                                                            Filters and Frequency Tables



18.0         Filters and Frequency Tables
     18.1 Standard       The standard filter provided for the FDS-360 is of the Linkwitz-Riley response
                         based on two second order Butterworth circuits in series. The response is a
              Filters    24dB/OCT slope with a 'corner' frequency where the output of the filter if 6dB
                         down from its pass band level. The use of these filter realisations has been
                         well documented and provides the best possible phase and amplitude response
                         for driving large speaker systems.
                         Table 17.1 lists the component values for various frequencies and should be
                         used in conjunction with the drawing for the FDS-360F frequency card (See
                         Figure 18.3). Blank cards, or ready made cards can be provided by any BSS
                         dealer.
                         All resistors should be
