Image preview - the first page of the document
>> Download Panel_CMO_V290BJ1-L01_1_[DS] documenatation <<Text preview - extract from the document Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
d ^
W ^
^
DK> EK s :
^h&&/y >
WWZKs z ^/'E dhZ
E d
E
W
W
s t
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
CONTENTS
REVISION HISTORY................................................................................................................................................................4
1. GENERAL DESCRIPTION...................................................................................................................................................5
1.1 OVERVIEW..................................................................................................................................................................5
1.2 FEATURES...................................................................................................................................................................5
1.3 APPLICATION............................................................................................................................................................5
1.4 GENERAL SPECIFICATIONS....................................................................................................................................5
1.5 MECHANICAL SPECIFICATIONS ...........................................................................................................................7
2. ABSOLUTE MAXIMUM RATINGS ....................................................................................................................................8
2.1 ABSOLUTE RATINGS OF ENVIRONMENT............................................................................................................8
2.2 PACKAGE STORAGE.................................................................................................................................................9
2.3 ELECTRICAL ABSOLUTE RATINGS........................................................................................................................9
2.3.1 TFT LCD MODULE...............................................................................................................................9
3. ELECTRICAL CHARACTERISTICS ................................................................................................................................. 10
3.1 TFT LCD MODULE................................................................................................................................................... 10
3.2 BACKLIGHT UNIT................................................................................................................................................... 13
3.2.1 LAMP SPECIFICATION......................................................................................................................13
4. BLOCK DIAGRAM OF INTERFACE ................................................................................................................................ 14
4.1 TFT LCD MODULE................................................................................................................................................... 14
5. INPUT TERMINAL PIN ASSIGNMENT .......................................................................................................................... 15
5.1 TFT LCD Module Input ............................................................................................................................................ 15
5.2 BACKLIGHT UNIT................................................................................................................................................... 17
5.3 LVDS INTERFACE.................................................................................................................................................... 18
5.4 COLOR DATA INPUT ASSIGNMENT ................................................................................................................... 19
6. INTERFACE TIMING......................................................................................................................................................... 20
6.1 INPUT SIGNAL TIMING SPECIFICATIONS ......................................................................................................... 20
6.2 POWER ON/OFF SEQUENCE ................................................................................................................................ 23
7. OPTICAL CHARACTERISTICS ........................................................................................................................................ 24
7.1 TEST CONDITIONS.................................................................................................................................................. 24
7.2 OPTICAL SPECIFICATIONS ................................................................................................................................... 25
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
8. PRECAUTIONS .................................................................................................................................................................. 29
8.1 ASSEMBLY AND HANDLING PRECAUTIONS ................................................................................................... 29
8.2 SAFETY PRECAUTIONS.......................................................................................................................................... 29
9. DEFINITION OF LABELS.................................................................................................................................................. 30
9.1 MODULE LABEL ...................................................................................................................................................... 30
9.2 CARTON LABEL....................................................................................................................................................... 31
10. PACKAGING .................................................................................................................................................................... 32
10.1 PACKAGING SPECIFICATIONS .......................................................................................................................... 32
10.2 PACKAGING METHOD ........................................................................................................................................ 32
11. MECHANICAL CHARACTERISTIC .............................................................................................................................. 34
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
REVISION HISTORY
Version Date Page(New) Section Description
Ver. 2.0 May.15, 2012 All All The approval specification was first issued.
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V290BJ1-L01 is a 29" TFT Liquid Crystal Display module with 3U-CCFL Backlight unit and 1ch-LVDS interface.
This module supports 1366 x 768 HDTV format and can display 16.7M colors (8-bit).
1.2 FEATURES
High brightness (300 nits)
High contrast ratio (2500:1)
Fast response time (Gray to gray average 8.5 ms)
High color saturation (NTSC 72%)
HDTV (1366 x 768 pixels) resolution
DE (Data Enable) only mode
LVDS (Low Voltage Differential Signaling) interface
Optimized response time for 50/60 Hz frame rate
Ultra wide viewing angle : Super MVA technology
RoHS compliance
1.3 APPLICATION
Standard Living Room TVs.
Public Display Application.
Home Theater Application.
MFM Application.
1.4 GENERAL SPECIFICATIONS
Item Specification Unit Note
Active Area 631.092 (H) x 354.816 (V) (29" diagonal) mm
(1)
Bezel Opening Area 635 (H) x 358.8 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch(Sub Pixel) 0.154 (H) x 0.462 (V) mm -
Pixel Arrangement RGB Vertical Stripe - -
Display Colors 16.7M color -
Display Operation Mode Transmissive mode / Normally black - -
Surface Treatment Anti-Glare coating (Haze 3.5%) - (2)
Rotation Function Unachievable
(3)
Display Orientation Signal input with "CMI" (3)
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and back outlines.
Note (2) The spec. of the surface treatment is temporarily for this phase. CMI reserves the rights to change this feature.
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
Note (3)
Back Side Front Side
CMI
X+C Board
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 653.8 654.8 655.8 mm
Module Size Vertical (V) 379.7 380.7 381.7 mm (1), (2)
Depth (D) 44 45 46 mm
Weight 3064
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth is between bezel to rear.
s D
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60
