Image preview - the first page of the document
![Panel_CPT_CLAA215FA01_1_[DS]](/pics/5c8ed9c02cbf1.gif)
>> Download Panel_CPT_CLAA215FA01_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Chunghwa Picture Tubes, Ltd.
Technical Specification
CPT TFT-LCD
CLAA 215FA01
APPROVED BY CHECKED BY PREPARED BY
Prepared by: Design General Division
CHUNGHWA PICTUER TUBES, LTD.
No. 1, Huaying Rd., Sanho Tsun, Lungtan Shiang, Taoyuan, Taiwan, 325, R.O.C.
TEL: +886-3-4805678 FAX: +886-3-4800589
Doc. No: CLAA215FA01-B Issue Date: 2009/01/09
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CHUNGHWA PICTUER TUBES, LTD.
Doc. No
TECHNICAL SPECIFICATION Version
Issue Date
Title CLAA215FA01 Technical Specification
Modification Record List
NO. Issue Date Modification Index
A 2008/08/01 Tentative version for the customer
Confirm the spec of backlight lamp voltage, power consumption, module weight, and
A 2008/10/31
timing characteristics
A 2008/12/26 Confirm the spec of color coordinates
B 2009/01/09 Modify the condition measuring power consumption
T-3010004-008-F CHUNGHWA PICTUER TUBES, LTD. Page: 2042
Datasheet Version.: 01
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CHUNGHWA PICTUER TUBES, LTD.
Doc. No
TECHNICAL SPECIFICATION Version
Issue Date
Title CLAA215FA01 Technical Specification
Table of Content
NO Table of Content Note
1 OVERVIEW P.4
2 ABSOLUTE MAXIMUM RATINGS P.5
3 ELECTRICAL CHARACTERISTICS P.6
4 INTERFACE PIN CONNECTION P.12
5 INTERFACE TIMING P.14
6 BLOCK DIAGRAM P.17
7 MECHANICAL SPECIFICATION P.18
8 OPTICAL CHARACTERISTICS P.20
9 RELIABILITY TEST CONDITIONS P.23
10 DESIGNATION OF LOT MARK P.25
11 PACKING SPECIFICATION P.27
12 HANDLING PRECAUTIONS FOR TFT-LCD MODULE P.29
T-3010004-008-F CHUNGHWA PICTUER TUBES, LTD. Page: 3042
Datasheet Version.: 01
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CHUNGHWA PICTUER TUBES, LTD.
Doc. No
TECHNICAL SPECIFICATION Version
Issue Date
Title CLAA215FA01 Technical Specification
1. OVERVIEW
CLAA215FA01 is 21.5" color TFT-LCD (Thin Film Transistor Liquid Crystal Display) module composed
of LCD panel, driver ICs, control circuit and backlight. By applying 6 bit digital data, 1920◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
