Image preview - the first page of the document
![Panel_AUO_T315XW04_V3_0_[DS]](/pics/5c36b7d302207.gif)
>> Download Panel_AUO_T315XW04_V3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
Model Name: T315XW04 V3
Issue Date : 2010/12/25
( )Preliminary Specifications
( )Final Specifications
Customer Signature Date AUO Date
Approved By Approval By PM Director
_________________________________ ____________________________________
Note Reviewed By RD Director
____________________________________
Reviewed By Project Leader
____________________________________
Prepared By PM
____________________________________
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
Contents
No
CONTENTS
RECORD OF REVISIONS
1 GENERAL DESCRIPTION
2 ABSOLUTE MAXIMUM RATINGS
3 ELECTRICAL SPECIFICATION
3-1 ELECTRIACL CHARACTERISTICS
3-2 INTERFACE CONNECTIONS
3-3 SIGNAL TIMING SPECIFICATION
3-4 SIGNAL TIMING WAVEFORM
3-5 COLOR INPUT DATA REFERENCE
3-6 POWER SEQUENCE
3-7 BACKLIGHT SPECIFICATION
4 OPTICAL SPECIFICATION
5 MECHANICAL CHARACTERISTICS
6 RELIABILITY TEST ITEMS
7 INTERNATIONAL STANDARD
7-1 SAFETY
7-2 EMC
8 PACKING
8-1 DEFINITION OF LABEL
8-2 PACKING METHODS
8-3 PALLET AND SHIPMENT INFORMATION
9 PRECAUTION
9-1 MOUNTING PRECAUTIONS
/9-2 OPERATING PRECAUTIONS
9-3 ELECTROSTATIC DISCHARGE CONTROL
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE
9-5 STORAGE
9-6 HANDLING PRECAUTIONS FOR PROTECT FILM
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
Record of Revision
Version Date Page Description
0.0 2010/12/25 First release
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
1. General Description
This specification applies to the 31.5 inch Color TFT-LCD SKD model T315XW04 V3. This LCD Open Cell Unit
has a TFT active matrix type liquid crystal panel 1366 x 768 pixels, and diagonal size of 31.5 inch. This Open Cell
Unit supports 1366 x 768 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are
arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale
signal for each dot.
* General Information
Items Specification Unit Note
Active Screen Size 31.5 inch
Display Area 697.6(H)*392.2(V) mm
Outline Dimension 760.0(H)*450.0(V)*46.9(D) mm D: front bezel to T-con cover
Driver Element a-Si TFT active matrix
Display Colors 8 bit, 16.7M Colors
Number of Pixels 1366 x 768 Pixel
Pixel Pitch 0.51075 mm
Pixel Arrangement RGB vertical stripe
Display Operation Mode Normally Black
Surface Treatment Anti-Glare, 3H Haze=2%
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
2. Absolute Maximum Ratings
The followings are maximum values which, if exceeded, may cause faulty operation or damage to the unit
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage (for Vcc -0.3 14 [Volt] Note 1
12V input)
Input Voltage of Signal (for 5V Vin -0.3 3.6 [Volt] Note 1
input)
o
Operating Temperature TOP 0 +50 [ C] Note 2
Operating Humidity HOP 10 90 [%RH] Note 2
o
Storage Temperature TST -20 +60 [ C] Note 2
Storage Humidity HST 10 90 [%RH] Note 2
o
Panel Surface Temperature PST 65 [ C] Note 3
Note 1: Duration:50 msec.
Note 2 : Maximum Wet-Bulb should be 39 and No condensation.
The relative humidity must not exceed 90% non-condensing at temperatures of 40 or less. At temperatures
greater than 40 , the wet bulb temperature must not exceed 39 .
Note 3: Surface temperature is measured at 50 Dry condition
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
3. Electrical Specification
The T315XW04 V3 Open Cell Unit requires power input which is employed to power the LCD electronics and to
drive the TFT array and liquid crystal.
