Image preview - the first page of the document
Panel_HITACHI_TX31D37VM0CAA_0_[DS]


>> Download Panel_HITACHI_TX31D37VM0CAA_0_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center           www.panelook.com




                                  KAOHSIUNG HITACHI ELECTRONICS CO., LTD.



       FOR MESSRS:                                                                  DATE: Nov. 21th 2011


                       CUSTOMER'S ACCEPTANCE SPECIFICATIONS

                                          TX31D37VM0CAA

                                                  Contents
        No.                     ITEM                            SHEET No.                    PAGE
         1     COVER                                7B64PS 2701-TX31D37VM0CAA-1          1-1/1
         2     RECORD OF REVISION                   7B64PS 2702-TX31D37VM0CAA-1          2-1/1
         3     GENERAL DATA                         7B64PS 2703-TX31D37VM0CAA-1          3-1/1
         4     ABSOLUTE MAXIMUM RATINGS             7B64PS 2704-TX31D37VM0CAA-1          4-1/1
         5     ELECTRICAL CHARACTERISTICS           7B64PS 2705-TX31D37VM0CAA-1          5-1/1
         6     OPTICAL CHARACTERISTICS              7B64PS 2706-TX31D37VM0CAA-1          6-1/2~2/2
         7     BLOCK DIAGRAME                       7B64PS 2707-TX31D37VM0CAA-1          7-1/1
         8     RELIABILITY TESTS                    7B64PS 2708-TX31D37VM0CAA-1          8-1/1
         9     LCD INTERFACE                        7B64PS 2709-TX31D37VM0CAA-1          9-1/10~10/10
         10    OUTLINE DIMENSIONS                   7B64PS 2710-TX31D37VM0CAA-1          10-1/2~2/2
         11    APPEARANCE STANDARD                  7B64PS 2711-TX31D37VM0CAA-1          11-1/3~3/3
         12    PRECAUTIONS                          7B64PS 2712-TX31D37VM0CAA-1          12-1/2~2/2
         13    DESIGNATION OF LOT MARK              7B64PS 2713-TX31D37VM0CAA-1          13-1/1~1/1




       ACCEPTED BY:                                            PROPOSED BY:




         KAOHSIUNG HITACHI        SHEET
        ELECTRONICS CO., LTD.      NO.           7B64PS 2701-TX31D37VM0CAA-1                PAGE      1-1/1


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com


       2. RECORD OF REVISION
        DATE            SHEET No.                               SUMMARY




         KAOHSIUNG HITACHI          SHEET
        ELECTRONICS CO., LTD.        NO.         7B64PS 2702-TX31D37VM0CAA-1                PAGE    2-1/1


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center              www.panelook.com


       3. GENERAL DATA
       3.1 DISPLAY FEATURES
       This module is a 12.1" SVGA of 4:3 format amorphous silicon TFT. The pixel format is vertical stripe
       and sub pixels are arranged as R (red), G (green), B (blue) sequentially. This display is RoHS
       compliant, COG (chip on glass) technology and LED backlight are applied on this display.

         Part Name                         TX31D37VM0CAA

         Module Dimensions                 280.0(W) mm x 210.0(H) mm x 12.58 (D) mm typ.

         LCD Active Area                   246.0(W) mm x 184.5(H) mm

         Pixel Pitch                       0.3075(W) mm x 0.3075 (H) mm

         Resolution                        800 x 3(RGB)(W) x 600(H) dots

         Color Pixel Arrangement           R, G, B Vertical stripe

         LCD Type                          Transmissive Color TFT; Normally Black

         Display Type                      Active Matrix

         Number of Colors                  16.7M Colors

         Backlight                         24 LEDs (3 series x 8)

         Weight                            (710) typ. (g)

         Interface                         LVDS; 20 pins

         Power Supply Voltage              3.3V for LCD; 12V for Backlight

         Power Consumption                 1.815W for LCD; 9.6W for Backlight

         Viewing Direction                 Super Wide Version (In-Plane Switching)




         KAOHSIUNG HITACHI         SHEET
        ELECTRONICS CO., LTD.       NO.              7B64PS 2703-TX31D37VM0CAA-1                PAGE    3-1/1


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center               www.panelook.com


       4. ABSOLUTE MAXIMUM RATINGS
                        Item                   Symbol         Min.         Max.        Unit        Remarks
                  Supply Voltage                 VDD            0           4.0         V              -
               Input Voltage of Logic             VI          -0.3       VDD+0.3        V           Note 1
                                                                                        $
              Operating Temperature              Top           -20            70            C       Note 2
                                                                                        $
               Storage Temperature               Tst           -30            80            C       Note 2
               Backlight Input Voltage          VLED            -             15        V              -


       Note 1: The rating is defined for the signal voltages of the interface such as CLK and pixel data pairs.
       Note 2: The maximum rating is defined as above based on the temperature on the panel surface, which
               might be different from ambient temperature after assembling the panel into the application.
               Moreover, some temperature-related phenomenon as below needed to be noticed:
              - Background color, contrast and response time would be different in temperatures other than
                25 $ C .
              - Operating under high temperature will shorten LED lifetime.




