Image preview - the first page of the document
![Panel_HITACHI_TX31D36VM2EAA_0_[DS]](/pics/5c8edc5941411.gif)
>> Download Panel_HITACHI_TX31D36VM2EAA_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
KAOHSIUNG HITACHI ELECTRONICS CO., LTD.
FOR MESSRS: DATE: Aug. 06th 2010
CUSTOMER'S ACCEPTANCE SPECIFICATIONS
TX31D36VM2EAA
Contents
No. ITEM SHEET No. PAGE
1 COVER 7B64PS 2701-TX31D36VM2EAA-1 1-1/1
2 RECORD OF REVISION 7B64PS 2702-TX31D36VM2EAA-1 2-1/1
3 GENERAL DATA 7B64PS 2703-TX31D36VM2EAA-1 3-1/1
4 ABSOLUTE MAXIMUM RATINGS 7B64PS 2704-TX31D36VM2EAA-1 4-1/1
5 ELECTRICAL CHARACTERISTICS 7B64PS 2705-TX31D36VM2EAA-1 5-1/2~2/2
6 OPTICAL CHARACTERISTICS 7B64PS 2706-TX31D36VM2EAA-1 6-1/3~3/3
7 BLOCK DIAGRAME 7B64PS 2707-TX31D36VM2EAA-1 7-1/1
8 RELIABILITY TESTS 7B64PS 2708-TX31D36VM2EAA-1 8-1/1
9 LCD INTERFACE 7B64PS 2709-TX31D36VM2EAA-1 9-1/12~12/12
10 OUTLINE DIMENSIONS 7B63PS 2710-TX31D36VM2EAA-1 10-1/2~2/2
11 APPEARANCE STANDARD 7B64PS 2711-TX31D36VM2EAA-1 11-1/3~3/3
12 PRECAUTIONS 7B64PS 2712-TX31D36VM2EAA-1 12-1/2~2/2
13 DESIGNATION OF LOT MARK 7B64PS 2713-TX31D36VM2EAA-1 13-1/1
ACCEPTED BY: PROPOSED BY:
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2701-TX31D36VM2EAA-1 PAGE 1-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. RECORD OF REVISION
DATE SHEET No. SUMMARY
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2702-TX31D36VM2EAA-1 PAGE 2-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3. GENERAL DATA
3.1 DISPLAY FEATURES
This module is a 12.1" SVGA of 4:3 format amorphous silicon TFT. The pixel format is vertical stripe
and sub pixels are arranged as R (red), G (green), B (blue) sequentially. This display is RoHS
compliant, COG (chip on glass) technology and LED backlight are applied on this display.
Part Name TX31D36VM2EAA
Module Dimensions 280.0(W) mm x 210.0(H) mm x 11.0(D) mm typ.
LCD Active Area 246.0(W) mm x 184.5(H) mm
Pixel Pitch 0.3075(W) mm x 0.3075 (H) mm
Resolution 800 x 3(RGB)(W) x 600(H) dots
Color Pixel Arrangement R, G, B Vertical stripe
LCD Type Transmissive Color TFT; Normally White; Anti-Reflection Polarizer
Display Type Active Matrix
Number of Colors 16.7M Colors (R.G.B 8bits digital each)
Backlight LED
Weight (680g)
Interface LVDS; 1ch 8bits 20pins
Power Supply Voltage 3.3V for LCD; 12V for Backlight
Power Consumption (1.5W) for LCD; (13.4W) typ. for Backlight
12 o'clock
Viewing Direction
(The direction without image inversion and least brightness change)
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2703-TX31D36VM2EAA-1 PAGE 3-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4. ABSOLUTE MAXIMUM RATINGS
Item Symbol Min. Max. Unit Remarks
Supply Voltage VDD 0 4.0 V -
Input Voltage of Logic and LVDS VI / VTH -0.3 VDD+0.3 V Note 1
$
Operating Temperature Top -20 70 C Note 2
$
Storage Temperature Tst -30 80 C Note 2
Backlight Input Voltage VLED 10.0 17.0 V Note 3
Note 1: It shall be applied to pixel data signal, clock signal and control Pin.
Note 2: The maximum rating is defined as above based on the temperature on the panel surface, which
might be different from ambient temperature after assembling the panel into the application.
