Image preview - the first page of the document



>> Download MOC3043 documenatation <<

Text preview - extract from the document

                                                                                                                                      MOC3031M, MOC3032M, MOC3033M, MOC3041M, MOC3042M, MOC3043M 6-Pin DIP Zero-Cross Optoisolators Triac Driver Output (250/400 Volt Peak)
                                                                                                                 June 2005




   MOC3031M, MOC3032M, MOC3033M, MOC3041M,
   MOC3042M, MOC3043M
   6-Pin DIP Zero-Cross Optoisolators Triac Driver Output
   (250/400 Volt Peak)
   Features                                                 Description
      Simplifies logic control of 115 VAC power             The MOC303XM and MOC304XM devices consist of a AlGaAs
      Zero voltage crossing                                 infrared emitting diode optically coupled to a monolithic silicon
                                                            detector performing the function of a zero voltage crossing bilat-
      dv/dt of 2000 V/
