Image preview - the first page of the document
![Panel_AU_Optronics_B141PN01_0_[DS]](/pics/5c8eb8e9d2c38.gif)
>> Download Panel_AU_Optronics_B141PN01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
U N I PA C O P T O E L E C T R O N I C S C O R P O R AT I O N
Spec. No. 413-212-103P
Version : 0.5
Total pages : 18
Date : 2001.08.09
Unipac 14.1 COLOR TFT-LCD MODULE
PRELIMINARY SPECIFICATION
MODEL NAME: B141PN01 (UB141P03)
The content of this technical information
is subject to change without notice.
Please contact Unipac or its agent for
further information.
Approved by Checked by Prepared by
Unipac copyright 2001
All rights reserved,
Copying forbidden.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Record of Revision
Version Revise Date Page Content
0.1 22/Mar./2001 First draft.
0.2 19/April./2001 9 d. Display position subtract 1 from X item
17 X item of even and odd data bus
0.3 28/May/2001 2 Change Weight => (480g) (460g)
6 Change Current consumption =>IB = 600(Max.) (840)(Max.)
10 Change Lamp voltage =>VL = 900(Typ.) 650(Typ.)
Change Power consumption =>PL = 5.4(Typ.) 3.9(Typ.)
0.4 15/Jun./2001 17 Update Fig.2 Timing chart => EVEN and ODD data bus
0.5 10/Aug./2001 2 Change weight => (460g) 455g
6 Change Current consumption =>IA = 540(Typ.) 440 (Typ.)
6 Change Current consumption =>IB = 840(Max.) 660(Max.)
Change CN1 type => DF-19K--20P-1H(Hirose),20-pin
FI-XB30S-HF10 (JAE), 30-pin
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 1 /17
Contents:
A. Physical specification P2
B. Electrical specifications P3
1. Pin assignment P3
2. Absolute maximum ratings P5
3. Electrical characteristics P6
a. Typical operating conditions P6
b. Display color v.s. input data signals P7
c. Input signal timing P8
d. Display position P9
e. Backlight unit P10
C. Optical specifications P11
D. Reliability test items P13
E. Display quality P13
F. Handling precaution P13
G. Packing form P14
Appendix:
Fig.1-(a) LCM outline dimensions(Front side) P15
Fig.1-(b) LCM outline dimensions (Back side) P16
Fig.2 Timing chart P17
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 2 /17
A. Physical specifications
NO. Item Specification Remark
1 Display resolution(pixel) 1400(H) 1050(V) SXGA+
2 Active area(mm) 285.6(H) 214.2(V)
3 Screen size(inch) 14.1(Diagonal)
4 Pixel pitch(mm) 0.204(H) 0.204(V)
5 Color configuration R. G. B. Vertical stripe
6 Overall dimension(mm) 298.5 226.7 5.2 [W H D] Note 1
7 Weight(g) 455g
8 Surface treatment Hard coating(3H), anti-glare of the front
polarizer(Haze25%)
Note 1: Refer to Fig. 1. on page 15,16.
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 3 /17
B. Electrical specifications
1.Pin assignment
(1).Input signal interface
CN1 (30P) connector : FI-XB30S-HF10 (JAE)
Matching connector : FI-X30H (wire Type)
FI-X30M (FPC Type)
Pin no Symbol Function Etc.
