Image preview - the first page of the document
![Panel_AUO_M240HW02_V5_0_[DS]](/pics/5c36af6ce721f.gif)
>> Download Panel_AUO_M240HW02_V5_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V5
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 24" Color TFT-LCD
Model Name M240HW02 V5
Customer Date Approved by Date
Winnie Chang 2010/05/30
Approved by Prepared by
Tony Kao 2010/05/30
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version 1.0 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V5
AU OPTRONICS CORPORATION
Contents
1.0 Handling Precautions ................................................................................................................4
2.0 General Description ...................................................................................................................5
2.1 Display Characteristics...........................................................................................................5
2.2 Optical Characteristics ...........................................................................................................6
3.0 Functional Block Diagram...................................................................................................... 10
4.0 Absolute Maximum Ratings ................................................................................................... 11
4.1 TFT LCD Module ..................................................................................................................11
4.2 Backlight Unit........................................................................................................................11
4.3 Absolute Ratings of Environment.........................................................................................11
5.0 Electrical characteristics........................................................................................................ 12
5.1 TFT LCD Module ................................................................................................................. 12
5.1.1 Power Specification.......................................................................................................... 12
5.1.2 Signal Electrical Characteristics....................................................................................... 13
5.2 Backlight Unit....................................................................................................................... 15
6.0 Signal Characteristic............................................................................................................... 16
6.1 Pixel Format Image ............................................................................................................. 16
6.2 The input data format .......................................................................................................... 17
6.3 Signal Description ............................................................................................................... 18
6.4 Timing Characteristics ......................................................................................................... 21
6.5 Timing diagram .................................................................................................................... 22
6.6 Power ON/OFF Sequence .................................................................................................. 23
7.0 Connector & Pin Assignment ................................................................................................ 24
7.1 TFT LCD Module ................................................................................................................. 24
7.1.1 Pin Assignment ................................................................................................................ 24
7.2 Connector on Backlight Unit. .............................................................................................. 25
7.2.1 Pin assignment................................................................................................................. 26
8.0 Reliability Test ......................................................................................................................... 27
9.0 Shipping Label ......................................................................................................................... 28
10.0 Mechanical Characteristics ................................................................................................. 29
11.0 Packing Specification ........................................................................................................... 31
document version 1.0 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V5
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1
First Version
2010/11/29
Response time Response time
0.2 Raising time: 7 ms Raising time: 7 ms
6
2011/03/24 Falling time: 7 ms Falling time: 5 ms
Raising+Falling time: 14ms Raising+Falling time: 12ms
2.1 Display Characteristics
0.3 2.1 Display Characteristics
5 Power Consumption (VDD line + LED line)
2011/4/20 Power Consumption (VDD line + LED line) 8W
7.5W
I/F PCB Interface: I/F PCB Interface:
185132-15021 12507WR-H15L
10
Mating Type: Mating Type:
12507HS-15L 12507HS-H15L
12
5.1.1 Power Specification 5.1.1 Power Specification
DD Typ. 1.5A IDD Typ. 1.6A
PDD Typ. 7.5W PDD Typ. 8W
IRush Max. TBD IRush Max. 3A
13 5.1.2 Signal Electrical Characteristics 5.1.2 Signal Electrical Characteristics
Input signals shall be low or Hi-Z state when Input signals shall be low or Hi-Z state when VDD
VDD is off. Please refer to specifications of is off.
SN75LVDS82DGG (Texas Instruments) in detail.
18 6.3 Signal Description 6.3 Signal Description
The module using one LVDS receiver The module using 51pin 4port-LVDS interface.
SN75LVDS82(Texas Instruments). LVDS is a LVDS is a differential signal technology for LCD
differential signal technology for LCD interface interface and high speed data transfer device. The
and high speed data transfer device. LVDS first/third LVDS port(RxOxxx) transmits odd pixels
transmitters shall be SN75LVDS83(negative while the second/fourth LVDS port(RxExxx)
edge sampling). The first/third LVDS transmits even pixels.
port(RxOxxx) transmits odd pixels while the
second/fourth LVDS port(RxExxx) transmits even
pixels.
21 6.4 Timing Characteristics 6.4 Timing Characteristics
Basically, interface timing described here is not The input timing characteristics are shown as the
actual input timing of LCD module but close to following table
output timing of SN75LVDS82DGG (Texas
Instruments) or equivalent.
24 VDD Connector: VDD Connector:
Manufacturer: P-TWO or compatible Manufacturer: YEONHO or compatible
Type Part Number: 185132-15021 Type Part Number: 12507WR-H15L
Mating Housing Part Number: Yeon-Ho Mating Housing Part Number: YEONHO
12507HS-15L 12507HS-H15L
1.0 6 Central Luminance 200nits Central Luminance 280nits
2011/5/30
24 7.1 TFT LCD Module 7.1 TFT LCD Module
LVDS connector: JAE or compatible LVDS connector: JAE
24 7.1 TFT LCD Module 7.1 TFT LCD Module
VDD connector: YEONHO or compatible VDD connector: YEONHO
All Final the Spec.
document version 1.0 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M240HW02 V5
AU OPTRONICS CORPORATION
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the LED lightbar edge. Instead, press at the
far ends of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Please avoid touching COF position while you are doing mechanical design
14) When storing modules as spares for a long time, the following precaution is necessary:
Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep
the temperature be
