Image preview - the first page of the document
![Panel_AUO_T260XW02_VQ_0_[DS]](/pics/5c36b2dcf123e.gif)
>> Download Panel_AUO_T260XW02_VQ_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Description: T260XW02 TFT-LCD PANEL with RoHS Guarantee
AUO Model Name: T260XW02 VQ
Customer Part No/Project Name:
Customer Signature Date AUO Date
Approved By: PM Director/ Frank Hsu
Reviewed By: RD Director/ Hong Hong Jye
Reviewed By: Project Leader/ Polo Shen
Prepared By: PM/ Alvin Chung
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
0/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Document Version: 1.0
Date: 2008/9/17
Product Specifications
26.0" WXGA Color TFT-LCD Module
Model Name: T260XW02 VQ
(*) Preliminary Specifications
() Final Specifications
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
1/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
No ITEM
COVER
CONTENTS
RECORD OF REVISIONS
1 GENERAL DESCRIPTION
2 ABSOLUTION MAXIMUM RATINGS
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTERISTICS
3-2 INTERFACE CONNECTIONS
3-3 SIGNAL TIMING SPECIFICATIONS
3-4 SIGNAL TIMING WAVEFORMS
3-5 COLOR INPUT DATA REFERENCE
3-6 POWER SEQUENCE for LCD
3-7 POWER SEQUENCE for INVERTER
4 OPTICAL SPECIFICATIONS
5 MECHANICAL CHARACTERISTICS
5-1 FRONT VIEW
5-2 REAR VIEW
6 RELIABILITY
7 INTERNATIONAL STANDARDS
7-1 SAFETY
7-2 EMC
7-3 GREEN
8 PACKING
9 PRECAUTIONS
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
2/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Record of Revision
Version Date No Old Description New Description Remark
1.0 2008/09/17 First release
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
3/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. General Description
This specification applies to the 26.0 inch Color TFT-LCD Module T260XW02 VQ. This LCD
module has a TFT active matrix type liquid crystal panel 1366x768 pixels, and diagonal size of 26.0
inch. This module supports 1366x768 XGA-WIDE mode (Non-interlace).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale
signal for each dot.
The T260XW02 VQ has been designed to apply the 8-bit 1 channel LVDS interface method. It is
intended to support displays where high brightness, wide viewing angle, high color saturation, and
high color depth are very important. The T260XW02 VQ model is RoHS verified which can be
distinguished on panel label.
* General Information
Items Specification Unit Note
Active Screen Size 26.0 inches
Display Area 575.769 (H) x 323.712(V) mm
Outline Dimension 626.0 (H) x 373.0 (V) x 45.0(D) mm With inverter
Driver Element a-Si TFT active matrix
Display Colors 16.7M Colors
Number of Pixels 1366 x 768 Pixel
Pixel Pitch 0.4215 mm
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Surface Treatment AG, Haze=11%, 3H
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
4/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to
the unit.
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VCC -0.3 13.2 [Volt] Note 1
Input Voltage of Signal Vin -0.3 3.6 [Volt] Note 1
BLU Input Voltage VDDB -0.3 27.0 [Volt] Note 1
BLU Brightness Control Voltage VDIM -0.3 6.0 [Volt] Note 1
Operating Temperature TOP 0 +50 [oC] Note 2
Operating Humidity HOP 10 90 [%RH] Note 2
Storage Temperature TST -20 +60 [oC] Note 2
Storage Humidity HST 10 90 [%RH] Note 2
Panel Surface Temperature PST 65 [oC] Note 3
Note 1: Duration = 1 sec
Note 2: Maximum Wet-Bulb should be 39 and No condensation.
The relative humidity must not exceed 90% non-condensing at temperatures of 40 or less. At temperatures greater
than 40 , the wet bulb temperature must not exceed 39 .
Note 3: Surface temperature is measured at 50 Dry condition
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
5/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3. Electrical Specification
The T260XW02 VQ requires two power inputs. One is employed to power the LCD electronics and
to drive the TFT array and liquid crystal. The second input power for the BLU is to power inverter.
