Image preview - the first page of the document
![Panel_HITACHI_TX48D50VM0BAA_0_[DS]](/pics/5c8edc9800502.gif)
>> Download Panel_HITACHI_TX48D50VM0BAA_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
FOR MESSRS: DATE : May 31st ,2012
CUSTOMER'S ACCEPTANCE SPECIFICATIONS
TX48D50VM0BAA
Contents
No. ITEM SHEET No. PAGE
1 COVER 7B64PS 2701-TX48D50VM0BAA-1 1-1/1
2 RECORD OF REVISION 7B64PS 2702-TX48D50VM0BAA-1 2-1/1
3 GENERAL DATA 7B64PS 2703-TX48D50VM0BAA-1 3-1/2~2/2
4 ABSOLUTE MAXIMUM RATINGS 7B64PS 2704-TX48D50VM0BAA-1 4-1/1
5 ELECTRICAL CHARACTERISTICS 7B64PS 2705-TX48D50VM0BAA-1 5-1/1
6 OPTICAL CHARACTERISTICS 7B64PS 2706-TX48D50VM0BAA-1 6-1/2~2/2
7 BLOCK DIAGRAM 7B64PS 2707-TX48D50VM0BAA-1 7-1/1
8 INTERFACE PIN ASSIGNMENT 7B64PS 2708-TX48D50VM0BAA-1 8-1/5~5/5
9 TIMING CHART 7B64PS 2709-TX48D50VM0BAA-1 9-1/4~4/4
10 OUTLINE DIMENSIONS 7B64PS 2710-TX48D50VM0BAA-1 10-1/2~2/2
11 APPEARANCE STANDARD 7B64PS 2711-TX48D50VM0BAA-1 11-1/3~3/3
12 PRECAUTIONS 7B64PS 2712-TX48D50VM0BAA-1 12-1/2~2/2
13 DESIGNATION OF LOT MARK 7B64PS 2713-TX48D50VM0BAA-1 13-1/1
ACCEPTED BY: PROPOSED BY:
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. NO. 7B64PS 2701-TX48D50VM0BAA-1 PAGE 1-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. RECORD OF REVISION
DATE SHEET No. SUMMARY
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. NO. 7B64PS 2702-TX48D50VM0BAA-1 PAGE 2-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3. GENERAL DATA
3.1 DISPLAY FEATURES
This module is a 19" WSXGA amorphous silicon TFT. The pixel format is vertical stripe and sub pixels
are arranged as R (red), G (green), B (blue) sequentially. This display is RoHS compliant, COF (chip on
film) technology and LED backlight are applied on this display.
Part Name TX48D50VM0BAA
Module Dimensions 444.0(W) mm x 300.0(H) mm x 24.0 (D) mm typ.
LCD Active Area 409.5(W) mm x 255.9375(H) mm
Pixel Pitch 0.24375(W) mm x 0.24375 (H) mm
Resolution 1680 x 3(RGB)(W) x 1050(H) dots
Color Pixel Arrangement R, G, B Vertical stripe
LCD Type Transmissive Color TFT; Normally Black
Display Type Active Matrix
Number of Colors 16.7M Colors
Backlight Edge Light Type with White LED
Weight (2000 typ). (g)
Interface 2-Channel LVDS (LVDS:Low Voltage Differential Signaling)
Power Supply Voltage 12V for LCD; 12V for Backlight
Viewing Direction Super Wide Version (In-Plane Switching)
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2703-TX48D50VM0BAA-1 PAGE 3-1/2
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3.2 APPLICATION AND OTHERS
(1) This LCD module was designed and manufactured to be used in an air-conditioned room away from
direct sunlight.
(2) This LCD module cannot be applied to an instrument which requires extremely high reliability and
safety from its functions and precision. These instruments include medical equipment which affects
life- and/or wealth-support apparatus.
(3) Any problems caused by a use with deviation from the conditions mentioned in this specification are
not included in the warranty.
(5) Maintenance
This LCD module and the aforementioned data may be changed without notice. When you demand
maintenance parts, please inquire about the changes in advance.
