Image preview - the first page of the document
Panel_AUO_T260XW04_V8_0_[DS]


>> Download Panel_AUO_T260XW04_V8_0_[DS] documenatation <<

Text preview - extract from the document
Model Name: T260XW04 V8
     Issue Date : 2010/11/05

  ( ) Preliminary Specifications
  () Final Specifications

                        Contents
No
           CONTENTS

           RECORD OF REVISIONS

1          GENERAL DESCRIPTION

2          ABSOLUTE MAXIMUM RATINGS

3          ELECTRICAL SPECIFICATION

     3-1   ELECTRIACL CHARACTERISTICS

     3-2   INTERFACE CONNECTIONS

     3-3   SIGNAL TIMING SPECIFICATION

     3-4   SIGNAL TIMING WAVEFORM

     3-5   COLOR INPUT DATA REFERENCE

     3-6   POWER SEQUENCE

     3-7   BACKLIGHT SPECIFICATION

4          OPTICAL SPECIFICATION

5          MECHANICAL CHARACTERISTICS

6          RELIABILITY TEST ITEMS

7          INTERNATIONAL STANDARD

     7-1   SAFETY

     7-2   EMC

8          PACKING

     8-1   DEFINITION OF LABEL

     8-2   PACKING METHODS

     8-3   PALLET AND SHIPMENT INFORMATION

9          PRECAUTION

     9-1   MOUNTING PRECAUTIONS

     9-2   OPERATING PRECAUTIONS

     9-3   ELECTROSTATIC DISCHARGE CONTROL

     9-4   PRECAUTIONS FOR STRONG LIGHT EXPOSURE

     9-5   STORAGE

     9-6   HANDLING PRECAUTIONS FOR PROTECT FILM
Record of Revision
 Version     Date       Page                   Description
   0.0     2010/09/27          First release
1. General Description
   This specification applies to the 26.0 inch Color TFT-LCD Module T260XW04 V8 This LCD module has a TFT
active matrix type liquid crystal panel 1366x768 pixels, and diagonal size of 26.0 inch. This module supports
1366x768 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot.
   The T260XW04 V8has been designed to apply the 8-bit 1 channel LVDS interface method. It is intended to
support displays where high brightness, wide viewing angle, high color saturation, and high color depth are very
important.




* General Information


                 Items                             Specification                 Unit                Note
Active Screen Size                                      26.00                     inch
Display Area                                 575.769 (H) x 323.712(V)             mm
Outline Dimension                         626.0 (H) x 373.0 (V) x 54.8 (D)        mm       With T-balance board
Driver Element                                 a-Si TFT active matrix
Display Colors                                       8 bit, 16.7M               Colors
Number of Pixels                                     768 x1366                   Pixel
Pixel Pitch                                   0.4215 (H) x 0.4215(W)              mm
Pixel Arrangement                                RGB Horizontal stripe
Display Operation Mode                             Normally Black
Surface Treatment                                  Anti-Glare, 3H                        Haze=2%
2. Absolute Maximum Ratings
      The followings are maximum values which, if exceeded, may cause faulty operation or damage to the unit


                  Item                 Symbol            Min               Max   Unit             Conditions
 Logic/LCD Drive Voltage                 Vcc             -0.3               14   [Volt]        Note 1
 Input Voltage of Signal                 Vin             -0.3               4    [Volt]        Note 1
                                                                                  o
 Operating Temperature                   TOP              0                +50    [ C]         Note 2
 Operating Humidity                     HOP              10                90    [%RH]         Note 2
                                                                                  o
 Storage Temperature                     TST             -20               +60    [ C]         Note 2
 Storage Humidity                        HST             10                90    [%RH]         Note 2
                                                                                  o
 Panel Surface Temperature               PST                               65     [ C]         Note 3

Note 1: Duration: 1sec.
Note 2 : Maximum Wet-Bulb should be 39         and No condensation.
The relative humidity must not exceed 90% non-condensing at temperatures of 40            or less. At temperatures
greater than 40    , the wet bulb temperature must not exceed 39       .
Note 3: Surface temperature is measured at 50       Dry condition
3. Electrical Specification
The T260XW04 V2 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT
array and liquid crystal. The second input for BLU is to power inverter.


Electrical Characteristics

     3.1.1: DC Characteristics

                                                                                Value
                      Parameter                           Symbol                               Unit   Note
                                                                       Min.     Typ.    Max
LCD
Power Supply Input Voltage (for input power=12V)            VDD        10.8     12      13.2   VDC
Power Supply Input Voltage (for input power=5V)             VDD            --   0.22    0.34   VDC
Power Supply Input Current (Define to section:1.1)           IDD           --   2.64    4.08    A      1
Inrush Current (Define to section:1.1)                      IRUSH          --    --      3      A      2

            Input Differential Voltage                       VID       200      400     600    mVDC    3

LVDS        Differential Input High Threshold Voltage       VTH        +100      --     +300   mVDC    3
Interface
            Differential Input Low Threshold Voltage         VTL       -300      --     -100   mVDC    3

            Input Common Mode Voltage                       VICM       1.1      1.25    1.4    VDC     3
                                                             VIH
CMOS        Input High Threshold Voltage                               2.7       --     3.3    VDC     4
                                                           (High)
Interface                                                    VIL
            Input Low Threshold Voltage                                    0     --     0.6    VDC     4
                                                           (Low)
Backlight Power Consumption                                  PBL           -    55       -     Watt


     3.1.2: AC Characteristics

                                                                                Value
                      Parameter                           Symbol                               Unit   Note
                                                                       Min.     Typ.    Max
            Input Channel Pair Skew Margin
                                                          tSKEW (CP)   -500      --     +500    ps     5
            (only for TCON: 12403U1, 12405K01)
            Receiver Clock : Spread Spectrum                           Fclk             Fclk
                                                          Fclk_ss                --            MHz     6
            Modulation range                                           -3%              +3%
LVDS
Interface   Receiver Clock : Spread Spectrum
                                                            Fss            30    --     200    KHz     6
            Modulation frequency
            Receiver Data Input Margin
                    Fclk = 85 MHz                          tRMG        -0.4      --     0.4     ns     7
                    Fclk = 65 MHz                                      -0.5      --     0.5
                                                                             T260XW04 V8 Product Specification
                                                                                                     Rev. 1.0
Note :
   1.    Test Condition:
               (1)   VDD = 12.0V
               (2)   Fv = Type Timing, 60Hz, 120Hz or Other
               (3)   Fclk= Max freq.
               (4)   Temperature = 25
               (5)   Typ. Input current : White Pattern
                    Max. Input current: Heavy loading pattern defined by AUO
         >> refer to "Section:3.3 Signal Timing Specification, Typical timing"


   2.    Measurement condition : Rising time = 400us

                                                                             VDD
                                                             90%



                                           10%
                                GND

                                                    400
