Image preview - the first page of the document
![Panel_AUO_M170XW01_V2_0_[DS]](/pics/5c36add82548e.gif)
>> Download Panel_AUO_M170XW01_V2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
AU OPTRONICS CORPORATION
Product Specification
17.0" WXGA Color TFT-LCD Module
Model Name: M170XW01 V.2
Approved by Prepared by
CC Chiu Gary Chen
DDBU Marketing Division / AU Optronics corporation
Customer Checked & Approved by
Ver0.2 1/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
Product Specification
17.0" WXGA Color TFT-LCD Module
Model Name: M170XW01
V.2
( ) Preliminary Specifications
( ) Final Specifications
Note: This Specification is subject to change without notice.
Ver0.2 4/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
Contents
1.0 Handling Precautions .............................................................6
2.0 General Description ...............................................................7
2.1 Display Characteristics............................................................................................................... 7
2.2 Optical Characteristics ............................................................................................................... 8
3.0 Functional Block Diagram.....................................................11
4.0 Absolute Maximum Ratings ..................................................12
5.0 Electrical characteristics ......................................................13
5.1 TFT LCD Module....................................................................................................................... 13
5.1.1 Power Specification............................................................................................... 13
5.1.2 Signal Electrical Characteristics.............................................................................. 14
5.2 Backlight Unit ............................................................................................................................ 15
6.0 Signal Characteristic ............................................................16
6.1 Pixel Format Image ................................................................................................................... 16
6.2 The input data format ............................................................................................................... 16
6.3 Signal Description..................................................................................................................... 17
6.4 Interface Timings....................................................................................................................... 18
6.4.1 Timing Characteristics........................................................................................... 18
6.4.2 Timing diagram .................................................................................................... 19
6.5 Power ON/OFF Sequence ....................................................................................................... 20
7.0 Connector & Pin Assignment ................................................21
7.1 TFT LCD Module....................................................................................................................... 21
7.2 Backlight Unit ............................................................................................................................ 21
8.0 Vibration, Shock, and Drop...................................................22
8.1 Vibration & Shock ..................................................................................................................... 22
8.2 Drop test .................................................................................................................................... 22
9.0 Environment ........................................................................22
9.1 Temperature and Humidity ....................................................................................................... 22
9.1.1 Operating Conditions ............................................................................................ 22
9.1.2 Shipping Conditions .............................................................................................. 22
9.2 Atmospheric Pressure .............................................................................................................. 23
9.3Thermal Shock ........................................................................................................................... 23
10.0 Reliability...........................................................................23
10.1 Failure Criteria ........................................................................................................................ 23
10.2 Failure Rate............................................................................................................................. 23
10.2.1 Usage................................................................................................................ 23
Ver0.2 5/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
11.0 Safety ................................................................................23
11.1 Sharp Edge Requirements ..................................................................................................... 23
11.2 Materials .................................................................................................................................. 24
11.2.1 Toxicity ............................................................................................................. 24
11.2.2 Flammability ...................................................................................................... 24
11.3 Capacitors................................................................................................................................ 24
12.0 Other requirement .............................................................24
12.1 National Test Lab Requirement ............................................................................................. 24
12.2 Label ........................................................................................................................................ 24
13.0 Mechanical Characteristics .................................................25
Ver0.2 6/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2004/03/26 All First Edition for Customer All
0.2 2004/05/24 13 IDD (Typ= TBD, Max= TBD) IDD (Typ= 950, Max= 1200 mA) Update
13 Irush= (Max= TBD) Irush= (Max= 3.0 A) Update
13 PDD (Typ= TBD, Max= TBD) PDD (Typ= 4.75, Max= 6.6 W) Update
Data CLK(Min= 35, Max= 83MHz) Data CLK(Min= 45, Max= 81MHz)
H-Period (Min= 1320 Tclk) H-Period (Min= 1330 Tclk)
18 Update
V-Period (Max= 823 Th) V-Period (Max= 860 Th)
Frame Rate (Max= 80Hz) Frame Rate (Max= 75Hz)
Power ON/OFF Sequence
Power ON/OFF Sequence
20 T1 (Min= 0.5 ms) ; T6 (Min= 0.5 Update
T1 (Min= NA) ; T6 (Min= NA)
ms)
Ver0.2 7/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a module has to be put back into the packing container slot after once it was taken out from
the container, do not press the center of the CCFL reflector edge. Instead, press at the far ends of the
CCFL reflector edge softly. Otherwise the TFT module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT module.
11) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for example), do not
twist nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise
the TFT module may be damaged.
