Image preview - the first page of the document
Panel_AUO_T460HW08_V0_1_[DS]


>> Download Panel_AUO_T460HW08_V0_1_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center           www.panelook.com



                                                                 T460HW08 V0 Product Specification
                                                                                            Rev. 1




                      Model Name: T460HW08 V0
                                    Issue Date : 2010/12/14

                              ( )Preliminary Specifications
                              ( )Final Specifications




      Copyright AUO Optronics Corp. 2009 All Rights Reserved.            Page 1 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



                                                                 T460HW08 V0 Product Specification
                                                                                            Rev. 1

                                               Contents
            No
                                 CONTENTS

                                 RECORD OF REVISIONS

             1                   GENERAL DESCRIPTION

             2                   ABSOLUTE MAXIMUM RATINGS

             3                   ELECTRICAL SPECIFICATION

                         3-1     ELECTRIACL CHARACTERISTICS

                         3-2     INTERFACE CONNECTIONS

                         3-3     SIGNAL TIMING SPECIFICATION

                         3-4     SIGNAL TIMING WAVEFORM

                         3-5     COLOR INPUT DATA REFERENCE

                         3-6     POWER SEQUENCE

                         3-7     BACKLIGHT SPECIFICATION

             4                   OPTICAL SPECIFICATION

             5                   MECHANICAL CHARACTERISTICS

             6                   RELIABILITY TEST ITEMS

             7                   INTERNATIONAL STANDARD

                         7-1     SAFETY

                         7-2     EMC

             8                   PACKING

                         8-1     DEFINITION OF LABEL

                         8-2     PACKING METHODS

                         8-3     PALLET AND SHIPMENT INFORMATION

             9                   PRECAUTION

                         9-1     MOUNTING PRECAUTIONS

                         9-2     OPERATING PRECAUTIONS

                         9-3     ELECTROSTATIC DISCHARGE CONTROL

                         9-4     PRECAUTIONS FOR STRONG LIGHT EXPOSURE

                         9-5     STORAGE

                         9-6     HANDLING PRECAUTIONS FOR PROTECT FILM




      Copyright AUO Optronics Corp. 2009 All Rights Reserved.            Page 2 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                www.panelook.com



                                                                     T460HW08 V0 Product Specification
                                                                                                Rev. 1

      Record of Revision
         Version     Date       Page                                 Description
            0      2010/12/14            First release
            1       2011/4/7    22, 23   ME Front view & Back view




      Copyright AUO Optronics Corp. 2009 All Rights Reserved.                Page 3 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                    www.panelook.com



                                                                               T460HW08 V0 Product Specification
                                                                                                          Rev. 1

      1. General Description
         This specification applies to the 46 inch Color TFT-LCD Module T460HW08 V0. This LCD module has a TFT
      active matrix type liquid crystal panel 1920 x 1080 pixels, and diagonal size of 46 inch. This module supports 1920
      x 1080 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
      stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot.
         The T460HW08 V0 has been designed to apply the 8-bit 2 channel LVDS interface method. It is intended to
      support displays where high brightness, wide viewing angle, high color saturation, and high color depth are very
      important.




      * General Information


                       Items                                Specification                     Unit               Note
      Active Screen Size                                          46                          inch
      Display Area                                     1018.08(H) x 572.67(V)                  mm
      Outline Dimension                            1083.0(H) x 627.0(V) x 59.0(D)              mm       With Inverter
      Driver Element                                   a-Si TFT active matrix
      Display Colors                                         8 bit, 16.7M                    Colors
      Number of Pixels                                      1920 x 1080                       Pixel
      Pixel Pitch                                              0.53025                         mm
      Pixel Arrangement                                  RGB vertical stripe
      Display Operation Mode                               Normally Black
      Surface Treatment                                     Anti-Glare, 3H                              Haze=2%
      Rotate Function                                        Achievable                                 Note 1
      Note 1: Rotate Function refers to LCD display could be able to rotate.




      Copyright AUO Optronics Corp. 2009 All Rights Reserved.                          Page 4 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                    www.panelook.com



                                                                             T460HW08 V0 Product Specification
                                                                                                        Rev. 1

      Absolute Maximum Ratings
            The followings are maximum values which, if exceeded, may cause faulty operation or damage to the unit


                        Item                 Symbol           Min            Max       Unit           Conditions
       Logic/LCD Drive Voltage                 Vcc            -0.3            14       [Volt]           Note 1
       Input Voltage of Signal                 Vin            -0.3            4        [Volt]           Note 1
       BLU Input Voltage                      VDDB            -0.3           28         VDC             Note 1
       BLU on/off Control Voltage             VBLON           -0.3            7         VDC             Note 1
       BLU Brightness Control Voltage         Vdim            -0.3            7         VDC             Note 1
                                                                                        o
       Operating Temperature                   TOP             0             +50        [ C]            Note 2
       Operating Humidity                     HOP              10            90       [%RH]             Note 2
                                                                                        o
       Storage Temperature                     TST            -20            +60        [ C]            Note 2
       Storage Humidity                        HST             10            90       [%RH]             Note 2
                                                                                        o
       Panel Surface Temperature               PST              -            65         [ C]            Note 3

      Note 1: Duration:50 msec.
      Note 2 : Maximum Wet-Bulb should be 39         and No condensation.
      The relative humidity must not exceed 90% non-condensing at temperatures of 40            or less. At temperatures
      greater than 40    , the wet bulb temperature must not exceed 39   .
      Note 3: Surface temperature is measured at 50      Dry condition




      Copyright AUO Optronics Corp. 2009 All Rights Reserved.                      Page 5 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                   www.panelook.com



                                                                                 T460HW08 V0 Product Specification
                                                                                                            Rev. 1

      3. Electrical Specification
      The T460HW08 V0 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT
      array and liquid crystal. The second input for BLU is to power inverter.