1 VCC +3.3 V power supply
2 VCC +3.3 V power supply
3 GND Ground
4 GND Ground
5 ReIN0-
LVDS receiver signal channel 0 (EVEN)
6 ReIN0+
7 ReIN1-
LVDS receiver signal channel 1 (EVEN)
8 ReIN1+
9 ReIN2-
LVDS receiver signal channel 2 (EVEN)
10 ReIN2+
11 ReCLKIN-
LVDS receiver signal clock (EVEN)
12 ReCLKIN+
13 RoIN0-
LVDS receiver signal channel 0 (ODD)
14 RoIN0+
15 RoIN1-
LVDS receiver signal channel 1 (ODD)
16 RoIN1+
17 RoIN2-
LVDS receiver signal channel 2 (ODD)
18 RoIN2+
19 RoCLKIN-
LVDS receiver signal clock 3 (ODD)
20 RoCLKIN+
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 4 /17
(2) LVDS transmitter/receiver signal mapping(EVEN)
Symbol Function
TxIN0 EVEN R0 EVEN Red data (LSB)
TxIN1 EVEN R1 EVEN Red data
TxIN2 EVEN R2 EVEN Red data
6 bit even red display data
TxIN3 EVEN R3 EVEN Red data
TxIN4 EVEN R4 EVEN Red data
TxIN5 EVEN R5 EVEN Red data (MSB)
TxIN6 EVEN G0 EVEN Green data (LSB)
TxIN7 EVEN G1 EVEN Green data
TxIN8 EVEN G2 EVEN Green data
6 bit even green display data
TxIN9 EVEN G3 EVEN Green data
TxIN10 EVEN G4 EVEN Green data
TxIN11 EVEN G5 EVEN Green data (MSB)
TxIN12 EVEN B0 EVEN Blue data (LSB)
TxIN13 EVEN B1 EVEN Blue data
TxIN14 EVEN B2 EVEN Blue data
6 bit even blue display data
TxIN15 EVEN B3 EVEN Blue data
TxIN16 EVEN B4 EVEN Blue data
TxIN17 EVEN B5 EVEN Blue data (MSB)
TxIN18 Hs EVEN Horizontal sync
TxIN19 Vs Vertical sync
TxIN20 DE Data enable
TxCLKIN EVEN CLK EVEN Clock even Dot clock
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 5 /17
(3) LVDS transmitter/receiver signal mapping(ODD)
Symbol Function
TxIN0 ODD R0 ODD Red data (LSB)
TxIN1 ODD R1 ODD Red data
TxIN2 ODD R2 ODD Red data
6 bit odd red display data
TxIN3 ODD R3 ODD Red data
TxIN4 ODD R4 ODD Red data
TxIN5 ODD R5 ODD Red data (MSB)
TxIN6 ODD G0 ODD Green data (LSB)
TxIN7 ODD G1 ODD Green data
TxIN8 ODD G2 ODD Green data
6 bit odd green display data
TxIN9 ODD G3 ODD Green data
TxIN10 ODD G4 ODD Green data
TxIN11 ODD G5 ODD Green data (MSB)
TxIN12 ODD B0 ODD Blue data (LSB)
TxIN13 ODD B1 ODD Blue data
TxIN14 ODD B2 ODD Blue data
6 bit odd blue display data
TxIN15 ODD B3 ODD Blue data
TxIN16 ODD B4 ODD Blue data
TxIN17 ODD B5 ODD Blue data (MSB)
TxIN18 NC NONE
TxIN19 NC NONE
TxIN20 NC NONE
TxCLKIN ODD CLK ODD Clock odd Dot clock
2. Absolute maximum ratings (GND = 0 V)
Values Unit
Parameter Symbol Remark
Min. Max.
Power voltage VCC -0.3 4 VDC At 25
Input signal voltage VLH -0.3 VCC+0.3 VDC At 25
Operating temperature Top 0 +50 Note 1
Storage temperature TST -20 +60 Note 1
Note 1:The relative humidity must not exceed 90% non-condensing at temperatures of 40 or
less. At temperatures greater than 40 , the wet bulb temperature must not exceed 39
. When operate at low temperatures, the brightness of CCFL will drop and the lifetime
of CCFL will be reduced.
Note 2:The unit should not be exposed to corrosive chemicals.
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 6 /17
3. Electrical characteristics
a. Typical operating conditions
Item Symbol Min. Typ. Max. Unit Remark
Input voltage VCC 3.0 3.3 3.6 V
Power
supply Current IA - 440 - mArms
Note 1
voltage consumption IB - - 660 mArms
Inrush current I RUSH - - 2200 mApeak Note 2
Internal Low voltage VIL 0 - 0.3 VCC
logic
High voltage VIH 0.7VCC - VCC
Power ripple voltage VRP - - 100 mVp-p
Note 1:Effective value (mArms) at VCC = 3.3 V/25 .