Moreover, some temperature-related phenomenon as below needed to be noticed:
- Background color, contrast and response time would be different in temperatures other than
$
25 C .
- Operating under high temperature will shorten LED lifetime.
Note 3: Do not operate at or near the maximum rating listed for extended periods of time. Exposure to
such conditions may adversely impact product reliability and result in failures not covered by
warranty.
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2704-TX31D36VM2EAA-1 PAGE 4-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
5. ELECTRICAL CHARACTERISTICS
5.1 LCD CHARACTERISTICS Ta 25 $ C , VSS 0V
Item Symbol Condition Min. Typ. Max. Unit Remarks
Power Supply Voltage VDD - 3.0 3.3 3.6 V -
Differential Input "H" level - - +100
Voltage for LVDS VTH mV Note 1
Receiver Threshold "L" level -100 - -
"H" level 2.0 VDD
Input Voltage for Logic VI V Note 2
"L" level VSS 0.8
VDD-VSS
Power Supply Current IDD - 450 - mA Note 3,4,5
=3.3V
Vsync Frequency fv - - 60 68 Hz Note 6
Hsync Frequency fH - - 37.7 42.5 KHz -
DCLK Frequency f CLK - - 40 45 MHz -
Note 1: VCM=+1.25V
VCM is common mode voltage of LVDS transmitter/receiver.
The input terminal of LVDS transmitter is terminated with 100.
IN+
LVDS
100
IN- Receiver
Note 2: The rating is defined for the signal voltages of the interface such as FRC and MSL.
Note 3: fv=60Hz, fCLK=40MHz, VDD=3.3V, DC Current.
Typical value is measured when displaying vertical 256 gray scale.
Maximum is measured when displaying Vertical-stripe.
DC Ampere Meter
IDD TFT-LCM
VDD
VDD
VSS
Note 4: 1A fuse is built in the module. Current capacity for VDD power supply should be larger then
2.5A, so that the fuse built in the module (maximum) could appropriately work under the
abnormal conditions.
Note 5: For LVDS transmitter input.
Note 6: Vertical Frequency 60Hz is recommended for best optical performance in terms of flicker.
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2705-TX31D36VM2EAA-1 PAGE 5-1/2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
5.2 BACKLIGHT CHARACTERISTICS Ta 25 $C
Item Symbol Condition Min. Typ. Max. Unit Remarks
LED Input Voltage VLED Backlight Unit 10.8 12.0 13.2 V Note 1
LED Driving Current DIM=0V;0%Duty - 1120 -
ILED mA Note 2,4,5
(DIM Control) DIM=3.3V;100%Duty - (6) -
LED Lifetime - 90mA x 4 - 70k - hrs Note 3
Note 1: As Fig 5.1 shown, all LEDs are controlled by the LED Driver when applying 12V VLED.
Note 2: Dimming function can be obtained by applying DC voltage or PWM signal from the display
interface CN1. The recommend PWM signal is 1KHz ~ 10KHz with 3.3V amplitude. The
brightness is increased when applied DC voltage or PWM duty of DIM Pin is decreased.
Note 3: The estimated lifetime is specified as the time to reduce 50% brightness by applying 90mA x 4
at 25 $ C .
Note 4: Fuse is built in the module, current capacity for VLED power supply should be larger than 6.25A,
so that the fuse built in the module (maximum) could appropriately work under the abnormal
conditions.
Fig 5.1
Note 5: ILED V.S. DIM voltage (Reference only)
1.2
1.0
ILED(A)
0.8
0.6
0.4
0.2
0 0.5 1.0 1.5 2.0 2.5 3.0 3.5
DIM Voltage(V)
Fig 5.2
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2705-TX31D36VM2EAA-1 PAGE 5-2/2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
6. OPTICAL CHARACTERISTICS
The optical characteristics are measured based on the conditions as below:
- Supplying the signals and voltages defined in the section of electrical characteristics.
- The backlight unit needs to be turned on for 30 minutes.
- The ambient temperature is 25 $ C .
- In the dark room around 500~1000 lx, the equipment has been set for the measurements as shown in
Fig 6.1.
