Image preview - the first page of the document
Panel_HITACHI_TX31D38VM2BAA_2_[DS]


>> Download Panel_HITACHI_TX31D38VM2BAA_2_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center           www.panelook.com




       FOR MESSRS :                                                                 DATE : May 1st, 2012


                      CUSTOMER'S ACCEPTANCE SPECIFICATIONS

                                        TX31D38VM2BAA

                                                   Contents
        No.                   ITEM                              SHEET No.                    PAGE
         1     COVER                                7B64PS 2701- TX31D38VM2BAA-2         1-1/1
         2     RECORD OF REVISION                   7B64PS 2702- TX31D38VM2BAA-2         2-1/1
         3     GENERAL DATA                         7B64PS 2703- TX31D38VM2BAA-2         3-1/1
         4     ABSOLUTE MAXIMUM RATINGS             7B64PS 2704- TX31D38VM2BAA-2         4-1/1
         5     ELECTRICAL CHARACTERISTICS           7B64PS 2705- TX31D38VM2BAA-2         5-1/2~2/2
         6     OPTICAL CHARACTERISTICS              7B64PS 2706- TX31D38VM2BAA-2         6-1/2~2/2
         7     BLOCK DIAGRAME                       7B64PS 2707- TX31D38VM2BAA-2         7-1/1
         8     RELIABILITY TESTS                    7B64PS 2708- TX31D38VM2BAA-2         8-1/1
         9     LCD INTERFACE                        7B64PS 2709- TX31D38VM2BAA-2         9-1/7~7/7
         10    OUTLINE DIMENSIONS                   7B64PS 2710- TX31D38VM2BAA-2         10-1/2~2/2
         11    APPEARANCE STANDARD                  7B64PS 2711- TX31D38VM2BAA-2         11-1/3~3/3
         12    PRECAUTIONS                          7B64PS 2712- TX31D38VM2BAA-2         12-1/2~2/2
         13    DESIGNATION OF LOT MARK              7B64PS 2713- TX31D38VM2BAA-2         13-1/1




        ACCEPTED BY:                                          PROPOSED BY:



                                           SHEET
     KAOHSIUNG OPTO-ELECTRONICS INC.                    7B64PS 2701-TX31D38VM2BAA-2        PAGE      1-1/1
                                            NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com


       2. RECORD OF REVISION
         DATE          SHEET No.                                 SUMMARY
       May 01,'12   All pages         Company name changed:
                                       KAOHSIUNG HITACHI ELECTRONICS CO.,LTD.
                                                          p
                                       KAOHSIUNG OPTO-ELECTRONICS INC.




                                           SHEET
     KAOHSIUNG OPTO-ELECTRONICS INC.                    7B64PS 2702-TX31D38VM2BAA-2        PAGE    2-1/1
                                            NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                www.panelook.com


       3. GENERAL DATA
       3.1 DISPLAY FEATURES
       This module is a 12.3" HSXGA of 8:3 format amorphous silicon TFT. The pixel format is vertical stripe
       and sub pixels are arranged as R (red), G (green), B (blue) sequentially. This display is RoHS
       compliant, COG (chip on glass) technology and LED backlight are applied on this display.

         Part Name                         TX31D38VM2BAA

         Module Dimensions                 320(W) mm x 130(H) mm x (12.8)(D) mm typ.

         LCD Active Area                   293.76(W) mm x 110.16(H) mm

         Pixel Pitch                       0.2295(W) mm x 0.2295(H) mm

         Resolution                        1280 x 3(RGB)(W) x 480(H) dots

         Color Pixel Arrangement           R, G, B Vertical stripe

         LCD Type                          Transmissive Color TFT; Normally White

         Display Type                      Active Matrix

         Number of Colors                  262k Colors

         Backlight                         LED (Lifetime: 70 Khrs)

         Weight                            586 g

         Interface                         LVDS; 20 pins

         Power Supply Voltage              3.3V for LCD; 12V for Backlight

         Power Consumption                 1.848 W for LCD; 10.08 W for backlight
                                          12 o'clock (without image inversion and least brightness change)
         Viewing Direction
                                          6 o'clock (contrast peak located at)




                                            SHEET
    KAOHSIUNG OPTO-ELECTRONICS INC.                         7B64PS 2703-TX31D38VM2BAA-2             PAGE     3-1/1
                                             NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                 www.panelook.com


       4. ABSOLUTE MAXIMUM RATINGS
                        Item                     Symbol         Min.          Max.       Unit    Remarks
                   Supply Voltage                 VDD             0           4.0         V         -
                Input Voltage of Logic             VI           -0.3       VDD+0.3        V      Note 1
                                                                                         $
               Operating Temperature               Top           -30           80            C   Note 2
                                                                                         $
                Storage Temperature                Tst           -40           90            C   Note 2
               Backlight Input Voltage           VLED             -            15         V      Note 3


