Image preview - the first page of the document
![Panel_CMO_M141X101_1_[DS]](/pics/5c8ec56577357.gif)
>> Download Panel_CMO_M141X101_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14003173
Issue Date: MAR.16,2000
Model: M141X101
APPROVAL
TFT-LCD Specification
Model No: M141X101
Customer : AMTRAN TECHNOLOGY CO.,LTD.
Approved by :
Note :
Liquid Crystal Division
QRA Dept. RD Dept. System Dept.
Approval Approval Approval
1/22
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14003173
Issue Date: MAR.16,2000
Model: M141X101
APPROVAL
CONTENTS
REVISION HISTORY
GENERAL DESCRIPTION
1. ABSOLUTE MAXIMUM RATINGS
2. ELECTRICAL SPECIFICATIONS
3. INTERFACE SPECIFICATIONS
3.1 THE PIN ASSIGNMENT OF TTL INTERFACE CONNECTOR
3.2 INPUT SIGNAL TIMING SPECIFICATIONS
3.3 COLOR DATA INPUT ASSIGNMENT
3.4 POWER UP/DOWN SEQUENCE
4. OPTICAL SPECIFICATIONS
5. Reliability Test Item
6. MECHNICAL DRAWINGS
7. PRECAUTION
7.1 ASSEMBLY AND HANDLING PRECAUTION
7.2 SAFTY PRECAUTION
8. PACKAGING
8.1 PACKING SPECIFICATIONS
8.2 PACKING METHOD
9. INCOMING INSPECTION DAY
2/22
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14003173
Issue Date: MAR.16,2000
Model: M141X101
APPROVAL
REVISION HISTORY
VERSION Date DESCPIPTION
Ver 1.0 Sep.10'99 Issue Preliminary Specification.
Ver 2.0 Nov.11'99 Page 5/22
- To revise the MECHANICAL SPECIFICATIONS
Page 6/22
- To Change the ABSOLUTE MAXIMUM RATINGS of Humidity
- To add Notes statement in ELECTRICAL SPECIFICATIONS
Page 10/22
- 3.2 INPUT SIGNAL TIMING SPECIFICATIONS is modified and
added the values which is TBD in version 1.0.
Page 11/22
- To revise the Tvdb interval in INPUT SIGNAL TIMING
DIAGRAM.
Page 13/22
- The illustration of POWER UP/DOWN SEQUENCE is modify.
Page 14/22 ~ 17/22
- To revise the OPTICAL SPECIFICATIONS and modify the
Illustration of Notes.
Page 19/22
- Add the PRECAUTION statement.
Page 20/22~22/22
- Add the illustration of PACKAGING method
Ver 2.1 Jan.31'00 Issue Approval Specification.
Page 5/22
- Add BLOCK DIAGRAM
- Add " Gap, panel surface with metal frame" spec. in
MECHANICAL SPECIFICATIONS.
Page 6/22
- Change the humidity condition in ABSOLUTE MAXIMUM
RATINGS.
Old ->Operation : 20% ~ 90% relative humidity
Non operation : 5% ~ 85% relative humidity
New ->Operation : 20% ~ 95% relative humidity, Ta40◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