3-1 Electrical Characteristics
Values
Parameter Symbol Min Typ Max Unit Notes
LCD:
Power Supply Input Voltage Vcc 10.8 12 13.2 Vdc 1
Power Supply Input Current Icc - 0.35 A 2
Power Consumption Pc - 4.2 Watt 2
Inrush Current IRUSH - - 3.0 Apeak 3
Differential Input High
VTH +100 mV 4
Threshold Voltage
LVDS Differential Input Low
VTL -100 mV 4
Interface Threshold Voltage
Common Input
VCIM 1.10 1.25 1.40 V 4
Voltage
Input High Threshold VIH
2.4 3.3 Vdc
CMOS Voltage (High)
Interface Input Low Threshold VIL
0 0.7 Vdc
Voltage (Low)
Backlight Power Consumption PDDB 40 Watt 8
Life Time 50,000 60,000 Hours 9
Note :
1. The ripple voltage should be controlled under 10% of VCC
2. Vcc=12.0V, f v = 60Hz, fCLK=81.5Mhz , 25 , Test Pattern : White Pattern
3. Measurement condition :
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
6/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4. VCIM = 1.2V
VTH
VCIM
VIL
0V
5. The performance of the Lamp in LCM, for example life time or brightness, is extremely influenced by the
characteristics of the DC-AC Inverter. So all the parameters of an inverter should be carefully designed so as
not to produce too much leakage current from high-voltage output of the inverter. When you design or order
the inverter, please make sure unwanted lighting caused by the mismatch of the lamp and the inverter (no
lighting, flicker, etc) never occurs. When you confirm it, the LCD Assembly should be operated in the same
condition as installed in your instrument.
6. Do not attach a conducting tape to lamp connecting wire. If the lamp wire attach to conducting tape, TFT-LCD
Module have a low luminance and the inverter has abnormal action because leakage current occurs between
lamp wire and conducting tape.
7. The relative humidity must not exceed 80% non-condensing at temperatures of 40 or less. At temperatures
greater than 40 , the wet bulb temperature must not exceed 39 . When operate at low temperatures, the
brightness of CCFL will drop and the life time of CCFL will be reduced.
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
7/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3-2 Interface Connections
LCD connector (CN1): Starconn 093G30-B0001A-1
Pin No Symbol Description Default
1 VCC +12V, DC, Regulated
2 VCC +12V, DC, Regulated
3 VCC +12V, DC, Regulated
4 VCC +12V, DC, Regulated
5 GND Ground and Signal Return
6 GND Ground and Signal Return
7 GND Ground and Signal Return
8 GND Ground and Signal Return
9 LVDS Option Low/Open for Normal (NS), High for JEIDA NS Mode
10 Reserved Open or High AUO internal test
11 GND Ground and Signal Return for LVDS
12 RIN0- LVDS Channel 0 negative
13 RIN0+ LVDS Channel 0 positive
14 GND Ground and Signal Return for LVDS
15 RIN1- LVDS Channel 1 negative
16 RIN1+ LVDS Channel 1 positive
17 GND Ground and Signal Return for LVDS
18 RIN2- LVDS Channel 2 negative
19 RIN2+ LVDS Channel 2 positive
20 GND Ground and Signal Return for LVDS
21 RCLK- LVDS Clock negative
22 RCLK+ LVDS Clock positive
23 GND Ground and Signal Return for LVDS
24 RIN3- LVDS Channel 3 negative
25 RIN3+ LVDS Channel 3 positive
26 GND Ground and Signal Return for LVDS
27 Reserved Open or High AUO internal test
28 Reserved Open or High AUO internal test
29 GND Ground and Signal Return
30 GND Ground and Signal Return
Note:
1. All GND (ground) pins should be connected together and should also be connected to the LCD's metal frame.
2. All Vcc (power input) pins should be connected together.
Copyright AU Optronics, Inc.
January, 2003 All Rights Reserved. T260XW02 VQ - Spec. Ver1.0
8/27
No Reproduction and Redistribution Allowed
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