(5) Repair
We will replace or repair all defective modules if the relevant defect is caused by KOE. However, we
will not take any responsibilities for defective modules after the expiration of warranty period. Also, if
you access the modules for repairs, we will not warrant them either even if it is within the warranty
period.
(6) Items in this specification may be changed for improvement without prior notice. Please consult our
sales division before engineering an instrument with this LCD module.
(7) When a question arises concerning the specification, please contact our sales division.
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. NO. 7B64PS 2703-TX48D50VM0BAA-1 PAGE 3-2/2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4. ABSOLUTE MAXIMUM RATINGS
Item Symbol Min. Max. Unit Remarks
Supply Voltage VDD 0 13.5 V -
Input Voltage of Logic VI -0.3 3.6 V Note 1
$
Operating Temperature Top 0 50 C Note 2
$
Storage Temperature Tst -20 60 C Note 2
Backlight Input Voltage VLED - (15) V -
Note 1: The rating is defined for the signal voltages of the interface such as DCLK, DTMG, and RGB
data bus.
Note 2: The maximum rating is defined as above based on the chamber temperature, which might be
different from ambient temperature after assembling the panel into the application. Moreover,
some temperature-related phenomenon as below needed to be noticed:
- Background color, contrast and response time would be different in temperatures other than
25 $ C .
- Operating under high temperature will shorten LED lifetime.
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2704-TX48D50VM0BAA-1 PAGE 4-1/1
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
5. ELECTRICAL CHARACTERISTICS
5.1 LCD CHARACTERISTICS Ta 25 $ C , VSS 0V
Item Symbol Min. Typ. Max. Unit Remarks
Power Supply Voltage VDD 11.4 12.0 12.6 V -
Input Voltage of Logic VI -0.3 - 3.6 V Note 1
Power Supply Current IDD - 500 800 mA Note 2
Vsync Frequency fv 50 60 60 Hz -
Hsync Frequency fH 52.7 63.2 66 KHz -
CLK Frequency f CLK 51.7 62 69.3 MHz -
Note 1: The rating is defined for the signal voltages of the interface such as DTMG, DCLK and RGB
data bus.
Note 2: An all white check pattern is used when measuring IDD. f v is set to 60 Hz.
Note 3: 1.0A fuse is applied in the module for IDD. For display activation and protection purpose, power
supply is recommended larger than 5.0A to start the display and break fuse once any short
circuit occurred.
5.2 BACKLIGHT CHARACTERISTICS Ta 25 $ C
Item Symbol Min. Typ. Max. Unit Remarks
Input Voltage Vin 10.8 12.0 13.2 V -
Input Current Iin - (1.46) - A -
ON/OFF ON 2.5 - 5.0 V B/L=ON
ON/OFF
Control Voltage OFF 0 - 0.8 V B/L=OFF
Brightness Control Voltage Vbc 1.0 - 3.6 V Note 1,2
PWM dimming signal High 2.9 - 5.0 V Note 3
PWM
Input Voltage Low 0 - 0.8 V -
PWM Frequency PWMf 140 150 160 Hz -
Note 1: As for Vbc, it is recommendable to use more than 1.0V.
If Vbc is set less than 1.0V in which brightness becomes less than 20% to the maximum,
display image may look unstable since relative change of brightness tends to become large
by the slight drift of Vbc.
Note 2: Brightness rises almost linearly by increaseing the Vbc in less than 3.0V.
However, brightness is saturated when Vbc exceeds 3.0V.
Note 3: Brightness is almost proportional to the on-Duty ratio of PWM signal input.
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2705-TX48D50VM0BAA-1 PAGE 5-1/1
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
6. OPTICAL CHARACTERISTICS
The optical characteristics are measured based on the conditions as below:
- Supplying the signals and voltages defined in the section of electrical characteristics.
- The backlight unit needs to be turned on for 30 minutes.
- The ambient temperature is 25 $ C ,VDD=12.0V,fv=60Hz.
- In the dark room around 500~1000 lx, the equipment has been set for the measurements as shown in
Fig 6.1.