         KAOHSIUNG HITACHI           SHEET
        ELECTRONICS CO., LTD.         NO.              7B64PS 2704-TX31D37VM0CAA-1                   PAGE     4-1/1


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center               www.panelook.com

       5. ELECTRICAL CHARACTERISTICS
       5.1 LCD CHARACTERISTICS                                                                   Ta    25 $ C , VSS      0V
                 Item           Symbol       Condition           Min.        Typ.       Max.          Unit     Remarks
         Power Supply Voltage    VDD              -              3.0         3.3        3.6            V             -
           Differential Input                 "H" level           -           -         +100
           Voltage for LVDS       VI                                                                  mV           Note 1
          Receiver Threshold                  "L" level          -100         -          -
           Voltage Input for                  "H" level         0.7VDD        -         VDD                        COMS
                                  VF                                                                   V
               AMode                          "L" level           0           -        0.3VDD                      Level
         Power Supply Current     IDD        IVDD=3.3V            -          550        600           mA           Note 2
           Vsync Frequency        fv              -               -          60          75           Hz             -
           Hsync Frequency        fH              -               -          37.7       50.6          KHz
                                                                                                                   Note 3
           CLK Frequency         f CLK            -               37         40          43           MHz

       Note 1: VCM=+1.2V
                                                                                        IN+
               VCM is common mode voltage of LVDS transmitter/receiver.                                       LVDS
                                                                                            100
                                                                                        IN-                  Receiver
               The input terminal of LVDS transmitter is terminated with 100.
       Note 2: An all white check pattern is used when measuring IDD. f v is set to 60 Hz.
       Note 3: For LVDS transmitter input.
       Note 4: 1.0A fuse is applied in the module for IDD. For display activation and protection purpose, power
               supply is recommended larger than 2.5A to start the display and break fuse once any short
               circuit occurred.


       5.2 BACKLIGHT CHARACTERISTICS                                                                          Ta     25 $ C
                 Item           Symbol         Condition              Min.    Typ.      Max.          Unit     Remarks
          LED Input Voltage     VLED                  -               11.7        12     12.3          V           Note1
         LED Forward Current                  0V; 0% duty               -      800           -
                                 ILED                                                                 mA           Note 2
            (Dim Control)                  3.3VDC; 100% duty            -         60     72
             LED lifetime          -            800 mA                  -      70K           -        hrs          Note 3
       Note 1: As Fig. 5.1 shown, LED current is constant, 800 mA, controlled by the LED driver when
              applying 12V VLED.
       Note 2: Dimming function can be obtained by applying DC voltage or PWM signal from the display
               interface CN1. The recommended PWM signal is 1K ~ 10K Hz with 3.3V amplitude.
       Note 3: The estimated lifetime is specified as the time to reduce 50% brightness by applying 800 mA at
               25 $ C .




                                                                 Fig 5.1
         KAOHSIUNG HITACHI         SHEET
        ELECTRONICS CO., LTD.       NO.                   7B64PS 2705-TX31D37VM0CAA-1                        PAGE          5-1/1


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                               www.panelook.com


       6. OPTICAL CHARACTERISTICS
       The optical characteristics are measured based on the conditions as below:
       - Supplying the signals and voltages defined in the section of electrical characteristics.
       - The backlight unit needs to be turned on for 30 minutes.
       - The ambient temperature is 25 $ C .
       - In the dark room around 500~1000 lx, the equipment has been set for the measurements as shown in
         Fig 6.1.
                                                                                                            Ta    25 $C , f v       60 Hz, VDD         3.3V
                    Item                Symbol              Condition             Min.           Typ.            Max.               Unit             Remarks
                                                                  $        $                                                               2
          Brightness of White              -            I     0 ,T      0 ,       480            600                 -          cd/m                 Note 1
         Brightness Uniformity             -                ILED= 90                  70          -                  -              %                Note 2
           Contrast Ratio                 CR                mA/series             500            1000                -               -               Note 3
           Response Time
            (Rising + Falling)          Tr  Tf          I      0$ ,T    0$            -           30             65                 ms               Note 4

