Image preview - the first page of the document
![Panel_AUO_M240HW02_V1_1_[DS]](/pics/5c36af667617d.gif)
>> Download Panel_AUO_M240HW02_V1_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V1
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 24.0" Color TFT-LCD
Model Name M240HW02 V1
Customer Date Approved by Date
:LQQLH&KDQJ 2011/2/17
Approved by Prepared by
-DPHV :HQJ 2011/2/17
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version 1.7
1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V1
AU OPTRONICS CORPORATION
Contents
1.0 Handling Precautions
2.0 General Description
2.1 Display Characteristics ...................................................................................................................................... 5
2.2 Optical Characteristics....................................................................................................................................... 6
3.0 Functional Block Diagram
4.0 Absolute Maximum Ratings
4.1 TFT LCD Module ............................................................................................................................................. 11
4.2 Backlight Unit ................................................................................................................................................... 11
4.3 Absolute Ratings of Environment..................................................................................................................... 11
5.0 Electrical characteristics
5.1 TFT LCD Module ............................................................................................................................................. 12
5.1.1 Power Specification ...................................................................................................................................... 12
5.1.2 Signal Electrical Characteristics
5.2 Backlight Unit...........................................................................................................................14
6.0 Signal Characteristic
6.1 Pixel Format Image.......................................................................................................................................... 16
6.2 The input data format....................................................................................................................................... 16
6.3 Signal Description ............................................................................................................................................ 17
6.4 Timing Characteristics ..................................................................................................................................... 19
6.5 Timing diagram ................................................................................................................................................ 20
6.6 Power ON/OFF Sequence............................................................................................................................... 21
7.0 Connector & Pin Assignment
7.1 TFT LCD Module ............................................................................................................................................. 22
7.1.1 Pin Assignment ............................................................................................................................................. 22
7.2 Connector on Backlight Unit........................................................................................................ 22
7.2.1 Signal for Lamp connector.........................................................................................................22
8.0 Reliability Test
9.0 Shipping Label
document version 1.7 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V1
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/03/04 All First Edition for Customer All
1.0 2010/6/15 5,6 Update spec table
1.1 2010/7/27 26 Change shipping label location
1.2 2010/8/10 27 Add a drawing of COF position
1.3 2010/8/16 5 Correct an error of "CCFL line" LED line
1.4 2010/9/17 4 Add item 13 of 1.0 handling precautions
1.4 2010/9/17 5 Add TCO 5.1 compliance
1.5 2010/11/23 5 Power consumption 27W Power consumption 26.3W
1.5 2010/11/23 11 LED current max 150 LED current max 120
1.6 2011/2/14 12 Ripple 300mV Ripple 500mV
1.6 2011/2/14 12 Add IDD/PDD at 75Hz
1.7 2011/2/17 19 Data CLK max 83 MHz Data CLK max 85 MHz
1.7 2011/2/17 19 H-section Period min 1034 Tclk H-section Period min 1004 Tclk
document version 1.7 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V1
AU OPTRONICS CORPORATION
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of LED light bar edge. Instead, press at the far
ends of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Avoid touching COF position while doing mechanical design.
document version 1.7 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V1
AU OPTRONICS CORPORATION
2.0 General Description
This specification applies to the 24 inch-wide Color TFT-LCD Module M240HW02. The display
supports the Full HD - 1920(H) x 1080(V) screen format and 16.7M colors (RGB 8-bits data). All
input signals are dual channel LVDS interface and this module doesn't contain an inverter board
for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 609.7(24.0")
Active Area [mm] 531.36 (H) x 298.89 (V)
Pixels H x V 1920(x3) x 1080
Pixel Pitch [um] 276.75 (per one triad) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