IA IB Black
(0)
64
Gray
(7)
64
White Black Vertical stripe line
64 Grayscale
Note 2: Refer to the following power-on condition.
90%
Vcc
10%
Ton=470 s
Sequence of Power-on/off and signal-on/off
T3 T4 0 T1 70msec
Power 0 T2 70msec
T1 T2
300msec T3
T5
100msec T4
T5 10msec
Input signal
Apply the lamp voltage within the LCD operating range. When the backlight turns on before
the LCD operation or the LCD turns off before the backlight turns off, the display may
momentarily become abnormal.
The above on/off sequence should be applied to avoid abnormal function in the display.
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 7 /17
Caution
The above on/off sequence should be applied to avoid abnormal function in the display.
In case of handling:
Make sure to turn off the power when you plug the cable into the input connector or pull the
cable out of the connector.
b. Display color v.s. input data signals (applied to ODD & EVEN)
Data signal (0 : Low level, 1: High level)
Display colors
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Blue 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Red 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Magenta 1 1 1 1 1 1 0 0 0 0 0 0 1 1 1 1 1 1
Basic
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
colors
Cyan 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0
Dark 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0
Red
grayscale
bright
1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0
1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0
Red 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0
Dark 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0
Green
grayscale
bright
0 0 0 0 0 0 1 1 1 1 0 1 0 0 0 0 0 0
0 0 0 0 0 0 1 1 1 1 1 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0
Blue
grayscale
bright
0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 0 1
0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 0
Blue 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Note : Each basic color can be displayed in 64 gray scales using the 6 bit data signals. By
combining the 18-bit data signals(R,G,B), the 262,144 colors can be achieved on the
display.
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 8 /17
c. Input signal timing
Timing diagrams of input signal are shown in Fig 2.
(1). Timing characteristics of Input signals ( DE Mode )
Item Symbol Min. Typ. Max. Unit Remark
Frequency Fck 51 54 57 MHz
CLK
Period Clk 17.5 18.5 19.6 ns
Period Th 820 844 1023 Clk
- - - s
Display Thd 700 Clk
Pulse Thw 10 56 240 Clk
Hs
Horizontal Display start The 32 120 120 Clk
sync Front Thf 0 24 Clk
Back Thb 32 64 120 Clk The-Thw
Blanking Thbl 120 144 323 Clk Th-700
Period Tv 1058 1066 2047 Th
- - - ms
Display Tvd 1050 Th
Vs Pulse Tvw 1 3 120 Th
Vertical Display start Tve 3 15 Th
sync Back Tvb 2 12 Tve-Tvw
Front Tvf 0 1
Blanking Tvbl 8 16 997 Tv-1050
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 9 /17
(2). Timing characteristics of Input signals ( HV Mode )
Item Symbol Min. Typ. Max. Unit Remark
Frequency Fck 51 54 57 MHz
CLK
Period Clk 17.5 18.5 19.6 ns
Period Th 820 844 1023 Clk
- - - s
Display Thd 700 Clk
Pulse Thw 56 56 56 Clk
Hs
Horizontal Display start The 120 120 120 Clk
sync Front Thf 0 24 203 Clk
Back Thb 64 64 64 Clk The-Thw
Blanking Thbl 120 144 323 Clk Th-700
Period Tv 1065 1066 2047 Th
ms
Display Tvd 1050 Th
Vs Pulse Tvw 3 3 3 Th
Vertical Display start Tve 15 15 15 Th
sync Back Tvb 12 12 12 Tve-Tvw
Front Tvf 0 1 962
Blanking Tvbl 15 16 977 Tv-1050
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 10 /17
(3). The timing condition of LVDS
Item Symbol Min. Typ. Max. Unit
The differential level VID 0.1 - 0.6 V
The common mode input voltage VIC VID - VID V
2.4
2 2
The input setup time tsu1 500 - - ps
The input hold time th1 500 - - ps
VID VID = VIAP - VIAM
VIAP VIAM
tsu1 th1
An
7 LCK
d.Display position
EVEN ODD - - - EVEN ODD
D( 0,1 ) D( 1,1 ) ...... D( X,1 ) ...... D(1398,1 ) D(1399,1 )
D( 0,2 ) D( 1,2 ) ...... D( X,2 ) ...... D(1398,2 ) D(1399,2 )
.
