Image preview - the first page of the document
![Panel_INNOLUX_BT156GW01_V-3_0_[DS]](/pics/5c8eddda94fed.gif)
>> Download Panel_INNOLUX_BT156GW01_V-3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
INNOLUX DISPLAY CORPORATION
BT156GW01 V.3 LCD MODULE SPECIFICATION
( ) Preliminary Specification
( ) Final Specification
Customer Checked & Approved by
HP
Approved by Checked by Prepared by
MKT PD PM
Annie Lu
Date: 2009/08/03
Innolux Display Corporation
No.160 Kesyue Rd., Chu-Nan Site, Hsinchu Science Park,
Chu-Nan 350, Miao-Li County, Taiwan
Tel: 886-37-586000 Fax: 886-37-586060
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Version: 0.1
InnoLux copyright
All rights reserved,
Copying forbidden.
Record of Revision
Version Revise Date Page Content
0.0 2009/05/27 All First Edition issued.
21, 22 Model name in 2D drawing revised.
0.1 2009/08/03
24 EDID code add.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. B T 1 5 6 G W 0 1 V. 3
PAGE 1/23
Contents: Page
1. General Specifications 2
2. Electrical Specifications
2-1 Pin Assignment 3
2-2 Absolute Maximum Ratings 5
2-3 Electrical Characteristics 6
3. Optical Specifications 12
4. Reliability Test Items 15
5. Safety 16
6. Display Quality 16
7. Handling Precaution 16
8. Label Definition 18
9. Packing Form 19
10. Mechanical Drawings 21
Appendix 24
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. B T 1 5 6 G W 0 1 V. 3
PAGE 2/23
1. General Specifications
NO. Item Specification Unit
1 Display resolution (pixel) 1366(H) X 768(V), HD resolution
2 Active area 344.232(H) X 193.536(V) mm
3 Screen size 15.6 inches diagonal Inches
4 Pixel pitch 0.252(H) X 0.252(V) mm
5 Color configuration Stripe
6 Overall dimension 359.8(W) X 210(H) X 5.5(D) (max) mm
7 Weight 450 Max. Grams
8 Surface treatment Glare, 3H
9 Input color signal 6 bit LVDS
10 Display colors 262K (6 bit)
11 Optimum viewing direction 6 o'clock
12 Backlight W-LED
13 RoHS RoHS compliance
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. B T 1 5 6 G W 0 1 V. 3
PAGE 3/23
2. Electrical Specifications
2-1. Pin Assignment
a. Panel connector
Connector Part No.: 20455-040-12 (I-PEX) or equivalent
User's connector Part No: 20453-040T-12 (I-PEX) or equivalent
Pin No Symbol Description Remark
1 NC No connection (Reserve)
2 VCC Power Supply (+3.3V)
3 VCC Power Supply (+3.3V)
4 VEDID DDC Power +3.3V
5 NC No connection (Reserve)
6 Clk EDID DDC Clock
7 DATA EDID DDC Data
8 Rxin0- Differential Data Input
R0~R5,G0
9 Rxin0+ Differential Data Input
10 GND Ground
11 Rxin1- Differential Data Input
G1~G5,B0,B1
12 Rxin1+ Differential Data Input
13 GND Ground
14 Rxin2- Differential Data Input
B2~B5,DE,Hsync,Vsync
15 Rxin2+ Differential Data Input
16 GND Ground
17 CLK- Differential Clock Input
18 CLK+ Differential Clock Input
19 NC No connection (Reserve)
20 NC No connection (Reserve)
21 NC No connection (Reserve)
22 NC No connection (Reserve)
23 NC No connection (Reserve)
24 NC No connection (Reserve)
25 NC No connection (Reserve)
26 NC No connection (Reserve)
27 NC No connection (Reserve)
28 NC No connection (Reserve)
29 NC No connection (Reserve)
30 NC No connection (Reserve)
31 LED_GND LED Ground
32 LED_GND LED Ground
33 LED_GND LED Ground
34 NC No connection (Reserve)
35 LED_PWM PWM dimming signal input
36 LED_EN LED enable pin (3.3V)
37 NC No connection (Reserve)
38 V_LED LED power supply 6.0V~20V
39 V_LED LED power supply 6.0V~20V
40 V_LED LED power supply 6.0V~20V
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. B T 1 5 6 G W 0 1 V. 3
PAGE 4/23
b. General Block Diagram
FPC
20455-040
VR DC/DC
DC/DC
Pin1
T-CON LED
Driver
Connector plug in direction
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. B T 1 5 6 G W 0 1 V. 3
PAGE 5/23
2-2. Absolute Maximum Ratings
Values Unit
Parameter Symbol Remark
Min. Max.
Power input voltage VCC - 0.3 4.0 V At 25 C
Signal input voltage VIN - 0.3 4.0 V At 25 C
Operating temperature TOP 0 50 C Note 1
Storage temperature TST - 20 60 C Note 2
Re-screw - 5 Times
Assured torque at side mount - 2 kgf.cm
Note 1: The relative humidity must not exceed 90% non-condensing at temperatures of 40 C or less.
At temperatures greater than 40 C, the wet bulb temperature must not exceed 39 C.
Note 2: The unit should not be exposed to corrosive chemicals.
Relative Humidity (%RH)
100
90
80
70
60 Operation Range
50
40
30
20
Storage Range
10
0
-30 -20 -10 0 10 20 30 40 50 60 70