       Note 1: It shall be applied to pixel data signal, clock signal and control Pin.
       Note 2: The maximum rating is defined as above based on the chamber temperature, which might be
               different from ambient temperature after assembling the panel into the application. Moreover,
               some temperature-related phenomenon as below needed to be noticed:
              - Background color, contrast and response time would be different in temperatures other than
                25 $ C .
              - Operating under high temperature will shorten LED lifetime.
       Note 3: Do not operate at or near the maximum rating listed for extended periods of time. Exposure to
               such conditions may adversely impact product reliability and result in failures not covered by
               warranty.




                                                SHEET
     KAOHSIUNG OPTO-ELECTRONICS INC.                          7B64PS 2704-TX31D38VM2BAA-2        PAGE      4-1/1
                                                 NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                 www.panelook.com


       5. ELECTRICAL CHARACTERISTICS
       5.1 LCD CHARACTERISTICS                                                              Ta     25 $ C , VSS       0V
               Item                Symbol        Condition         Min.     Typ.    Max.         Unit     Remarks
          Power Supply                                  -           3.0     3.3      3.6          V               -
                                    VDD
              Voltage
         Differential Input                        VIH               -       -      +100
         Voltage for LVDS            VI                                                          mV         Note 1
        Receiver Threshold                         VIL             -100      -        -

          Power Supply                           VDD-VSS
            Current                 IDD                              -      560      680         mA        Note 2,3
                                                  =3.3V
         Vsync Frequency             fv                 -            -      60       66          Hz
         Hsync Frequency             fH                 -            -      31.8    33.3         KHz        Note 4
         DCLK Frequency             f CLK               -            -      43.2     48          MHz


       Note 1: VCM=+1.2V
               VCM is common mode voltage of LVDS transmitter/receiver.
               The input terminal of LVDS transmitter is terminated with 100.

                              IN+
                                                LVDS
                                  100
                              IN-            Receiver


       Note 2: An all black check pattern is used when measuring IDD, f v is set to 60Hz.

                              DC Ampere Meter
                                                             TFT-LCM
                                                  IDD
                                                             VDD
                                    VDD
                                                             VSS


       Note 3: 1.0A fuse is applied in the module for IDD. For display activation and protection purpose, power
               supply is recommended larger than 2.5A to start the display and break fuse once any short
               circuit occurred.
       Note 4: For LVDS transmitter input.




                                                 SHEET
     KAOHSIUNG OPTO-ELECTRONICS INC.                               7B64PS 2705-TX31D38VM2BAA-2          PAGE          5-1/2
                                                  NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center              www.panelook.com


       5.2 BACKLIGHT CHARACTERISTICS                                                                Ta     25 $ C
                Item           Symbol        Condition             Min.   Typ.   Max.       Unit    Remarks
          LED Input Voltage    VLED              -                 11.5   12     12.5        V           Note1
         LED Forward Current                0V; 0% duty             -     840     890
                                ILED                                                        mA       Note 2
            (Dim Control)                3.3VDC; 100% duty          -     70      120
             LED lifetime         -           840 mA                -     70K      -        hrs      Note 3


       Note 1: As Fig. 5.1 shown, LED current is constant, 840 mA, controlled by the LED driver when
              applying 12V VLED.
       Note 2: Dimming function can be obtained by applying DC voltage or PWM signal from the display
               interface CN1. The recommended PWM signal is 1K ~ 10K Hz with 3.3V amplitude.
       Note 3: The estimated lifetime is specified as the time to reduce 50% brightness by applying 840 mA at
               25 $ C .




                                                         Fig 5.1




                                             SHEET
     KAOHSIUNG OPTO-ELECTRONICS INC.                          7B64PS 2705-TX31D38VM2BAA-2          PAGE       5-2/2
                                              NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                               www.panelook.com


       6. OPTICAL CHARACTERISTICS
       The optical characteristics are measured based on the conditions as below:
       - Supplying the signals and voltages defined in the section of electrical characteristics.
       - The backlight unit needs to be turned on for 30 minutes.
       - The ambient temperature is 25 $ C .
       - In the dark room around 500~1000 lx, the equipment has been set for the measurements as shown in
         Fig 6.1.
                                                                           Ta = 25 $C, fv = 60 Hz, VDD = 3.3V

