Image preview - the first page of the document
![Panel_AUO_M185XW01_V6_2_[DS]](/pics/5c36adef0164f.gif)
>> Download Panel_AUO_M185XW01_V6_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M185XW01 V6
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 18.5" Color TFT-LCD
Model Name M185XW01 V6
Customer Date Approved by Date
Sean Chen 2009/9/4
Approved by Prepared by
Stanley Su 2009/9/4
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version 1.1 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M185XW01 V6
AU OPTRONICS CORPORATION
Contents
1.0 Handling Precautions............................................................. 4
2.0 General Description ............................................................... 5
2.1 Display Characteristics.................................................................................................................... 5
2.2 Optical Characteristics .................................................................................................................... 6
3.0 Functional Block Diagram .................................................... 10
4.0 Absolute Maximum Ratings......................................................... 11
4.1 TFT LCD Module.............................................................................................................................. 11
4.2 Backlight Unit.................................................................................................................................... 11
4.3 Absolute Ratings of Environment ...................................................................................................... 11
5.0 Electrical characteristics...................................................... 12
5.1 TFT LCD Module............................................................................................................................ 12
5.1.1 Power Specification.............................................................................................. 12
5.1.2 Signal Electrical Characteristics.............................................................................. 13
5.2 Backlight Unit.................................................................................................................................... 14
6.0 Signal Characteristic............................................................ 15
6.1 Pixel Format Image........................................................................................................................ 15
6.2 The input data format .................................................................................................................... 16
6.3 Signal Description.......................................................................................................................... 17
6.4 Timing Characteristics ....................................................................................................................... 19
6.5 Timing diagram............................................................................................................................... 20
6.6 Power ON/OFF Sequence ........................................................................................................... 21
7.0 Connector & Pin Assignment ............................................... 22
7.1 TFT LCD Module............................................................................................................................ 22
7.1.1 Pin Assignment ................................................................................................... 22
7.2 Recommend connector for Backlight Unit ......................................................................................... 23
7.2.1 Pin assignment ................................................................................................... 23
8.0 Reliability Test..................................................................... 24
9.0 Shipping Label ..................................................................... 25
10.0 Mechanical Characteristics ................................................ 26
document version 1.1 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M185XW01 V6
AU OPTRONICS CORPORATION
Record of Revision
Version and Pag
Old description New Description Remark
Date e
0.1 2009/6/8 All First Edition for Customer N/A
1.0 2009/7/2 5 2.1 Display Characteristics 2.1 Display Characteristics
Weight Weight
1330 1330 50g
1.0 2009/7/2 10 I/F PCB Interface: I/F PCB Interface:
FI-XB30SSRL-HF16(JAE)/MSCKT2407P3 FI-XB30SRL-HF11(JAE) /
0HB( ) 093F30-B0T01A(CHIEF LAND)
1.0 2009/7/2 11 4.2 Backlight Unit 4.2 Backlight Unit
LED current LED current
Min:n/a Max:20 Min: 19 Max:21
1.0 2009/7/2 12 5.1.1 Power Specification 5.1.1 Power Specification
Input Current Input Current
Typ:0.6 Max:0.7 Typ:0.84 Max:1
Allowable Logic/LCD Drive Ripple Voltage Allowable Logic/LCD Drive Ripple Voltage
Max:200 Max:350
1.0 2009/7/2 14 5.2 Backlight Unit 5.2 Backlight Unit
LED Operation Current LED Operation Current
Min:n/a Typ:n/a Max:20 Min:19 Typ:20 Max:21
LED Operation Voltage LED Operation Voltage
Typ:42.9 Max:44.2 Typ:44.8 Max:47.6
BLU Power consumption BLU Power consumption
Typ:5.5 Max:5.7 Typ:5.4 Max:6.0
LED life Time LED life Time
Typ:n/a Typ:25,000
1.0 2009/7/2 18 6.3 Signal Description 6.3 Signal Description
Signal Drawing Signal Drawing
Plus FFC drawing Remove FFC drawing
1.0 2009/7/2 19 H-section H-section
Blanking Blanking
Min:50 Min:104
Period Period
Min:1482 Min:1470
Note2 : Note2 :
Clock Frequency 90MHz(Max.)= Clock Frequency 90MHz(Max.)=
1416(H)*847(V)*75Hz 1470(H)*816(V)*75Hz
1.1 2009/9/4 14 VLB VLB
Light Bar Operation Voltage Light Bar Operation Voltage
Min:-- Min:39.2
BLU Power consumption BLU Power consumption
Min:n/a Min:4.4
document version 1.1 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M185XW01 V6
AU OPTRONICS CORPORATION
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the LED lightbar edge. Instead, press at the
far ends of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
document version 1.0 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M185XW01 V6
AU OPTRONICS CORPORATION
2.0 General Description
This specification applies to the 18.5 inch-wide Color a-Si TFT-LCD Module M185XW01.The
display supports the WXGA - 1366(H) x 768(V) screen format and 16.7M colors (RGB 6-bits +
Hi-FRC data). All input signals are 1-channel LVDS interface and this module doesn't contain an
inverter board for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 470.1(18.51")
Active Area [mm] 409.8 (H) x 230.4 (V)
Pixels H x V 1366(x3) x 768
Pixel Pitch [um] 300 (per one triad) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