. .
. .
. .
. .
.
. . ...... . ...... . .
D( 0,Y ) D( 1,Y ) ...... D( X,Y ) ...... D( 1398,Y ) D(1399,Y )
.
. .
. .
. .
. .
.
. . ...... . ...... . .
D( 0,1049 ) D( 1,1049 ) ...... D( X,1049 ) ...... D( 1398,1049) D(1399,1049)
D( 0,1050 ) D( 1,1050 ) ...... D( X,1050 ) ...... D(1398,1050) D(1399,1050)
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 11 /17
e.Backlight unit
The backlight system is an edge-lighting type with a CCFL(Cold Cathode Fluorescent Lamp).
The characteristics of a single lamp are shown in the following tables.
Parameter Symbol Min. Typ. Max. Unit Remark
Lamp voltage VL - 650 - Vrms IL = 6mA.
Lamp current IL 3 6 6.5 mArms Note 1
Power consumption PL - 3.9 - W Note 2
- - 1400 (T=0 )
Lamp starting voltage VS Vrms Note 3
- - 1050 (T=25 )
Frequency FL 50 60 80 KHZ Note 4
Lamp life time LL 10000 - - Hr Note 5
Note 1: Using the inverter of PWM type(keep stable peak value of output voltage during
adjusting lamp current), the minimum lamp current is 3mA.
Note 2: Inverter should be designed with the characteristic of lamp. When you are designing
the inverter, the output voltage of the inverter should comply with the following
conditions.
(1).The area under the positive and negative cycles of the waveform of the lamp
current and lamp voltage should be area symmetric(the symmetric ratio should be
larger than 90%).
(2).There should not have any spikes in the waveform.
(3).The waveform should be sine wave as possible.
(4).Lamp current should not exceed the maximum value within the operating
temperature (It is prohibited to over the maximum lamp current even if operated in
the non-guaranteed temperature). When lamp current over the maximum value for
a long time, it may cause fire. Therefore, it is recommend that the inverter should
have the current limiter circuit.
Note 3: The inverter open voltage should be designed larger than the lamp starting voltage at
T=0oC, otherwise backlight may be blinking for a moment after turning on or not be
able to turn on. The open voltage should be measured after ballast capacitor. If an
inverter has shutdown function it should keep its open voltage for longer than 1
second even if lamp connector is open.
Note 4: Lamp frequency may produce interference with horizontal synchronous frequency and
this may cause line flow on the display. Therefore lamp frequency shall be detached
from the horizontal synchronous frequency and its harmonics as far as possible in
order to avoid interference. In case using the inverter by PWM control, PWM
frequency may interference with frame frequency. We suggest that PWM frequency
is same as frame frequency.
Note 5: T= 25 , IL = 6mA. Brightness to be decrease to the 50% of the initial value.
Note 6: CN2 connector (backlight): BHSR-02VS-1(JST).
Mating connector: SM02B-BHSS-1-TB (JST).
Pin no. Symbol Function Remark
1 H CCFL power supply(H.V.) Cable color: Pink
2 L CCFL power supply(GND) Cable color: White
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 12 /17
C. Optical specifications ( Note 1, Note 2 )
Specification
Item Symbol Condition Unit Remark
Min. Typ. Max.
Response time
Rising time Tr =0 - 20 40 ms Note 4
Falling time Tf - 30 50
Contrast ratio CR =0 150 250 - Note 3,5
Viewing angle
Top 10 - -
Bottom CR 10 30 - - deg. Note 3,8
Left 40 - -
Right 40 - -
- Note
Brightness 5 points YL =0 (120) 150
- 3,6,7,9
Wx - 0.310 -
Color chromaticity(CIE) =0
Wy - 0.330 -
Rx - TBD -
Ry - TBD -
Note 3
Gx - TBD -
Gy - TBD -
Bx - TBD -
By - TBD -
White uniformity W - - 1.8 Note 3,9
Note 1: Ambient temperature = 25 .
