Image preview - the first page of the document

>> Download Panel_HITACHI_TX43D50VM0BAA_0_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

FOR MESSRS: DATE : May 31st ,2012

CUSTOMER'S ACCEPTANCE SPECIFICATIONS

TX43D50VM0BAA

Contents
No. ITEM SHEET No. PAGE
1 COVER 7B64PS 2701-TX43D50VM0BAA-1 1-1/1
2 RECORD OF REVISION 7B64PS 2702-TX43D50VM0BAA-1 2-1/1
3 GENERAL DATA 7B64PS 2703-TX43D50VM0BAA-1 3-1/2~2/2
4 ABSOLUTE MAXIMUM RATINGS 7B64PS 2704-TX43D50VM0BAA-1 4-1/1
5 ELECTRICAL CHARACTERISTICS 7B64PS 2705-TX43D50VM0BAA-1 5-1/2~2/2
6 OPTICAL CHARACTERISTICS 7B64PS 2706-TX43D50VM0BAA-1 6-1/2~2/2
7 BLOCK DIAGRAM 7B64PS 2707-TX43D50VM0BAA-1 7-1/1
8 INTERFACE PIN ASSIGNMENT 7B64PS 2708-TX43D50VM0BAA-1 8-1/5~5/5
9 TIMING CHART 7B64PS 2709-TX43D50VM0BAA-1 9-1/4~4/4
10 OUTLINE DIMENSIONS 7B64PS 2710-TX43D50VM0BAA-1 10-1/2~2/2
11 APPEARANCE STANDARD 7B64PS 2711-TX43D50VM0BAA-1 11-1/3~3/3
12 PRECAUTIONS 7B64PS 2712-TX43D50VM0BAA-1 12-1/1~2/2
13 DESIGNATION OF LOT MARK 7B64PS 2713-TX43D50VM0BAA-1 13-1/1

ACCEPTED BY: PROPOSED BY:

SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. NO. 7B64PS 2701-TX43D50VM0BAA-1 PAGE 1-1/1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

2. RECORD OF REVISION
DATE SHEET No. SUMMARY

SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. NO. 7B64PS 2702-TX43D50VM0BAA-1 PAGE 2-1/1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

3. GENERAL DATA
3.1 DISPLAY FEATURES
This module is a 17" WXGA amorphous silicon TFT. The pixel format is vertical stripe and sub pixels
are arranged as R (red), G (green), B (blue) sequentially. This display is RoHS compliant, COF (chip on
film) technology and LED backlight are applied on this display.

Part Name TX43D50VM0BAA

Module Dimensions 400.0(W) mm x 258.0(H) mm x 20.0 (D) mm typ.

LCD Active Area 369.6(W) mm x 221.76(H) mm

Pixel Pitch 0.28875(W) mm x 0.28875 (H) mm

Resolution 1280 x 3(RGB)(W) x 768(H) dots

Color Pixel Arrangement R, G, B Vertical stripe

LCD Type Transmissive Color Mode; Normally Black Mode

Display Type Active Matrix

Number of Colors 16.7M Colors

Backlight Edge Light Type with White LED

Weight 1700 typ. (g)

Interface 1-channel LVDS (LVDS:Low Voltage Differential Signaling)

Power Supply Voltage 5V for LCD; 12V for Backlight

Viewing Direction Super Wide Version (In-Plane Switching)

SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2703-TX48D50VM0BAA-1 PAGE 3-1/2
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

3.2 APPLICATION AND OTHERS
(1) This LCD module was designed and manufactured to be used in an air-conditioned room away from
direct sunlight.
(2) This LCD module cannot be applied to an instrument which requires extremely high reliability and
safety from its functions and precision. These instruments include medical equipment which affects
life- and/or wealth-support apparatus.
(3) Any problems caused by a use with deviation from the conditions mentioned in this specification are
not included in the warranty.
(4) Maintenance
This LCD module and the aforementioned data may be changed without notice. When you demand
maintenance parts, please inquire about the changes in advance.
(5) Repair
We will replace or repair all defective modules if the relevant defect is caused by KOE. However, we
will not take any responsibilities for defective modules after the expiration of warranty period. Also, if
you access the modules for repairs, we will not warrant them either even if it is within the warranty
period.
(6) Items in this specification may be changed for improvement without prior notice. Please consult our
sales division before engineering an instrument with this LCD module.
(7) When a question arises concerning the specification, please contact our sales division.

SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2703-TX48D50VM0BAA-1 PAGE 3-2/2
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

4. ABSOLUTE MAXIMUM RATINGS
Item Symbol Min. Max. Unit Remarks
Supply Voltage VDD 0 6 V -
Input Voltage of Logic VI -0.3 3.4 V Note 1
$
Operating Temperature Top 0 50 C Note 2
$
Storage Temperature Tst -20 60 C Note 2
Backlight Input Voltage VLED - (18) V -

Note 1: It is applied to LVDS signal.
Note 2: Temperature and Humidity should be applied to the center glass surface of TFT module, not
to the system installed with a module. The temperature at the center of rear surface should be
less than 60
