Image preview - the first page of the document
![Panel_AUO_M170EP01_V0_0_[DS]](/pics/5c36adaa970d6.gif)
>> Download Panel_AUO_M170EP01_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
AU OPTRONICS CORPORATION
Product Specification
17.0" SXGA Color TFT-LCD Module
Model Name: M170EP01 V.0
Approved by Prepared by
DDBU Marketing Division / AU Optronics corporation
Customer Checked & Approved by
Ver0.1 1/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Page intentionally left blank.
Ver0.1 2/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Product Specification
17.0" SXGA Color TFT-LCD Module
Model Name: M170EP01
V.0
() Preliminary Specifications
(...) Final Specifications
Note: This Specification is subject to change without notice.
Ver0.1 3/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Page intentionally left blank.
Ver0.1 7/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Contents
2.0 General Description ............................................................... 3
2.1 Display Characteristics .....................................................................................................3
2.2 Functional Block Diagram..................................................................................................3
2.3 Optical Characteristics......................................................................................................3
2.4 Pixel format image ..........................................................................................................3
3.0 Electrical characteristics........................................................ 3
3.1 Absolute Maximum Ratings................................................................................................3
3.2 Connectors ...................................................................................................................3
3.3 Pin Assignment ..............................................................................................................3
3.4 Signal Description ...........................................................................................................3
3.5 Signal Electrical Characteristics...........................................................................................3
3.6 Interface Timings ............................................................................................................3
3.6.1 Timing Characteristics ............................................................................................3
3.6.2 Definition of terms .................................................................................................3
3.8 Power ON/OFF Sequence .................................................................................................3
4.0 Backlight Characteristics ....................................................... 3
4.1 Signal for Lamp connector .................................................................................................3
4.2 Parameter guideline for CCFL Inverter...................................................................................3
5.0 Vibration, Shock, and Drop .................................................... 3
5.1 Vibration & Shock ...........................................................................................................3
5.2 Drop test ......................................................................................................................3
6.0 Environment .......................................................................... 3
6.1 Temperature and Humidity.................................................................................................3
6.1.1 Operating Conditions..............................................................................................3
6.1.2 Shipping Conditions ...............................................................................................3
6.2 Atmospheric Pressure ......................................................................................................3
6.3 Thermal Shock...............................................................................................................3
7.0 Reliability .............................................................................. 3
7.1 Failure Criteria ...............................................................................................................3
7.2 Failure Rate ..................................................................................................................3
7.2.1 Usage ..................................................................................................................3
8.0 Safety .................................................................................... 3
8.1 Sharp Edge Requirements.................................................................................................3
8.2 Materials ......................................................................................................................3
8.2.1 Toxicity ................................................................................................................3
8.2.2 Flammability .........................................................................................................3
8.3 Capacitors ....................................................................................................................3
9.0 Other requirement................................................................. 3
Ver0.1 8/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
9.1 National Test Lab Requirement ...........................................................................................3
9.2 Label ..........................................................................................................................3
10.0 Mechanical Characteristics .................................................. 3
Ver0.1 9/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2/21/2004 All First Edition for Customer All
Viewing Angle (Down) Viewing Angle (Down)
0.1 5/25/2004 15
70(typical) 60(min) 60(typical) 50(min)
Ver0.1 10/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Page intentionally left blank.
Ver0.1 11/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
1.0 Handling Precautions
1) Do not scratch the front polarier of panel. The front polarier is easily damaged
2) Be sure to turn off power supply when inserting and disconnecting from input connector.
3) Wipe off water drop immediately. Contacted with water in a long time may cause discoloration or spots.
4) Use absorbent cotton or other kind of soft cloth to wipe when the panel is dusty.
5) Do not drop it on hard surface. The face of panel is fragile
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) The TFT module will be damaged if the center of the CCFL reflector is pressed heavily.
10) Keep the connector interface straight during the period of inserting and disconnecting it.
11) Do not twist nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise the TFT
module may be damaged.
Ver0.1 12/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
2.0 General Description
This specification applies to the 17.0 inch Color TFT/LCD Module M170EP01 V0.
This module is designed for a display unit of personal computer.
The display supports the SXGA (1280(H) x 1024(V)) screen format and 16.2M colors (RGB 6-bits + FRC data).
The input signal is Analog RGB interface compatible, DVI interface optional.
This module does not contain an inverter card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 432(17.0")
Active Area [mm] 337.920 (H) x 270.336(V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.264 (per one triad) x 0.264
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance [cd/m2] 260 (Typ)
Contrast Ratio 450
Optical Rise Time/Fall Time [msec] 16 (Typ)
Nominal Input Voltage VDD [Volt] +5.1 V
Power Consumption [Watt] 27 W(Typ)
(VDD line + CCFL line) (PDD=7 W, PCFL=20 W @Lamp=7.5mA)
Weight [Grams] 2000 (Typ)
Physical Size [mm] Min. Typ. Max.