      3.1 Electrical Characteristics
          3.1.1: DC Characteristics
                                                                                         Value
                             Parameter                          Symbol                                  Unit    Note
                                                                             Min.        Typ.    Max
       LCD
       Power Supply Input Voltage                                 VDD        10.8        12      13.2   VDC
       Power Supply Input Current                                 IDD            --       1       1.2    A       1
       Power Consumption                                           PC            --      12      14.4   Watt
       Inrush Current                                            IRUSH           --       --       4     A       2

                   Input Differential Voltage                     VID        200         400      600   mVDC     3

       LVDS        Differential Input High Threshold Voltage      VTH       +100          --     +300   mVDC     3
       Interface
                   Differential Input Low Threshold Voltage       VTL        -300         --     -100   mVDC     3

                   Input Common Mode Voltage                      VICM       1.1         1.25     1.4   VDC      3
                                                                   VIH
       CMOS        Input High Threshold Voltage                              2.7          --      3.3   VDC      4
                                                                 (High)
       Interface                                                   VIL
                   Input Low Threshold Voltage                                   0        --      0.6   VDC      4
                                                                 (Low)
       Backlight Power Consumption                                PBL        114         120      126   Watt
       Life Time                                                            50,000                 --   Hours   9,10


             3.1.2: AC Characteristics
                                                                                         Value
                             Parameter                          Symbol                                  Unit    Note
                                                                             Min.        Typ.    Max

                   Input Channel Pair Skew Margin              tSKEW (CP)    -500         --     +500    ps      5

                   Receiver Clock : Spread Spectrum                          Fclk                Fclk
                                                                Fclk_ss                   --            MHz      6
                   Modulation range                                          -3%                 +3%
       LVDS
       Interface   Receiver Clock : Spread Spectrum
                                                                  Fss            30       --      200   KHz      6
                   Modulation frequency
                   Receiver Data Input Margin
                           Fclk = 85 MHz                         tRMG        -0.4         --      0.4    ns      7
                           Fclk = 65 MHz                                     -0.5         --      0.5


      Note:
      1. VDD = 12.0V, Fv = 60Hz, Fclk= 82MHz , 25       , Test Pattern : White Pattern
      2. Measurement condition : Rising time = 400us

      Copyright AUO Optronics Corp. 2009 All Rights Reserved.                            Page 6 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                www.panelook.com



                                                                             T460HW08 V0 Product Specification
                                                                                                        Rev. 1
                                                                             9''




                                    *1'

                                                             s

      3. VICM = 1.25V

                  LVDS -
                        V IC M                                                              V TH
                                                                                                 |V ID |
                                                                                            V TL
                 LVDS +



                        GND




                                                   |V ID |

                         0V

                                                                   |V ID |



      4. The measure points of VIH and VIL are in LCM side after connecting the System Board and LCM.
      5. Input Channel Pair Skew Margin




                Note: x = 0, 1, 2, 3, 4
      6. LVDS Receiver Clock SSCG (Spread spectrum clock generator) is defined as below figures


                                                                    )66
                                 )FONB
                                 )FONBVV PD[


                                     )FON


                                 )FONB
                                 )FONBVV PLQ


      Copyright AUO Optronics Corp. 2009 All Rights Reserved.                      Page 7 / 30

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                         www.panelook.com



                                                                                       T460HW08 V0 Product Specification
                                                                                                                  Rev. 1
      7. Receiver Data Input Margin
                                                                              Rating
                  Parameter                 Symbol                                                                Unit      Note
                                                                Min           Type                Max
         Input Clock Frequency               Fclk           Fclk (min)            --            Fclk (max)        MHz    T=1/Fclk
         Input Data Position0                tRIP1           -|tRMG|              0              |tRMG|           ns
         Input Data Position1                tRIP0         T/7-|tRMG|         T/7            T/7+|tRMG|           ns
         Input Data Position2                tRIP6         2T/7-|tRMG|        2T/7           2T/7+|tRMG|          ns
         Input Data Position3                tRIP5         3T/7-|tRMG|        3T/7           3T/7+|tRMG|          ns
         Input Data Position4                tRIP4         4T/7-|tRMG|        4T/7           4T/7+|tRMG|          ns
         Input Data Position5                tRIP3         5T/7-|tRMG|        5T/7           5T/7+|tRMG|          ns
         Input Data Position6                tRIP2         6T/7-|tRMG|        6T/7           6T/7+|tRMG|          ns




                                     W5,3
                                     W5,3
                                     W5,3
                                     W5,3
                                     W5,3
                                     W5,3
                                 W5,3
         /9'6 5[
                                5[      5[      5[         5[     5[     5[        5[      5[       5[       5[     5[    5[
         ,QSXW 'DWD
         /9'6 5[
         ,QSXW &ORFN                           9GLII   9


                                                                         )FON 7



      8. Do not attach a conducting tape to lamp connecting wire. If the lamp wire attach to conducting tape, TFT-LCD
          Module have a low luminance and the inverter has abnormal action because leakage current occurs between
          lamp wire and conducting tape
      9. The relative humidity must not exceed 80% non-condensing at temperatures of 40                      or less. At temperatures
          greater than 40   , the wet bulb temperature must not exceed 39                . When operate at low temperatures, the
          brightness of CCFL will drop and the life time of CCFL will be reduced
      10. Specified values are for a single lamp only which is aligned horizontally. The lifetime is defined as the time
          which luminance of the lamp is 50% compared to its original value. [Operating condition: Continuous operating
          at Ta = 25