                Item                 Symbol               Condition              Min.        Typ.       Max.            Unit         Remarks
                                                                                                                               2
         Brightness of White               -                                     800      1000               -          cd/m         Note 1
                                                      I       0$ ,T    0$ ,
        Brightness Uniformity              -                                     70           -              -           %           Note 2
                                                      ILED= 840 mA
          Contrast Ratio               CR                                        400         800             -           -           Note 3
          Response Time
           (Rising + Falling)        Tr  Tf           I        0$ ,T   0$         -           25             -           ms          Note 4
            NTSC Ratio                     -          I        0$ ,T   0$         -           60             -           %                -
                                                          $
                                      Tx          I   0 , CR t 10                60           80             -
                                      T xc        I           $
                                                      180 , CR t 10              60           80             -
           Viewing Angle                                                                                            Degree           Note 5
                                      Ty          I   90 $ , CR t 10             40           60             -
                                      T yc        I   270 $ , CR t 10            60           80             -
                                       X                                         0.55        0.60           0.65
                          Red
                                       Y                                         0.31        0.36           0.41
                                       X                                         0.31        0.36           0.41
                         Green
           Color                       Y                                         0.55        0.60           0.65
                                                      I        0$ ,T   0$                                                -           Note 6
       Chromaticity                    X                                         0.10        0.15           0.20
                          Blue
                                       Y                                         0.05        0.10           0.15
                                       X                                         0.27        0.32           0.37
                         White
                                       Y                                         0.30        0.35           0.40

       Note 1: The brightness is measured from center point of the panel, P5 in Fig. 6.2, for the typical value.
       Note 2: The brightness uniformity is calculated by the equation as below:
                                                              Min. Brightness
                        Brightness uniformity =                                   X100%
                                                              Max. Brightness

       , which is based on the brightness values of the 9 points measured by BM-7 as shown in Fig. 6.2.

                                                                                        320           640          960
                                 Photo detector: BM-7
                                                                                  80     1              2           3


              Field 1           Distance       500 mm                            240     4              5           6



                                     LCD panel                                   400     7              8           9


                                                                                                    Fig. 6.2
                     Fig. 6.1



                                                          SHEET
    KAOHSIUNG OPTO-ELECTRONICS INC.                                           7B64PS 2706-TX31D38VM2BAA-2                          PAGE       6-1/2
                                                           NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                              www.panelook.com


       Note 3: The contrast ratio is measured from the center point of the panel, P5, and defined as the
               following equation:

                                                                     Brightness of White
                                                            CR
                                                                     Brightness of Black

       Note 4: The definition of response time is shown in Fig. 6.3. The rising time is the period from 90%
               brightness to 10% brightness when the data is from white to black. Oppositely, Falling time is
               the period from 10% brightness rising to 90% brightness.



                                                        White                        Black                             White


                                                                     Tr   Rising time         Falling time             Tf
                                    100 %
                                       90
                               Brightness




                                             10
                                              0
                                                                                  Fig . 6.3

       Note 5: The definition of viewing angle is shown in Fig. 6.4. Angle I is used to represent viewing
               directions, for instance, I 270 $ means 6 o'clock, and I 0 $ means 3 o'clock. Moreover,
               angle T is used to represent viewing angles from axis Z toward plane XY.
               The viewing direction of this display is 12 o'clock, which means that a photograph with gray
               scale would not be reversed in color and the brightness change would be less from this
               direction. However, the best contrast peak would be located at 6 o'clock.

                                                                             z
                                                                                  T = Viewing angle
                                                         I 90$
                                                                 y
                                                  12 o'clock
                                                                                                         I (x, y ,0)
                                                                                                                        $
                                            x'      $
                                                                                                                 x I 0
                                            I 180                                                                  3 o'clock
                                             9 o'clock


                                                                                              y' I     270$
                                                                                                     6 o'clock
                                                                             z'
                                                                          Fig. 6.4

       Note 6: The color chromaticity is measured from the center point of the panel, P5, as shown in Fig. 6.2.




                                                            SHEET
     KAOHSIUNG OPTO-ELECTRONICS INC.                                              7B64PS 2706-TX31D38VM2BAA-2                  PAGE   6-2/2
                                                             NO.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                             www.panelook.com


       8. RELIABILITY TESTS
                Test Item                                                             Condition
                                          1) Operating
            High Temperature                                                                                 500 hrs
                                          2) 80 $ C
                                          1) Operating
            Low Temperature                                                                                  500 hrs
                                          2) -30 $ C
                                          1) Storage
            High Temperature                                                                                 500 hrs
                                          2) 90 $ C
                                          1) Storage
            Low Temperature                                                                                  500 hrs
                                          2) -40 $ C
                                          1) Operating
               Heat Cycle                 2)



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