Ta 25 $C , f v 60 Hz, VDD 12V
Item Symbol Condition Min. Typ. Max. Unit Remarks
2
Brightness of White - 280 350 - cd/m Note 1,2
$
Brightness Uniformity - T 0 70 - - % Note 3
Contrast Ratio CR 600 900 - - Note 4
Rise ton - 12.7 21.9
Response Time ms Note 5
Fall toff - 11.5 20.7
X 0.614 0.644 0.674
Red
Y 0.307 0.337 0.367
X 0.306 0.336 0.366
Green
Color Y 0.583 0.613 0.643
T 0$ - Note 6
Chromaticity X 0.116 0.146 0.176
Blue
Y 0.015 0.045 0.075
X 0.283 0.313 0.343
White
Y 0.299 0.329 0.359
$
T 85
Contrast Ratio at 85 CR 85 I $
0 , 90 $ , 10 - - - -
$ $
180 , 270
NTSC Ratio T 0$ - 72 - % -
Note 1: The brightness is measured from the panel center point, P5 in Fig. 6.2, for the typical value.
Note 2: Brightness of white is measured by LCM is light up after 30 minutes .
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2706-TX48D50VM0BAA-1 PAGE 6-1/2
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Note 3: The brightness uniformity is calculated by the equation as below:
Min. Brightness
Brightness uniformity u 100%
Max. Brightness
, which is based on the brightness values of the 9 points measured by CS-1000A as shown in Fig. 6.2.
1$
Fig. 6.1 Fig. 6.2
Note 4: The Contrast Ratio is measured from the center point of the panel, P5, and defined as the
following equation:
Brightness of White
CR
Brightness of Black
Note 5: The definition of response time is shown in Fig. 6.3. The rising time is the period from 10%
brightness to 90% brightness when the data is from black to white. Oppositely, Falling time is
the period from 90% brightness rising to 10% brightness.
Fig 6.3
Note 6: The color chromaticity is measured from the center point of the panel, P5, as shown in Fig. 6.2.
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2706-TX48D50VM0BAA-1 PAGE 6-2/2
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
7. BLOCK DIAGRAM
7.1 TFT Module
Receiver
Drain driver
CN1
ODD
D5040
LVDS (ODD data)
D1
D2
pixel
Timing signals Timing
Display data converter
Control signals G1
G2
LVDS (EVEN data) EVEN
Gate driver
Display data pixel
TFT-LCD
(IPS-Pro)
Receiver DC/DC
converter
G1050
DC power supply
7.2 Back light unit
LED (Series)
CN2
LED (Series)
DC power supply LED (Series)
LED driver
ON/OFF Control
Brightness Control
SHEET
KAOHSIUNG OPTO-ELECTRONICS INC. 7B64PS 2707-TX48D50VM0BAA-1 PAGE 7-1/1
NO.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
8. INTERFACE PIN ASSIGNMENT
8.1 TFT-LCD MODULE
The display interface connector (CN1) is MDF76GW-30S-1H (HIROSE), and Pin assignment is as below:
(Matching connector: JAE FI-X30H or FI-X30M or Equivalent )
Pin No. Symbol Function Note
1 RAIN0-
ODD pixel data 2)
2 RAIN0+
3 RAIN1-
ODD pixel data 2)
4 RAIN1+
5 RAIN2-
ODD pixel data 2)
6 RAIN2+
7 VSS GND (0V) 1)
8 RACLKIN-
ODD pixel clock 2)
9 RACLKIN+
10 RAIN3-
ODD pixel data 2)
11 RAIN3+
12 RBIN0- 2)
EVEN pixel data
13 RBIN0+ 2)
14 VSS GND (0V) 1)
15 RBIN1-
EVEN pixel data 2)
16 RBIN1+
17 VSS GND (0V) 1)
18 RBIN2-
EVEN pixel data 2)
19 RBIN2+
20 RBCLKIN-
EVEN pixel clock 2)
21 RBCLKIN+
22 RBIN3-
EVEN pixel data 2)
23 RBIN3+
24 VSS GND (0V) 1)
25 NC No Connection 3)
26 DE No Connection 3)
27 NC No Connection 3)
28 VDD
29 VDD Power Supply (12V) 4)
30 VDD
Notes 1) All Vss pins should be grounded.