                                          Tx        I       0$ , CR t 10              75          85                 -
                                                                  $
                                         T xc       I       180 , CR t 10             75          85                 -
            Viewing Angle                                                                                                       Degree               Note 5
                                          Ty        I         $
                                                            90 , CR t 10              75          85                 -
                                         T yc       I       270 $ , CR t 10           75          85                 -
                                           X                                      0.58           0.63            0.68
                            Red
                                           Y                                      0.30           0.35            0.40
                                           X                                      0.28           0.33            0.38
                           Green
            Color                          Y                                      0.57           0.62            0.67
                                                        I      0$ ,T    0$                                                           -               Note 6
        Chromaticity                       X                                      0.10           0.15            0.20
                            Blue
                                           Y                                      0.07           0.12            0.17
                                           X                                      0.28           0.33            0.38
                            White
                                           Y                                      0.33           0.38            0.43


       Note 1: The brightness is measured from the panel center point, P5 in Fig. 6.2, for the typical value.
       Note 2: The brightness uniformity is calculated by the equation as below:

                                                                      Min. Brightness
                                      Brightness uniformity                           u 100%
                                                                      Max. Brightness

       , which is based on the brightness values of the 9 points measured by BM-5 as shown in Fig. 6.2.

                                                                                                  1              2              3
                                                                                                                                               50%
                                   Photo Detector: BM-5                                    15%
                                                                                85%              4               5              6
                      $
             Field: 1
                                                                                                 7                8             9
                                   Distance: 500 mm
                                                                                                      15%
                                                                                                                         50%
                                                                                                                                     85%
                                        LCD panel
                                                                                                        measuring points

                        Fig. 6.1                                                                         Fig. 6.2

         KAOHSIUNG HITACHI                SHEET
        ELECTRONICS CO., LTD.              NO.                         7B64PS    2706-TX31D37VM0CAA-1                                          PAGE       6-1/2


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                   www.panelook.com


       Note 3: The Contrast Ratio is measured from the center point of the panel, P5, and defined as the
               following equation:

                                                       Brightness of White
                                                 CR
                                                       Brightness of Black

       Note 4: The definition of response time is shown in Fig. 6.3. The rising time is the period from 10%
               brightness to 90% brightness when the data is from black to white. Oppositely, Falling time is
               the period from 90% brightness falling to 10% brightness.




       Note 5: The definition of viewing angle is shown in Fig. 6.4. Angle I is used to represent viewing
               directions, for instance, I 270$ means 6 o'clock, and I 0 $ means 3 o'clock. Moreover,
               angle T is used to represent viewing angles from axis Z toward plane XY.
               The display is super wide viewing angle version, so that the best optical performance can be
               obtained from every viewing direction.


                                                             T       Viewing angle
                                              I 90$
                                       12 o'clock
                                                                                 I (x, y ,0)
                                                                                                $
                                  x'     $
                                                                                         x I 0
                                 I 180                                                     3 o'clock
                                  9 o'clock


                                                                            I 270$
                                                                             6 o'clock


                                                           Fig 6.4
       Note 6: The color chromaticity is measured from the center point of the panel, P5, as shown in Fig. 6.2.




         KAOHSIUNG HITACHI         SHEET
        ELECTRONICS CO., LTD.       NO.                 7B64PS       2706-TX31D37VM0CAA-1              PAGE   6-2/2


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center             www.panelook.com


       7 BLOCK DIAGRAM




       Note1: Signals are CLK and pixel data pairs.




         KAOHSIUNG HITACHI        SHEET
        ELECTRONICS CO., LTD.      NO.                7B64PS   2707-TX31D37VM0CAA-1         PAGE    7-1/1


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                                           www.panelook.com


       8. RELIABILITY TESTS
                Test Item                                                            Condition
                                   1) Operating
            High Temperature                                                                                                   240 hrs
                                   2) 70 $ C
                                   1) Operating
            Low Temperature                                                                                                    240 hrs
                                   2) -20 $ C
                                   1) Storage
            High Temperature                                                                                                   240 hrs
                                   2) 80 $ C
                                   1) Storage
            Low Temperature                                                                                                    240 hrs
                                   2) -30 $ C
                                   1) Operating
               Heat Cycle          2)



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
