Image preview - the first page of the document
![Panel_HITACHI_TFTMD80120CBB_0_[DS]](/pics/5c8edc3a642a9.gif)
>> Download Panel_HITACHI_TFTMD80120CBB_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Hitachi Displays, Ltd.
DATE : Nov. 10, 2003
Technical Sheets of 32 cm diagonal WXGA Super-TFT Module
Product Name : TFTMD80120CBB
CONTENTS
No. Item Sheet No. Page
- COVER 3284STD-2188-1 1-1/1
- RECORD OF REVISION 2-1/1
- DESCRIPTION 3284STD-2188-1 3-1/1
1 ABSOLUTE MAXIMUM RATINGS 3284STD-2188-1 4-1/1
2 OPTICAL CHARACTERISTICS 3284STD-2188-1 5-1/2 - 2/2
3 ELECTRICAL CHARACTERISTICS 3284STD-2188-1 6-1/1
4 BLOCK DIAGRAM 3284STD-2188-1 7-1/1
5 INTERFACE PIN CONNECTION 3284STD-2188-1 8-1/6 - 6/6
6 INTERFACE TIMING 3284STD-2188-1 9-1/3-3/3
7 DIMENSIONAL OUTLINE 3284STD-2188-1 10 -1/2-2/2
8 DESIGNATION OF LOTMARK 3284STD-2188-1 11-1/1
9 PRECAUTION 3284STD-2188-1 12-1/3-3/3
The information described in this technical specification is tentative and it is possible to be changed without prior notice.
Sheet
Hitachi Displays, Ltd. No.
3284STD-2188-1 Page 1-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
RECORD OF REVISION
The upper section : Before revision
Date The lower section : After revision Summary
Sheet No. Page
Sheet
Hitachi Displays, Ltd. Date Nov.10,2003 3284STD-2188-1 Page 2-1/1
No.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
DESCRIPTION
The following specifications are applied to the following Super-TFT module.
Note : Inverter for back light unit is not built in this module.
Product Name : TFTMD80120CBB
General Specifications
Effective Display Area : (H)687.36x (V)412.42 (mm)
Number of Pixels : (H)1,280x(V)768 (pixels)
Pixel Pitch : (H)0.537x(V)0.537 (mm)
Color Pixel Arrangement : R+G+B Vertical Stripe
Display Mode : Transmissive Mode
Normally Black Mode
Top Polarizer Type : Anti-Glare
Number of Colors : 16,777,216 (colors)
Viewing Angle Range : Super Wide Version
(Horizontal & Vertical : 170◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