Ver0.2 6/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
2.0 General Description
This specification applies to the 17.0 inch Color TFT/LCD Module M170XW01 V.2. This module is designed for a
display unit of personal computer. The display supports the WXGA (1280(H) x 768(V)) screen format and 16.2M
colors (RGB 6-bits + FRC data). All input signals are 1 Channel LVDS interface compatible. This module does
not contain an inverter card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 432(17.0" Wide)
Active Area [mm] 370.56 (H) x 222.34(V)
Pixels H x V 1280(x3) x 768
Pixel Pitch [mm] 0.2895 (per one triad) x 0.2895
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally Black
White Luminance [cd/m2] 450 (Typ, Center @ Lamp= 11.0mA)
Contrast Ratio 800 : 1
Optical Response Time
[msec] 16 (Typ)
(Gray to Gray)
Color Saturation 72% NTSC
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption [Watt] TBD W(Typ)
(VDD line + CCFL line) (PDD=TBD W, PCFL=TBD W @Lamp=11.0mA)
Weight [Grams] 2000 (Typ)
Min. Typ. Max.
Horizatal(H) 403.5 404.0 404.5
Physical Size [mm]
Vertical(V) 248.0 248.5 249.0
Depth(D) 16.8 17.3 17.8
Electrical Interface 1 Channel LVDS
Support Color 16.2M colors (RGB 6-bit + FRC data)
Temperature Range
Operating [oC] 0 to +50
o
Storage (Shipping) [ C] -20 to +60
Ver0.2 7/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 :
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 75 85 -
CR = 10 (Left) 75 85 -
Viewing Angle [degree]
Vertical (Up) 75 85 -
CR = 10 (Down) 75 85 -
Contrast ratio Normal Direction 600 800 -
Rasing Time - 15 25
Falling Time - 10 15
Response Time [msec] Note 1
Raising + Falling - 25 40
Gray to Gray - 16 -
Red x 0.61 0.64 0.67
Red y 0.31 0.34 0.37
Color / Chromaticity Green x 0.26 0.29 0.32
Coordinates (CIE) Green y 0.58 0.61 0.64
Blue x 0.11 0.14 0.17
Blue y 0.04 0.07 0.10
Color Coordinates (CIE) White x 0.28 0.31 0.34
White White y 0.30 0.33 0.36
White Luminance @ CCFL 2
[cd/m ] 400 450 -
11.0mA (Center)
Luminance Uniformity [%] 75 80 Note 2
Crosstalk (in 75Hz) [%] - - 1.5 Note 3
Flicker dB - - -20 Note 4
Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter
(PR 880, BM-5A / BM7)
Aperture 1 with 100cm VD or 2 with 50cm viewing distance
Test Point Center (VESA point 9)
Environment < 1 lux
LCD Module
PR-880 /
BM5A /
BM7
measuring distance
Module Driving Equipment
Ver0.2 8/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
Note 1: The Definition of Response time
The output signals of photodetector are measured when the input signals are changed from "Black" to "White"
(rising time), and from "White" to "Black "(falling time), respectively. The response time is interval between the
10% and 90% of amplitudes.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
Note 2: Brightness uniformity of these 9 points is defined as below
90 % 50 % 10 %
10 %
50 %
90 %
Minimum Luminance in 9 points (1 - 9)
Uniformity =
Maximum Luminance in 9 Points (1 - 9)
Ver0.2 9/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
Note 3: The Definition of Crosstalk
1/2 1/6 2/3 1/2 1/3 1/6
1/6
A A' 1/6
1/3
1/2 1/2
B B'
2/3
184 gray level 184 gray level
Unit: percentage of dimension of display area 0 gray level
l LA-LA' l / LA x 100%= 1.5% max., LA and LB are brightness at location A and B
l LB-LB' l / LB x 100%= 1.5% max., LA' and LB' are brightness at location A' and B'
Note4: The Definition of Flicker
Test Paterm: Subchecker Pattern
RGB R GB
Gray Level = L127
RGB R GB
Gray Level = L0
RGB R GB
Method: Record dBV & DC value with (WESTAR)TRD-100
Amplitude
AC
DC
Time
AC Level(at 30 Hz)
Flicker (dB) = 20 log
DC Level
Ver0.2 10/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
3.0 Functional Block Diagram
