6.4 Timing Characteristics ....................................................................................................................... 18
6.5 Power ON/OFF Sequence................................................................................................................. 20
7. Connector & Pin Assignment ...................................................................................................21
7.1 TFT LCD Module ............................................................................................................................. 21
7.2 Backlight Unit.................................................................................................................................... 22
8. Reliability Test ............................................................................................................................23
9. Shipping Label............................................................................................................................24
10. Mechanical Characteristics ....................................................................................................25
document version 1.0 2/25
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M170EG01 VH
AU OPTRONICS CORPORATION
Record of Revision
Version and
Page Old description New Description Remark
Date
0.1 2010/02/03 All First Edition for Customer All
0.2 2010/5/18 p.10 Manufacturer Manufacturer
revised
YENONHO YEONHO
Type Part Number Type Part Number
p.12 revised
35001HS-02L or CP0521S1 35001HS-02L or CP0502SL090
Mating Type Part Number Mating Type Part Number
p.12 revised
35001WR-00LS00 or CP0502SL090 35001WR-02L or CP0502P1ML0
P-Two P-Two
1.0 2010/10/29 p.10 revised
AL230T-A0G1D-P 187034-30091
T3(min)=500,T5(min)=40;Power sequence
1.0 2011/01/24 p. 20 T3(min)=300, T5(min)=0 revised
timing revised (see page 20 in details.)
All Final version to all customer
document version 1.0 3/25
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M170EG01 VH
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the CCFL reflector edge. Instead, press at the far
ends of the CCFL Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit (IEC60950 or
UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
15) Please avoid touching COF position while you are doing mechanical design.
document version 1.0 4/25
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M170EG01 VH
AU OPTRONICS CORPORATION
2. General Description
This specification applies to the 17 inch Color TFT-LCD Module M170EG01 VH.
The display supports the SXGA+ (1280(H) x 1024(V)) screen format and 16.7M colors (RGB 6-bits+Hi-RFC
data).All input signals are 2 Channel LVDS interface compatible.
This module does not contain an inverter card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 432 (17.0")
Active Area [mm] 337.920(H) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
