Image preview - the first page of the document
![Panel_AUO_M220EW01_V4_0_[DS]](/pics/5c36af2d6483f.gif)
>> Download Panel_AUO_M220EW01_V4_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 22" WXGA+ Color TFT-LCD
Model Name M220EW01 V4
Checked &
Customer Date Date
Approved by
&0 :XQJ 2007/08/22
Approved by Prepared by
%RULV &KX 2007/08/22
Note: This Specification is subject to change without Desktop Display Business Group /
notice. AU Optronics corporation
document version 1.0 1
NUMPAGES |29}
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions.............................................................................................................. 4
2. General Description ................................................................................................................ 5
2.1 Display Characteristics ....................................................................................................................... 5
3. Functional Block Diagram .................................................................................................... 11
4. Absolute Maximum Ratings.................................................................................................. 12
4.1 Absolute Ratings of TFT LCD Module............................................................................................. 12
4.2 Absolute Ratings of Backlight Unit .................................................................................................. 12
4.3 Absolute Ratings of Environment ..................................................................................................... 13
5. Electrical characteristics ...................................................................................................... 14
5.1 TFT LCD Module ............................................................................................................................. 14
5.2 Backlight Unit ................................................................................................................................... 16
6. Signal Characteristic............................................................................................................. 17
6.1 Pixel Format Image........................................................................................................................... 17
6.2 The Input Data Format ...................................................................................................................... 18
6.4 Interface Timing................................................................................................................................ 21
6.5 Power ON/OFF Sequence................................................................................................................. 23
7. Connector & Pin Assignment ............................................................................................... 24
7.1 TFT LCD Module ............................................................................................................................. 24
7.2 Backlight Unit ................................................................................................................................... 25
8. Reliability Test ....................................................................................................................... 26
9. Shipping Label....................................................................................................................... 27
10. Mechanical Characteristics ................................................................................................ 28
document version 1.0 2
NUMPAGES |29}
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
Version and
Page Old description New Description Remark
Date
0.1 2007/04/19 All First Edition for Customer All
1.0 2007/08/22 5 Surface Treatment Hard-coating (3H), Surface Treatment Hard-coating (3H),
Non-glare type Revised
Non-glare type, reflection ratio 2.5%
1.0 2007/08/22 15 CCFL Life Time(LTCFL) Typ => TBD CCFL Life Time(LTCFL) Typ => 50,000 Revised
Optical ResponseTime Optical ResponseTime
1.0 2007/08/22 5 Revised
5 (Typ, on/off) 5 (Typ, on/off); 8 (Typ, SPD on)
Power Consumption
Power Consumption
(VDD line + CCFL line)
(VDD line + CCFL line)
1.0 2007/08/22 5 28.5W (Typ) (Without Invertor, All black 28.5W (Typ) SPD off / 32W (Typ) SPD Revised
pattern) on (Without Invertor, All black pattern)
Optical Response Time
1.0 2007/08/22 6 NA Min Typ Max Revised
MPRT - 8 15
Note 8: SPD Measurement is defined
1.0 2007/08/22 9~10 NA as below: Revised
IDD Input Current
Min Typ Max
IDD Input Current
- 890 1500
Min Typ Max
1.0 2007/08/22 14 VDD= 5.0V, All black pattern At 60Hz
- 890 1500 Revised
- 1200 1800
VDD= 5.0V, All black pattern At 60Hz
VDD= 5.0V, All black pattern At 75Hz,
SPD on
IDD Input Current
Min Typ Max
PDD VDD Power
- 5 7
Min Typ Max
1.0 2007/08/22 14 VDD= 5.0V, All black pattern At 60Hz
- 5 7 Revised
- 6 8
VDD= 5.0V, All black pattern At 60Hz
VDD= 5.0V, All black pattern At 75Hz,
SPD on
document version 1.0 3
NUMPAGES |29}
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the CCFL reflector edge. Instead, press at the far
ends of the CCFL Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit (IEC60950 or
UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 1.0 4
NUMPAGES |29}
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
2. General Description
This specification applies to the 22 inch-wide Color TFT-LCD Module M220EW01.
The display supports the WSXGA+ (1680(H) x 1050(V)) screen format and 16.7M colors. All input signals are 2
Channel LVDS interface compatible.
This module does not contain an inverter card for backlight. .
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Active Area [mm] 473.76 (H) x 296.1(V)
Pixels H x V 1680x3(RGB) x 1050
Pixel Pitch [mm] 0.282x 0.282
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN Mode,Normally White
White Luminance [cd/m2] 300 cd/m2 @ 7.0mA (Typ)
Contrast Ratio 1000:1 (Typ)
Optical ResponseTime [msec] 5 (Typ, on/off); 8 (Typ, SPD on)
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption 28.5W (Typ) SPD off / 32W (Typ) SPD on
[Watt]
(VDD line + CCFL line) (Without Invertor, All black pattern)
Weight [Grams] 2385 Note1
Physical Size (H x V x D) [mm] 493.7(W) x 320.1(H) x 16.7(D) (Typ)
Electrical Interface Dual Channel LVDS
Support Colors 16.7M colors (6-bits + HiFRC)
Temperature Range [oC] 0 to +50
Operating [oC] -20 to +60
Storage (Shipping)
Hard-coating (3H), Non-glare type
Surface Treatment
reflection ratio 2.5%
RoHS Compliance RoHS Compliance
Note1: 2500 gm (Max)
document version 1.0 5
NUMPAGES |29}
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):Except
MPRT, all data are measured with SPD OFF.
Item Unit Conditions Min. Typ. Max. Note
Horizontal
(Right)+ (Left) 160 170 -
CR = 10
Viewing Angle [degree] 1
Vertical
(Up) + (Down) 150 160 -
CR = 10
Luminance Uniformity [%] 9 Points 75 80 - 2, 3
Rising - 3.6 5.7
Falling - 1.4 2.3 4, 6
Optical Response Time [msec]
Rising + Falling - 5 8
MPRT - 8 15 8
Red x 0.628 0.658 0.688
Red y 0.301 0.331 0.361
Green x 0.178 0.208 0.238
Color / Chromaticity Green y 0.649 0.679 0.709
Coordinates 4
(CIE 1931) Blue x 0.117 0.147 0.177
Blue y 0.035 0.065 0.095
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
White Luminance
(At CCFL= 7.0mA)
[cd/m2 ] 240 300 - 4
Contrast Ratio Normal Direction 600 1000 - 4
Cross Talk (At 75Hz) [%] - - 1.5 5
Flicker [dB] - - -20 7
Optical Equipment: BM-5A, BM-7, PR880, or equivalent
document version 1.0 6
NUMPAGES |29}
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M220EW01 V4
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle: measured by ELDIM (EZContrast 88)