The following diagram shows the functional block of the 17.0 inches wide Color TFT/LCD Module:
AUO ASIC
G1
LVDS
Y-Driver IC
Receiver Timing TFT-LCD
LVDS
Connector
Controller 1280*(3)*768
Pixels
Over-Driver
+ 5V
X-Driver IC
G768
D1 D3840
Gamma
DC/DC
Correction
Converter
DC POWER
Inverter
FI-XB30SRL-HF11 / MDF76LBRW-30S-1H JST-BHSR-02VS-1
Mating Type: JAE FI-X30C2L / HRS MDF76G-30P-1SD SM02(4.0)B-BHS-1-TB
Ver0.2 11/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
4.0 Absolute Maximum Ratings
Absolute maximum ratings of the module is as following:
TFT LCD Module
Item Symbol Min Max Unit Conditions
Logic/LCD Drive VIN -0.3 +5.5 [Volt] Note 1,2
Backlight Unit
Item Symbol Min Max Unit Conditions
CCFL Current ICFL - 12.0 [mA] rms Note 1,2
CCFL Frequency FCFL 40 80 [Hz] Note 1,2
Absolute Ratings of Environment
Item Symbol Min Max Unit Conditions
Operating Humidity HOP 8 95 [%RH]
Storage Temperature TST -20 +60 [oC]
Storage Humidity HST 8 95 [%RH]
Note 1: With in Ta (25 )
Note 2: Permanent damage to the device may occur if exceed maximum values
Relative Humidity %
Twb=39
T=40 ,H=95%
100
95
80
T=50 ,H=55%
60
T=60 ,H=39%
Storage
40 range Operation range T=65 ,H=29%
20 Storage
range
5
0 -20 0 50 60
Temperature
Ver0.2 12/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
5.0 Electrical characteristics
5.1 TFT LCD Module
5.1.1 Power Specification
Input power specifications are as follows;
Symbol Parameter Min Typ Max Units Condition
Logic/LCD Drive
VDD 4.5 5 5.5 [Volt] 10%
Voltage
Vin=5V , All White Pattern,
IDD VDD current - 950 1200 [mA]
+30%, at 75Hz
Irush LCD Inrush Current - - 3.0 [A] Note
Vin=5V , All White Pattern,
PDD VDD Power - 4.75 6.6 [Watt]
+30%, at 75Hz
Allowable Logic/LCD [mV]
VDDrp 100
Drive Ripple Voltage p-p
Note: Measurement conditions:
+5.0V Q3
AO6402
D6 F1
D5
D2 S
VCC
D1
R1 (LCD Module Input)
G
47K
C1
1uF/16V
D1
D2
D5
D6
(High to Low)
Control Signal Q3
R2 AO6402
G
SW
1K
S
C3
+12.0V
VR1 0.01uF/25V
47K
C2
1uF/25V
90% 5.0V
10%
0V
470 us
Vin rising time
Ver0.2 13/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
5.1.2 Signal Electrical Characteristics
Each signal characteristics are as follows;
Symbol Parameter Min Typ Max Units Condition
Differential Input High VICM = 1.2V
VTH - - +100 [mV]
Threshold Note
Differential Input Low VICM = 1.2V
VTL -100 - - [mV]
Threshold Note
VID Input Differential Voltage 100 400 600 [mV] Note
Differential Input Common VTH/VTL = 100MV
VICM 1.1 - 1.45 [V]
Mode Voltage Note
Note: LVDS Signal Waveform
VTH
VID
VTL
VICM
VSS
Ver0.2 14/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170XW01 V.2
Product Specification
5.2 Backlight Unit
Parameter guideline for CCFL Inverter
Symbol Parameter Min. Typ. Max. Unit Condition
[mA]
ISCFL CCFL standard current 10.5 11.0 11.5 (Ta=25oC) Note 1
rms
[mA] o
IRCFL CCFL operation range 5.5 11.0 12.0 (Ta=25 C)
rms
FCFL CCFL Frequency 40 60 80 [KHz] (Ta=25oC) Note 2
ViCFL CCFL Ignition Voltage [Volt] o
1650 - - (Ta=0 C)
(0oC) (End of the lamp wire connector) rms
ViCF CCFL Ignition Voltage [Volt] o
1250 - - (Ta=25 C)
(25oC) (End of the lamp wire connector) rms
560 680 [Volt]
VCFL CCFL Operation Voltage - (Ta=25oC) Note 3
@11.0mA @5.5mA rms
CCFL Power consumption o
PCFL - 24.6 28 [Watt] (Ta=25 C) Note 4
(for reference)
LTCFL CCFL life Time 30,000 - - [Hour] (Ta=25oC) Note 5
Note 1: CCFL standard current is measured at 25 2 . The variance of the current is 10%.
Note 2: CCFL Frequency should be carefully determined to avoid interference between inverter and TFT LCD
Note 3: CCFL operation voltage is measured at 25 2 .
Note 4: The variance of CCFL power consumption is 10%. Calculator value for reference
(ICFL◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