3.1 Electrical Characteristics
3.1.1: DC Characteristics
Value
Parameter Symbol Unit Note
Min. Typ. Max
LCD
Power Supply Input Voltage VDD 10.8 12 13.2 VDC
Power Supply Input Current IDD -- 0.3 0.36 A 1
Inrush Current IRUSH -- 2 3 A 2
Input Differential Voltage VID 200 400 600 mVDC 3
LVDS Differential Input High Threshold Voltage VTH +100 -- +300 mVDC 3
Interface
Differential Input Low Threshold Voltage VTL -300 -- -100 mVDC 3
Input Common Mode Voltage VICM 1.1 1.25 1.4 VDC 3
VIH
CMOS Input High Threshold Voltage 2.7 -- 3.3 VDC
(High)
Interface VIL
Input Low Threshold Voltage 0 -- 0.6 VDC
(Low)
Backlight Power Consumption PBL 55 Watt
3.1.2: AC Characteristics
Value
Parameter Symbol Unit Note
Min. Typ. Max
Receiver Clock : Spread Spectrum Fclk Fclk
Fclk_ss -- MHz 4
Modulation range -3% +3%
Receiver Clock : Spread Spectrum
LVDS Fss 30 -- 200 KHz 4
Modulation frequency
Interface
Receiver Data Input Margin
Fclk = 85 MHz tRMG -0.4 -- 0.4 ns 5
Fclk = 65 MHz -0.5 -- 0.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
Note :
1. Test Condition:
(1) VDD = 12.0V
(2) Fv = 60 Hz
(3) Fclk= 82 Mhz(typ)
(4) Temperature = 25
(5) Typ. Input current : White Pattern
2. Measurement condition : Rising time = 400us
9''
*1'
s
3. VICM = 1.25V
LVDS -
V IC M V TH
|V ID |
V TL
LVDS +
GND
|V ID |
0V
|V ID |
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
4. LVDS Receiver Clock SSCG (Spread spectrum clock generator) is defined as below figures
)66
)FONB
)FONBVV PD[
)FON
)FONB
)FONBVV PLQ
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
5. Receiver Data Input Margin
Rating
Parameter Symbol Unit Note
Min Type Max
Input Clock Frequency Fclk Fclk (min) -- Fclk (max) MHz T=1/Fclk
Input Data Position0 tRIP1 -|tRMG| 0 |tRMG| ns
Input Data Position1 tRIP0 T/7-|tRMG| T/7 T/7+|tRMG| ns
Input Data Position2 tRIP6 2T/7-|tRMG| 2T/7 2T/7+|tRMG| ns
Input Data Position3 tRIP5 3T/7-|tRMG| 3T/7 3T/7+|tRMG| ns
Input Data Position4 tRIP4 4T/7-|tRMG| 4T/7 4T/7+|tRMG| ns
Input Data Position5 tRIP3 5T/7-|tRMG| 5T/7 5T/7+|tRMG| ns
Input Data Position6 tRIP2 6T/7-|tRMG| 6T/7 6T/7+|tRMG| ns
W5,3
W5,3
W5,3
W5,3
W5,3
W5,3
W5,3
/9'6 5[
5[ 5[ 5[ 5[ 5[ 5[ 5[ 5[ 5[ 5[ 5[ 5[
,QSXW 'DWD
/9'6 5[
,QSXW &ORFN 9GLII 9
)FON 7
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
3-2 Interface Connections
z LCD connector: 196337-30041-3 (P-TWO, FFC connector)
PIN Symbol Description
1 VDD Power Supply, +12V DC Regulated
2 VDD Power Supply, +12V DC Regulated
3 VDD Power Supply, +12V DC Regulated
4 VDD Power Supply, +12V DC Regulated
5 GND Ground
6 GND Ground
7 GND Ground
8 GND Ground
9 LVDS_SEL Open/High(3.3V) for NS, Low(GND) for JEIDA
10 N.C. AUO Internal Use Only
11 GND Ground
12 CH1_0- LVDS Channel 1, Signal 0-
13 CH1_0+ LVDS Channel 1, Signal 0+
14 GND Ground
15 CH1_1- LVDS Channel 1, Signal 1-
16 CH1_1+ LVDS Channel 1, Signal 1+
17 GND Ground
18 CH1_2- LVDS Channel 1, Signal 2-
19 CH1_2+ LVDS Channel 1, Signal 2+
20 GND Ground
21 CH1_CLK- LVDS Channel 1, Clock -
22 CH1_CLK+ LVDS Channel 1, Clock +
23 GND Ground
24 CH1_3- LVDS Channel 1, Signal 3-
25 CH1_3+ LVDS Channel 1, Signal 3+
26 GND Ground
27 N.C. AUO Internal Use Only
28 N.C. AUO Internal Use Only
29 N.C. AUO Internal Use Only
30 GND Ground
Note: N.C. : please leave this pin unoccupied. It can not be connected by any signal
(Low/GND/High).
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
T315XW04 V3 Product Specification
Rev. 0.0
