Image preview - the first page of the document
![Panel_AUO_M215HW03_V1_1_[DS]](/pics/5c36aef830066.gif)
>> Download Panel_AUO_M215HW03_V1_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW03 V1
AU OPTRONICS CORPORATION
( ) Preliminary Specification
(V) Final Specification
Module 21.5" Color TFT-LCD
Model Name M215HW03 V1
Customer Date Approved by Date
Paul Huang Mar 22, 2011
Approved by Prepared by Date
Louis Jung Mar 22, 2011
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version 1.0 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW03 V1
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 Display Characteristics ................................................................................................................... 5
2.2 Optical Characteristics.................................................................................................................... 6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 TFT LCD Module ........................................................................................................................... 11
4.2 Absolute Ratings of Environment................................................................................................ 11
(OHFWULFDO FKDUDFWHULVWLFV
5.1 TFT LCD Module ........................................................................................................................... 12
5.1.1 Power Specification.................................................................................................................... 12
5.1.2 Signal Electrical Characteristics .............................................................................................. 13
6LJQDO &KDUDFWHULVWLF
6.1 Pixel Format Image ....................................................................................................................... 16
6.2 The input data format.................................................................................................................... 16
6.3 Signal Description.......................................................................................................................... 17
6.4 Timing Characteristics................................................................................................................... 19
6.5 Timing diagram............................................................................................................................... 20
6.6 Power ON/OFF Sequence ........................................................................................................... 21
&RQQHFWRU 3LQ $VVLJQPHQW
7.1 TFT LCD Module ........................................................................................................................... 22
3LQ $VVLJQPHQW
7.2 Connector on Backlight Unit. ........................................................................................................... 23
6LJQDO IRU /(' OLJKW EDU FRQQHFWRU
5HOLDELOLW\ 7HVW
6KLSSLQJ /DEHO
0HFKDQLFDO &KDUDFWHULVWLFV
3DFNLQJ 6SHFLILFDWLRQ
document version 1.0 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW03 V1
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/12/21 All First Edition for Customer -
0.2 2011/2/10 23 LED connector Revised
CVILUX ; CI1406M1HRB-NH ENTERY; 3707K-Q06N-01
1.0 2011/3/22 23 LED connector Revised
ENTERY: 3707K-Q06N-01 ENTERY: 3707K-S06N-21R
1.0 2011/3/22 23 N/A Add "Mating type Part Number" Revised
1.0 2011/3/22 6
1.0 2011/3/22 All Final Spec.
document version 1.0 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW03 V1
AU OPTRONICS CORPORATION
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the LED lightbar edge. Instead, press at the
far ends of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Pls avoid touching COF position while you are doing mechanical design.
14) When storing modules as spares for a long time, the following precaution is necessary:
Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep
the temperature between 5 and 35 at normal humidity.
document version 1.0 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW03 V1
AU OPTRONICS CORPORATION
2.0 General Description
This specification applies to the 21.5 inch-wide Color a-Si TFT-LCD Module M215HW03.The
display supports the Full HD - 1920(H) x 1080(V) screen format and 16.7M colors (RGB 6-bits +
Hi-FRC data). All input signals are 2-channel LVDS interface and this module doesn't contain an
driver board for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 546.86(21.53")
Active Area [mm] 476.64 (H) x 268.11 (V)
Pixels H x V 1920(x3) x 1080
Pixel Pitch [um] 248.25 (per one triad) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
