Image preview - the first page of the document



>> Download Crest-XR20suplement mix documenatation <<

Text preview - extract from the document

                                    Crest Audio XR-20 mono input module user options 12-18-01




                                                                                                                                       Aux Pre Signal Mod
        Direct out mod
                                                                                        Easy to read instructions located
                                                                                        right on the board here....




Cut and remove 0 ohm jumpers R159 and R106 on the mono input main PCB. Add solder blobs to SB4 and SB5 to join the 2
solder pad halves. Now your direct out for this channel is Post-EQ and Pre-fader. If you require a easy pre fader/pre EQ dir
out it is possible to utilize the insert send and modify your 1/4" connector for this accordingly so as not to interrupt signal flow
to the rest of the module (IE: short tip/ring together).
XR-20/24 block diagram          XR-20 / XR-24 owner's manual




                         JIMI




p. 4