Horizatal(H) 358 358.5 359.0
Vertical(V) 296 296.5 297
Depth(D) 19.5 20 20.5
Electrical Interface Analog RGB (DVI optional)
Support Color 16.2M colors (RGB 6-bit + FRC data)
Temperature Range
Operating [oC] 0 to +50
Storage (Shipping) [oC] -20 to +60
TC0-03 Compliance TC0-03 Compliance
Ver0.1 13/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
2.2 Functional Block Diagram
The following diagram shows the functional block of the 17.0 inches Color TFT/LCD Module:
Ver0.1 14/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
2.3 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 60 70
CR = 10 (Left) 60 70 -
Viewing Angle [degree]
Vertical (Up) 60 70
CR = 10 (Down) 50 60 -
Contrast ratio Normal Direction 250 450 -
Raising Time - 4 5
Response Time [msec] Falling Time - 12 20 Note 1
Raising + Falling - 16 25
Red x 0.61 0.64 0.67
Red y 0.31 0.34 0.37
Color / Chromaticity Green x 0.26 0.29 0.32
Coordinates (CIE) Green y 0.58 0.61 0.64
Blue x 0.11 0.14 0.17
Blue y 0.04 0.07 0.10
Color Coordinates (CIE) White x 0.28 0.31 0.34
White White y 0.30 0.33 0.36
White Luminance @ CCFL 2
[cd/m ]
7.5mA (center) 210 260 Note 2
Luminance Uniformity [%] 75 80 Note 3
Crosstalk (in 75Hz) [%] 1.5 Note 4
Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter
(PR 880, BM-5A / BM7)
Aperture 1 with 100cm VD or 2 with 50cm viewing distance
Test Point Center (VESA point 9)
Environment < 1 lux
LCD Module
PR-880 /
BM5A /
BM7
measuring distance
Module Driving Equipment
Ver0.1 15/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Note 1: Definition of Response time
The output signals of photodetector are measured when the input signals are changed from "Black" to "White"
(rising time), and from "White" to "Black "(falling time), respectively. The response time is interval between the
10% and 90% of amplitudes.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
Note 2: Definition of center brightness
The brightness of center is measured at 30mins when opening lamp.
Note 3: Brightness uniformity of these 9 points is defined as below
90 % 50 % 10 %
10 %
50 %
90 %
Minimum Luminance in 9 points (1 - 9)
Uniformity
Maximum Luminance in 9 Points (1 - 9)
Ver0.1 16/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
Note 4:
1/2 1/6 2/3 1/2 1/3 1/6
1/6
A A' 1/6
1/3
1/2 1/2
B B'
2/3
184 gray level 184 gray level
Unit: percentage of dimension of display area 0 gray level
l LA-LA' l / LA x 100%= 1.5% max., LA and LB are brightness at location A and B
l LB-LB' l / LB x 100%= 1.5% max., LA' and LB' are brightness at location A' and B'
2.4 Pixel format image
Following figure shows the relationship of the input signals and LCD pixel format.
1 2 1279 1280
1st Line R G B R GB R GB R G B
1024th R G B R GB R GB R G B
Ver0.1 17/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
3.0 Electrical characteristics
3.1 Absolute Maximum Ratings
Absolute maximum ratings of the module is as following:
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VIN +4.5 +5.5 [Volt]
CCFL Current ICFL - 8.5 [mA] rms
Operating Temperature TOP 0 +50 [oC] Note
Operating Humidity HOP 8 95 [%RH] Note
o
Storage Temperature TST -20 +60 [ C] Note
Storage Humidity HST 8 95 [%RH] Note
Note : Maximum Wet-Bulb should be 39 and No condensation.
Ver0.1 18/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
3.2 Connectors
Physical interface is described as for the connector on module.
These connectors are capable of accommodating the following signals and will be following components.
Connector Name / Designation Power Connector (J1)
Manufacturer STM or compatiable
Type Part Number STM MS242612R
Mating Housing Part Number STM P242612
Connector Name / Designation OSD Connector (J4)
Manufacturer STM or compatiable
Type Part Number STM MS242613R
Mating Housing Part Number STM PS242613
Connector Name / Designation VGA Connector (J2)
Manufacturer STM or compatiable
Type Part Number STM MS242614R
Mating Housing Part Number STM P242614R
Connector Name / Designation DVI Connector (optional)
Manufacturer STM or compatiable
Type Part Number STM MDS240315
Mating Housing Part Number STM PDS240315
Connector Name / Designation Lamp Connector / Backlight lamp
Manufacturer JST
Type Part Number BHSR-02VS-1
Mating Type Part Number SM02(4.0)B-BHS-1-TB
Ver0.1 19/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.0
Product Specification
3.3 Pin Assignment
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
