Image preview - the first page of the document
>> Download Panel_HYDIS_HV121WX4-110_0_[DS] documenatation <<Text preview - extract from the document Global LCD Panel Exchange Center www.panelook.com
PROPRIETARY NOTE
THIS SPECIFICATION IS THE PROPERTY OF HYDIS AND SHALL NOT BE
REPRODUCED OR COPIED WITHOUT THE WRITTEN PERMISSION OF
HYDIS AND MUST BE RETURNED TO HYDIS UPON ITS REQUEST
TITLE : HV121WX4-110
Product Specification
Rev. A
HYDIS Technologies
SPEC. NUMBER PRODUCT GROUP REV. ISSUE DATE PAGE
S864-1342 TFT-LCD PRODUCTS A 2009. 02. 10 1 OF 30
B2005-C001-D(1/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT-LCD PRODUCT 2009.02.10
REVISION HISTORY
REV. ECN NO. DESCRIPTION OF CHANGES DATE PREPARED
O Initial Release 07.10.30 Joseph Ha
A E0902-F003 CI Logo Change (HYDIS) 09.02.10 S.T. KO
SPEC. NUMBER SPEC. TITLE PAGE
S864-1342 HV121WX4-110 Product Specification 2 OF 30
B2005-C001-D(2/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP
TFT-LCD PRODUCT 2009.02.10
Contents
No Item Page
1.0 General Description .. ................................................................. 4
2.0 Absolute Maximum ratings........................................................... 6
3.0 Electrical specifications ................................................................ 7
4.0 Optical specifications .................................................................. 8
5.0 Interface Connection .................................................................. 10
6.0 Signal Timing Specification .......................................................... 12
7.0 Signal Timing waveforms of interface signal (DE mode) ............... 14
8.0 Input Signals, Display Colors & Gray Scale of Colors ..................... 15
9.0 Power Sequence ........................................................................ 16
10.0 Mechanical Characteristics .......................................................... 17
11.0 Reliability Test ........................................................................... 18
12.0 Handling & Cautions ................................................................... 19
13.0 Packing ..................................................................................... 20
14.0 Environment & Safety.................................................................. 21
15.0 Appendix ........................................................................................... 23
16.0 EDID Data .......................................................................................... 27
SPEC. NUMBER SPEC. TITLE PAGE
S864-1342 HV121WX4-110 Product Specification 3 OF 30
B2005-C001-D(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP
TFT-LCD PRODUCT 2009.02.10
1.0 GENERAL DESCRIPTION
1.1 Introduction
HV121WX4-110 is a color active matrix TFT LCD module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 12.1 inch
diagonally measured active area with WXGA resolutions (1280 horizontal by 800 vertical
pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this module can display 262,144 colors. The TFT-LCD panel used for
this module is a low reflection and higher color type.
LVDS Source Driver
Input
Signal LVDS Rx
+
Connector (CN
T/CON
Gate Driver
TFT LCD Panel
1280 800
VDD DC/DC
1 Gamma
)
Vcom
BACK LIGHT (Fluorescent Lamp)
.
CN2
1.2 Features
z Thin and light weight
z 3.3 V power supply
z Low driving voltage and low power consumption
z 1 Channel LVDS Interface
z Single CCFL (Bottom side/Horizontal Direction)
z 262,144 colors
z Data enable signal mode
z Side Mounting Frame
z On Board EDID chip
z RoHS Product
z VESA V2 Compatible except for thickness
z Anti-Reflection polarizer product for sunlight readability
SPEC. NUMBER SPEC. TITLE PAGE
S864-1342 HV121WX4-110 Product Specification 4 OF 30
B2005-C001-D(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP
TFT-LCD PRODUCT 2009.02.10
1.3 Application
z Tablet PC
1.4 General Specifications
Parameter Specification Unit Remarks
Active area 261.12 (H) 163.20 (V) mm
Number of pixels 1280 (H) 800 (V) pixels
Pixel pitch 0.204 (H) 0.204 (V) mm
Pixel arrangement RGB Vertical stripe
Display colors 262,144 colors
Display mode Normally Black
Dimensional
275.8r0.5(W) 178.0r0.5(V) 6.4 Typ D (6.7 Max) mm
outline
Luminance of
200 (Typ.) Cd/m
