Image preview - the first page of the document



>> Download E250Pservicemanual documenatation <<

Text preview - extract from the document

    Northridge E250P/230
Service Manual




                         Amplifier
         Power (RMS):             250 Watts
           Driver:           300mm (12") PolyPlas
           Inputs:      Line Level (switchable to LFE)
                            and Speaker Level with
                              5-way binding posts
           Outputs:        Speaker Level, High-Pass
                              5-way binding posts
                         Low-Pass
          Frequency:        Continuously variable
                             from 50Hz
