Image preview - the first page of the document

>> Download Panel_AUO_M215HW02_V0_1_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

Product Specification M215HW02 V0
AU OPTRONICS CORPORATION

( ) Preliminary Specification
( V ) Final Specification

Module 21.5" Color TFT-LCD

Model Name M215HW02 V0

Customer Date Approved by Date

3DXO +XDQJ 2011/01/17

Approved by Prepared by

.HQ +R 2011/01/17

Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation

document version 1.0 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification M215HW02 V0
AU OPTRONICS CORPORATION

Contents

1.0 Handling Precautions .....................................................................................5
2.0 General Description ........................................................................................6
2.1 Display Characteristics....................................................................................................... 6
2.2 Optical Characteristics ....................................................................................................... 7
3.0 Functional Block Diagram ............................................................................10
4.0 Absolute Maximum Ratings .........................................................................12
4.1 TFT LCD Module ............................................................................................................. 12
4.2 Backlight Unit ................................................................................................................... 12
4.3 Absolute Ratings of Environment..................................................................................... 12
5.0 Electrical characteristics ..............................................................................14
5.1 TFT LCD Module ............................................................................................................. 14
5.1.1 Power Specification ...................................................................................................... 14
5.1.2 Signal Electrical Characteristics.................................................................................... 15
5.2 Backlight Unit ................................................................................................................... 17
6.0 Signal Characteristic.....................................................................................18
6.1 Pixel Format Image.......................................................................................................... 18
6.2 The input data format....................................................................................................... 18
6.3 Signal Description ............................................................................................................ 19
6.4 Timing Characteristics ..................................................................................................... 21
6.5 Timing diagram ................................................................................................................ 22
6.6 Power ON/OFF Sequence ............................................................................................... 23
7.0 Connector & Pin Assignment .......................................................................24
7.1 TFT LCD Module ............................................................................................................. 24
7.1.1 Pin Assignment ............................................................................................................. 24
7.2 Connector on Backlight Unit. ........................................................................................... 25
7.2.1 Pin assignment ............................................................................................................. 25
8.0 Reliability Test ...............................................................................................26
9.0 Shipping Label ..............................................................................................27
10 Mechanical Characteristics ...........................................................................28
11 Packing Specification ....................................................................................29

document version 1.0 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification M215HW02 V0
AU OPTRONICS CORPORATION

Record of Revision

Version and
Page Old description New Description Remark
Date
0.1
First Version for Customer
2010/10/15
0.2
5 RGB 6 bits + Hi-FRC data RGB 8 bits data Revised
2010/11/22
Power consumption (VDD line + LED Power consumption (VDD line + LED
5 Revised
line): 21 watt line): 19.5 watt

11 Maximum LED current: 60 mA Maximum LED current: 90 mA. Revised

15 1. Maximum LED operation current: 1. Maximum LED operation current: 90
80 mA. mA.
2. Light bar operation voltage: 68 2. Light bar operation voltage: 72
Revised
voltage. voltage.
3. Maximum BLU power consumption: 3. Maximum BLU power consumption:
16.32 watt. 24.48 watt.
14) When storing module as spares for a
1.0 5 N/A
long time, the following precaution is
2010/01/17 necessary: Store them in a dark place. Do
not expose the module to sunlight orAdd
fluorescent light. Keep the temperature
between 5 and 35 at normal humidity

7 1. Viewing Angle, Horizontal Min./Typ. 1. Viewing Angle, Horizontal Min./Typ.
75/75/85/85 150 / 178.
Revised
2. Viewing Angle, Vertical Min./Typ. 2. Viewing Angle, Vertical Min./Typ. 150 /
70/70/80/80 178.
9 TrR + TrF = 25 msec (typ.). TrR + TrF = 16 msec (typ.). Revised

12 N/A
Note 3. 1.) 90% RH Max ( Ta 39 ) ;
2. ) Max wet-bulb temperature at 39 or Add
less. ( Ta 39 ); 3.) No condensation
Note4. Function Judged only
14 N/A Add IDD current and PDD power at 75 Hz.

Add

document version 1.0 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification M215HW02 V0
AU OPTRONICS CORPORATION

Revised

28 N/A Avoid touching COF position when doing
Add
mechanical design.

document version 1.0 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification M215HW02 V0
AU OPTRONICS CORPORATION

1.0 Handling Precautions

1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the LED lightbar edge. Instead, press at the
far ends of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Please avoid touching COF position while you are doing mechanical design.
14) When storing modules as spares for a long time, the following precaution is necessary:
Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep
the temperature between

document version 1.0 5

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification M215HW02 V0
AU OPTRONICS CORPORATION

2.0 General Description
This specification applies to the 21.5 inch-FHD Color a-Si TFT-LCD Module M215HW02. The
display supports the FHD - 1920(H) x 1080(V) screen format and 16.7M colors (RGB 8-bits data).
The light source of this TFT-LCD module is W-LED. All input signals are 2-channel LVDS interface
and this module doesn't contain a driver for backlight.

2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:

ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 546.86(21.53")
Active Area [mm] 476.64 (H) x 268.11 (V)
Pixels H x V 1920(x3) x 1080
Pixel Pitch [um] 248.25 (per one triad)
