Image preview - the first page of the document
>> Download 0183_line_boost_w_T1310 documenatation <<
Text preview - extract from the document
Neve BA-183AM card as used for line booster single-ended output pins E and H are
not used
24vdc B+ pins M and J are
M*
M shown twice but
T1310
only exist as single
1Hy choke edge card fingers
B
Output
F
note that with loads below
2K ohms cap C7 may need
L D to be increased in value to
Input maintain low frequency
response
note that amplifier should be
biased with whatever load it will
K be driving connected.
Gain set C
bias point for lowest distortion
at operating level is not going to
be exactly the same as the bias
point for maximum level
J J* before clip
Ovdc B-
pay attention to current while
A biaising - do not exceed 100mA
GAIN: this amplifier has an inherent gain of 11dB to pin F. The gain can be increased by taking pin K to ground (pin J)
through an R and a C = the C assures gain is only increased for audio (not dc) and the R sets the AC gain
R=1K2 and C=100uF will increase gain to 16dB
R=110 and C=220uF will increase gain to 31dB
note that at higher gains distortion will increase somewhat