Ta 25 $C, fv 60 Hz, VDD 3.3V
Item Symbol Condition Min. Typ. Max. Unit Remarks
2
Brightness of White - 800 1000 - cd/m Note 1,7
I 0$ ,T 0$ ,
Brightness Uniformity - 70 - - % Note 2
DIM=0V
Contrast Ratio CR - 800 - - Note 3
Response Time Rise(Ton) - 15 -
(Rising + Falling) I 0$ ,T 0$ ms Note 4
Fall(Toff) - 10 -
NTSC Ratio - I 0$ ,T 0$ - (60) - % -
$
Tx I 0 , CR t 10 - 80 -
T xc I 180 $ , CR t 10 - 80 -
Viewing Angle $
Degree Note 5
Ty I 90 , CR t 10 - 80 -
T yc I 270 $ , CR t 10 - 60 -
X - 0.61 -
Red
Y - 0.36 -
X - 0.35 -
Green
Color Y - 0.59 -
I 0$ ,T 0$ - Note 6
Chromaticity X - 0.15 -
Blue
Y - 0.08 -
X - 0.32 -
White
Y - 0.32 -
Note 1: The brightness is measured from the panel center point, P5 in Fig. 6.2, for the typical value.
Note 2: The brightness uniformity is calculated by the equation as below:
Min. Brightness
Brightness uniformity u 100%
Max. Brightness
, which is based on the brightness values of the 9 points measured by BM-5A as shown in Fig. 6.2.
Y=133 Y=400 Y=667
Dot(0,0)
1$ P1 P2 P3
X=100
X=300 P4 P5 P6
P7 P8 P9
X=500
Fig. 6.1 Fig. 6.2
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2706-TX31D36VM2EAA-1 PAGE 6-1/3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Note 3: The contrast ratio is measured from the center point of the panel, P5, and defined as the
following equation:
Brightness of White
CR
Brightness of Black
Note 4: The definition of response time is shown in Fig. 6.3. The rising time is the period from 90%
brightness to 10% brightness when the data is from white to black. Oppositely, Falling time is
the period from 10% brightness rising to 90% brightness.
White Black White
Tr Rising time Falling time Tf
100 %
90
Brightness
10
0
Fig . 6.3
Note 5: The definition of viewing angle is shown in Fig. 6.4. Angle I is used to represent viewing
directions, for instance, I 270 $ means 6 o'clock, and I 0 $ means 3 o'clock. Moreover,
angle T is used to represent viewing angles from axis Z toward plane XY.
The viewing direction of this display is 12 o'clock, which means that a photograph with gray
scale would not be reversed in color and the brightness change would be less from this
direction. However, the best contrast peak would be located at 6 o'clock.
T Viewing angle
I 90$
12 o'clock
I (x, y ,0)
$
x' $
x I 0
I 180 3 o'clock
9 o'clock
I 270$
6 o'clock
Fig 6.4
Note 6: The color chromaticity is measured from the center point of the panel, P5, as shown in Fig. 6.2.
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2706-TX31D36VM2EAA-1 PAGE 6-2/3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Note 7: Relative Brightness V.S. DIM Voltage (Reference only)
1.0
Relative Brightness[%]
0.8
0.6
0.4
0.2
0 0.5 1.0 1.5 2.0 2.5 3.0 3.5
DIM Voltage(V)
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2706-TX31D36VM2EAA-1 PAGE 6-3/3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
7 BLOCK DIAGRAM
(1, 1) (1, 800)
VDD Power
Circuit
TFT LCD
Gamma
Voltage
Generator
(600, 1) (600, 800)
Signals Source Driver
Timing
Controller
DIM
VDD
VLED LED Control
LED Backlight
Circuit
KAOHSIUNG HITACHI SHEET
ELECTRONICS CO., LTD. NO. 7B64PS 2707-TX31D36VM2EAA-1 PAGE 7-1/1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
8. RELIABILITY TESTS
Test Item Condition
1) Operating
High Temperature 240 hrs
2) 70 $ C
1) Operating
Low Temperature 240 hrs
2) -20 $ C
1) Storage
High Temperature 240 hrs
2) 80 $ C
1) Storage
Low Temperature 240 hrs
2) -30 $ C
1) Operating
