Image preview - the first page of the document
![Panel_AUO_M240HTN01-0_0_[DS]](/pics/5c36af33c0504.gif)
>> Download Panel_AUO_M240HTN01-0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HTN01.0
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V) Final Specification
Module 24.0" Color TFT-LCD
Model Name M240HTN01.0
Customer Date Approved by Date
Howard Lee 2012/01/09
Approved by Prepared by
Bernice Huang 2012/01/09
Note: This Specification is subject to change Desktop Display Business Group /
without notice. AU Optronics Corporation
document version 1.0 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HTN01.0
AU OPTRONICS CORPORATION
Content
1 HANDLING PRECAUTIONS.......................................................................................................... 4
2 GENERAL DESCRIPTION............................................................................................................. 5
2.1 Display Characteristics ............................................................................................................................. 5
2.2 Optical Characteristics.............................................................................................................................. 6
3 FUNCTIONAL BLOCK DIAGRAM .............................................................................................. 10
4 ABSOLUTE MAXIMUM RATINGS .............................................................................................. 11
4.1 TFT LCD Module .................................................................................................................................... 11
4.2 Backlight Unit.......................................................................................................................................... 11
4.3 Absolute Ratings of Environment........................................................................................................... 11
5 ELECTRICAL CHARACTERISTICS ........................................................................................... 12
5.1 TFT LCD Module .................................................................................................................................... 12
5.1.1 Power Specification ........................................................................................................................................ 12
5.1.2 Signal Electrical Characteristics ..................................................................................................................... 13
5.2 Backlight Unit.......................................................................................................................................... 15
6 SIGNAL CHARACTERISTICS..................................................................................................... 16
6.1 Pixel Format Definition ........................................................................................................................... 16
6.2 Input Data Format Definition .................................................................................................................. 16
6.3 Signal Description................................................................................................................................... 17
6.4 Timing Characteristics ............................................................................................................................ 19
6.5 Timing Diagram ...................................................................................................................................... 20
6.6 Power ON/OFF Sequence ..................................................................................................................... 21
7 CONNECTOR AND PIN ASSIGNMENT ..................................................................................... 22
7.1 TFT LCD Module .................................................................................................................................... 22
7.1.1 LVDS Connector Pin Assignment .................................................................................................................. 22
7.2 Backlight Unit.......................................................................................................................................... 23
7.2.1 Light Bar Connector Pin Assignment ............................................................................................................. 23
7.2.2 Light Bar Connector Dimension ..................................................................................................................... 23
8 RELIABILITY TEST...................................................................................................................... 24
9 SHIPPING LABEL ........................................................................................................................ 25
10 MECHANICAL CHARACTERISTICS.......................................................................................... 26
11 PACKING SPECIFICATION ........................................................................................................ 28
11.1 Packing Flow .......................................................................................................................................... 28
11.2 Pallet and Shipment Information ............................................................................................................ 29
document version 1.0 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HTN01.0
AU OPTRONICS CORPORATION
Records of Revision
Version and Date Page Old Description New Description Remark
0.1 2011/11/21 All First Edition for Customer N/A
0.2 2011/11/21 20 7.2 Add L/B CNT Mating Type
1.0 2012/01/04 21 Final version
6.6 T5 min changes to 40 msec
document version 1.0 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HTN01.0
AU OPTRONICS CORPORATION
1 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of LED light bar edge. Instead, press at the far ends
of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Avoid touching COF position while doing mechanical design.
14) While storing modules as spares for a long time, the following precautions are necessary:
Store modules in a dark place. Do not expose them to sunlight or fluorescent light.
Keep the temperature between 5◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
