Image preview - the first page of the document



>> Download Internal Modification documenatation <<

Text preview - extract from the document

 MONO P.C.B. (2channels shown)
                                              Internal Modifications
                                      3
                                              The console is designed to satisfy almost all
                                              applications. The internal modifications are offered to
                                              provide alternative routings for very special
                                              applications. All modifications can be carried out from
                                              the bottom side of the P.C.B..
                                   4          Warning: The modifications involve cutting of traces
                                              and resoldering of specially designed pads and should
                                              only carried out by competent electronic technician.
                                              MIDAS accepts no responsibility for any damages or
                                              injuries. In case of damages by modifications, MIDAS
                                              may declare warranty privileges void.

                                              To open the unit, the following steps are necessary:

                                              1. Remove all cords including the mains cord.
                                              2. Remove the sidewings and the armrest.
                                              3. Remove the screws that attach the top panel.
                                              4. Open the top panel carefully. Now you have acces
                                  5           to the bottom side of the P.C.B..

                                              Mon and aux sends post-eq :
                                  1
                                              1. Cut here.
                                              2. Solder here.

                                  2

                                  6           Fx sends pre-eq:
STEREO P.C.B. (2channels shown)

                                          1   3. Cut here.
        1                                     4. Solder here.

        2
                                              Direct outs pre-fader:
                                          2
                                              5. Cut here.
                                              6. Solder here.
                                                                                       CUT

                                          4



                                                                                       SOLDER

                                          3