Note 2: To be measured in dark room after lighting the backlight for 30 minutes.
Note 3: To be measured with a viewing cone of 1 by Topcon luminance meter BM-5A.
Note 4: Definition of response time:
The output signals of BM-7 are measured when the input signals are changed from
"Black" to "White" (falling time) and from "White" to "Black" (rising time), respectively. The
response time interval between the 10% and 90% of amplitudes. Refer to figure as below.
"Black"
"White" "White"
100%
Signal(Relative value)
90%
10%
0%
Tr Tf
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 13 /17
Note 5. Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 6: Definition of brightness:
YLD +YLE +YLG +YLI +YLJ
Brightness( YL)=
5
Note 7: Driving conditions for CCFL : IL= 6.0 mA ,60 KHZ frequency
Note 8: Definition of viewing angle.
Note 9: Definition of white uniformity:
White uniformity is defined as the following with thirteen measurements (A~M).
256 512 768 10mm
10mm
10mm 10mm
A B C
192
D E
384
F G H
576
I J
10mm K L M
Maximum Brightness of thirteen points
W =
Minimum Brightness of thirteen points
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 14 /17
D. Reliability test items(Note 1)
Test tem Test Condition judgement Remark
High temperature storage 60 , 240Hrs Display quality Note 1, 2
Low temperature storage -20 , 240Hrs Display quality Note 1, 2
High temperature & high 40 , 90%RH, 240Hrs Display quality Note 1, 2
humidity operation (No condensation)
High temperature operation 50 , 240Hrs Display quality Note 1, 2
Low temperature operation 0 , 240Hrs Display quality Note 1, 2
Temperature cycling -20 ~60 Display quality Note 1, 2
(non-operation) 1H, 10mins, 1H, 8cycles
Interface connector ESD test 200 PF, 0 ,200V,CN1 Display function Note 3
Contact discharge 100 PF, 1.5K , 8KV, 1second, 9 Display function Note 3
points on the panel, 10 times each place
Vibration Sweep:1.5G,10HZ ~ 300HZ ~ Display quality Note 1, 2
(non-operation) 10HZ/10min
; 30min for each direction X, Y, Z
Mechanical shock 240G, 2ms, X, Y, Z Display quality Note 1, 2
(non-operation) once for each direction
Note 1: Evaluation should be tested after storage at room temperature for one hour.
Note 2: There should be no change which might affect the practical display function when the
display quality test is conducted under normal operating condition.
Note 3: The discharging points are shown as below.
E. Display quality
The display quality of the color TFT-LCD module should be in compliance with the
unipac's Incoming inspection standard.
F. Handling precaution
The Handling of the TFT-LCD should be in compliance with the Unipac's handling principle
standard.
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 15 /17
G. Packing form
LCD Module
Note 1.
Separate Pad
Anti-Static Bag
Note :
1.The panel of each LCD Module faces toward
seperation pad.
2.Max. capacity : 20 LCD Modules/Carton.
3.Max. weight : 12.3kg/Carton.
4.Meas. : 458mm*412mm*365mm.
2
Cushion
Carton
1
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 16 /17
Fig.1-(a) LCM outline dimensions (Front side)
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 17 /17
Fig.1-(b) LCM outline dimensions (Back side)
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Spec. No. : 413-212-103P
Version : 0.5
Page : 18 /17
(1 pixel / clock)
invalid
invalid
Thf
Invalid
Tvf
1396,Y 1398,Y
1397,Y 1399,Y
X,1050
X,1049
Tvd
Thd
Fig.2 Timing chart
Tv
X,3
Th
X,2
Th
X,1
4,Y
5,Y
3,Y
2,Y
1,Y
0,Y
Thb
Tve
The
Tvbl
Tvw
Thw
invalid
Invalid
Thbl
invalid
Tvf
Thf
1399,Y
1398,Y
X,768
X,767
R0~R5
G0~G5
G0~G5
EVEN R0~R5
B0~B5
B0~B5
RGB
CLK
DE
DE
ODD
Vs
Hs
Hs
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS PRPER SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM UNIPAC OPTOELECTRONICS CORP.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
