Image preview - the first page of the document
![Panel_AUO_M200RW01_V3_1_[DS]](/pics/5c36aeaf69277.gif)
>> Download Panel_AUO_M200RW01_V3_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M200RW01 V3 open cell
AU OPTRONICS CORPORATION
( ) Preliminary Specification
(V ) Final Specification
Module 20.0" Color TFT-LCD
Model Name M200RW01 V3 Open Cell
Customer Date Approved by Date
Frankie Wang 2011/7/25
Approved by Prepared by
Jacqueline Song 2011/07/21
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version 1.0 1
NUMPAGES 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M200RW01 V3 open cell
AU OPTRONICS CORPORATION
Contents
1.0 Handling Precautions .............................................................4
2.0 General Description................................................................5
2.1 Display Characteristics ................................................................................................................... 5
2.2 Optical Characteristics .................................................................................................................... 6
3.0 Functional Block Diagram.......................................................9
4.0 Absolute Maximum Ratings .........................................................10
4.1 TFT LCD Module ............................................................................................................................. 10
4.2 Absolute Ratings of Environment ...................................................................................................... 10
5.0 Electrical characteristics ......................................................11
5.1 TFT LCD Module............................................................................................................................ 11
5.1.1 Power Specification .............................................................................................. 11
5.1.2 Signal Electrical Characteristics.............................................................................. 12
6.0 Signal Characteristic ............................................................13
6.1 Pixel Format Image ....................................................................................................................... 13
6.2 The input data format .................................................................................................................... 13
6.3 Signal Description.......................................................................................................................... 14
6.4 Timing Characteristics ....................................................................................................................... 15
6.5 Timing diagram............................................................................................................................... 16
6.6 Power ON/OFF Sequence ........................................................................................................... 17
7.0 Connector & Pin Assignment ................................................18
7.1 TFT LCD Module............................................................................................................................ 18
7.1.1 Pin Assignment.................................................................................................... 18
8.0 Reliability Test .....................................................................19
9.0 Mechanical Characteristics ...................................................20
document version 1.0 2
NUMPAGES 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M200RW01 V3 open cell
AU OPTRONICS CORPORATION
Record of Revision
Remar
Version and Date Page Old description New Description
k
0.1 2009/11/16 All First Edition for Customer N/A
2.2 Optical Characteristics 2.2 Optical Characteristics
0.2 2010/01/22 6
3.0 Functional Block Diagram 3.0 Functional Block Diagram
I/F PCB Interface: I/F PCB Interface:
10
MSCKT2407P30HB AL230F-A0G1D-P (P-TWO)
MSCKT2407P30HB (STM)
5.1.1 Power Specification 5.1.1 Power Specification
12
IRush Max. 2.5 [A] IRush Max. 3 [A]
Note 1: LVDS Signal Waveform
Note 1: LVDS Signal Waveform
13
14
t
e
C
V
F
C
g
e
o
g
o
n
aC
F
L
T
0
0C
L
Vi,I
F)ii
Cii
)io
(n
V
Lo
Fl
nl
CIt
Ct
Ta
V(
V
gn
ag
o,i
a
n
o(
g
aL
eg
=
=e
,o
T)
L
CI
Vi
)ii
al
T
5C
,F
Fo
(n
V
2a
V
C
F
2
5
=t
n
a
g
=i
l
t
t
t
5.2 Backlight Unit
CCFL Ignit
Max. 1620 [Volt] rms
Max. 1240 [Volt] rms
6.6 Power ON/OFF Sequence
5.2 Backlight Unit
Max. 1660 [Volt] rms
Max. 1280 [Volt] rms
6.6 Power ON/OFF Sequence
20 T1 value: T1 value:
Min. 0.5msec / Max. 10msec Min. 0.2msec / Max. 1msec
7.1 TFT LCD Module
7.1 TFT LCD Module Type Part Number:
21
Type Part Number: MSCKT2407P30HB AL230F-A0G1D-P (P-TWO)
MSCKT2407P30HB (STM)
1.0 25 10.0 Mechanical Characteristics. 10.0 Mechanical Characteristics.
2010/04/22 26 Revised 2D drawing
All N/A Final Spec
20100722 Sec 10 Old panel diagram New with COF position
document version 1.0 3
NUMPAGES 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M200RW01 V3 open cell
AU OPTRONICS CORPORATION
6.6 Power ON/OFF Sequence 6.6 Power ON/OFF Sequence
2010/12/15 20
Parameter T1 max=1msec Parameter T1 max=10msec
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the CCFL reflector edge. Instead, press at
the far ends of the CCFL Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit
(IEC60950 or UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 1.0 4
NUMPAGES 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M200RW01 V3 open cell
AU OPTRONICS CORPORATION
2.0 General Description
This specification applies to the 20 inch-wide Color a-Si TFT-LCD Module M200RW01.The
display supports the HD+ 1600(H) x 900(V) screen format and 16.7M colors (RGB 6-bits + Hi-FRC
data). All input signals are 2-channel LVDS interface and this module doesn't contain an inverter
board for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25
ITEMS
Screen Diagonal
Active Area
Pixels H x V
Pixel Pitch
Unit
[mm]
[mm]
[um]
SPECIFICATIONS
508.05 (20.0")
442.8 (H) x 249.075 (V)
1600(x3) x 900
"
276.75 (per one triad) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
