Image preview - the first page of the document
![Panel_INNOLUX_TM315GW11_V-0_0_[DS]](/pics/5e96bf20daa62.gif)
>> Download Panel_INNOLUX_TM315GW11_V-0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
INNOLUX DISPLAY CORPORATION
TM315GW11 V.0 LCD MODULE SPECIFICATION
( ) Preliminary Specification
( ) Final Specification
Customer Checked and Approved by
SEC
Innolux Display Corporation,
No.160 Kesyue Rd., Chu-Nan Site, Hsinchu Science Park,
Chu-Nan 350, Miao-Li County, Taiwan
Tel: 886-37-586000 Fax: 886-37-586060
Document Number: TM315GW11 V. 0 DR4-26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 2/23
InnoLux copyright
Version: 1.0 All rights reserved,
Copying forbidden.
Record of Revision
Version Revise Date Page Content
1 2010.2.05 All All
2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 3/23
Contents:
A. General Specification 4
B. Electrical Specifications 5
1. Pin assignment 5
2. Absolute maximum ratings 8
3. Electrical characteristics 8
a. TFT LCD Module conditions 8
b. Display color vs. input data signals 11
c. Input signal timing 12
d. Display position 14
e. Backlight driving conditions 15
C. Optical specifications 16
D. Reliability test items 20
E. Safety 21
F. Display quality 21
G. Handling precaution 21
H. Label 22
3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 4/23
A. General specification
NO. Item Specification Remark
1 Display resolution (pixel) 1,366(H) X 768(V), WXGA+ resolution
2 Active area (mm) 697.685 (H) X 392.256(V)
3 Screen size (inch) 31.5 inches diagonal
4 Pixel pitch (mm) 0.17025 (H) X 0.51075 (V)
5 Color configuration R, G, B vertical stripe
6 Overall dimension (mm) 783.55 (W) X 462.55 (H) X 61.6(D)
7 Weight (g) 5300
8 Surface treatment Anti-glare, Haze=11%, Hard coating (3H) Note 1
9 Input color signal 8 bit LVDS
10 Display colors 16.7M
11 Color saturation 72% NTSC
12 Backlight 4U CCFL
13 RoHS & Halogen free RoHS & Halogen free compliance
Note 1: Glare Option available
4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 5/23
B. Electrical specifications
1. Pin assignment
5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 6/23
2. LVDS INTERFACE
6
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 7/23
3. Absolute maximum ratings
7
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 8/23
4. Electrical characteristics
a. TFT LCD MODULE
8
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 9/23
9
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 10/23
10
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 11/23
b. Display color vs. input data signals
The brightness of each primary color (red, green and blue) is based on the 8-bit gray scale data input
for the color; the higher the binary input, the brighter the color. The table below provides a reference for
color versus data input.
Input color data
Color Red Green Blue
MSB LSB MSB LSB MSB LSB
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(255) 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(255) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Basic Blue(255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
colors Cyan 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Red(000) dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(001) 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(002) 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red : : : : : : : : : : : : : : : : : : : : : : : : :
Red(253) 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(254) 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(255) bright 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(000)dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
Green(002) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
Green : : : : : : : : : : : : : : : : : : : : : : : : :
Green(253) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0
Green(254) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
Green(255)bright 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Blue(000) dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Blue(001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Blue(002) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0
Blue : : : : : : : : : : : : : : : : : : : : : : : : :
Blue(253) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1
Blue(254) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0
Blue(255) bright 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
11
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 12/23
c. Input signal timing
Support Input Timing Table
12
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 13/23
13
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 14/23
d. Display Position
D(1, 1) D(2, 1) ...... D(683, 1) ...... D(1365, 1) D(1366, 1)
D(1, 2) D(2, 2) ...... D(683, 2) ...... D(1365, 2) D(1366, 2)
.
. .
. .
. .
.
. ...... . ...... . .
D(1, 384) D(2, 384) ...... D(683, 384) ...... D(1365, 384) D(1366, 384)
.
. .
. .
. .
.
. ...... . ...... . .
D(1, 767) D(2, 767) ...... D(683, 767) ...... D(1365, 767) D(1366, 767)
D(1, 768) D(2, 768) ...... D(683, 768) ...... D(1365, 768) D(1366, 768)
14
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 15/23
e. Backlight driving conditions
Electrical specification
Note 3: (1) Uniformity and flicker does not guarantee when the dimming control under 20%.
(2) 10% dimming function is okay, no shutdown occur.
15
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 0
PAGE 16/23
C. Optical specifications
Specification
Item Symbol Condition Unit Remark
Min. Typ. Max.
G to G Response time T =0 - 8.5 - ms Note 2
Contrast ratio CR =0 2300 3000 - Note 1,3
Viewing angle
Top CR 10 75 88 -
Bottom CR 10 75 88 -
deg. Note 1,3,5
Left CR 10 70 88 -
Right CR 10 70 88 -
Brightness (Center) YL 300 350 - nits Note 1,4
Wx 0.280
Color chromaticity(CIE)
Wy 0.290
Rx 0.643
Ry 0.331
-0.03 +0.03 Note 1
Gx =0 0.276
Gy 0.597
Bx 0.144
By 0.069
White uniformity (9) W
0.75 0.80 - Note 1,6
Cross talk Ct - - 2% Note 7
Note : 1 Ambient temperature = 25◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
