Image preview - the first page of the document
![Panel_AUO_M201SP01_V1_0_[DS]](/pics/5c36aec896cf0.gif)
>> Download Panel_AUO_M201SP01_V1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M201SP01 V1
AU OPTRONICS CORPORATION
( V ) Preliminary Specification
( ) Final Specification
Module 20.1" WSXGA+ Color TFT-LCD
Model Name M201SP01 V1
Checked &
Customer Date Date
Approved by
Vincent CH Chen Aug. 7 , 2007
Approved by Prepared by
Jack CC Hsu Aug. 7 , 2007
Note: This Specification is subject to change without Desktop Display Business Unit /
notice. AU Optronics corporation
document version 0.1 1/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M201SP01 V1
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions.............................................................................................................. 4
2. General Description ................................................................................................................ 5
2.1 Display Characteristics ....................................................................................................................... 5
3. Functional Block Diagram .................................................................................................... 10
4. Absolute Maximum Ratings.................................................................................................. 11
4.1 Absolute Ratings of TFT LCD Module ............................................................................................ 11
4.2 Absolute Ratings of Backlight Unit .................................................................................................. 11
4.3 Absolute Ratings of Environment..................................................................................................... 11
5. Electrical characteristics ...................................................................................................... 13
5.1 TFT LCD Module ............................................................................................................................. 13
5.2 Backlight Unit................................................................................................................................... 14
6. Signal Characteristic............................................................................................................. 15
6.1 Pixel Format Image........................................................................................................................... 15
6.2 Signal Description............................................................................................................................. 16
6.3 The input data format........................................................................................................................ 19
6.4 Signal Electrical Characteristics ....................................................................................................... 21
6.5 Interface Timings .............................................................................................................................. 24
6.6 Power ON/OFF Sequence................................................................................................................. 26
7. Connector & Pin Assignment ............................................................................................... 27
7.1 TFT LCD Module ............................................................................................................................. 27
7.2 Backlight Unit................................................................................................................................... 30
8. Reliability Test ....................................................................................................................... 31
9. Shipping Label....................................................................................................................... 32
10. Mechanical Characteristics ................................................................................................ 33
document version 0.1 2/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M201SP01 V1
AU OPTRONICS CORPORATION
Record of Revision
Version & Date Page Old Description New Description Remark
0.1 2007/8/6 All First Edition for Customer
document version 0.1 3/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M201SP01 V1
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the CCFL reflector edge. Instead, press at the far
ends of the CCFL Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit (IEC60950 or
UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 0.1 4/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M201SP01 V1
AU OPTRONICS CORPORATION
2. General Description
M201SP01 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a driver circuit,
and backlight system. The screen format is intended to support the WSXGA+ (1680(H) x 1050(V)) screen
and 16.7M colors (RGB 6-bits + Hi-FRC data). The input signals are VESA standard analog RGB and
DVI-D interface compatible.This module does not contain an inverter card for backlight unit.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 511.13 (20.1" Wide)
Active Area [mm] 433.44(H) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
