Image preview - the first page of the document
Shure-M62 preamp


>> Download Shure-M62 preamp documenatation <<

Text preview - extract from the document
                   222 HARTREY AVE   l   EVANSTON, ILL. (60204) U.S.A.                          MODEL M62
                                                                            DATA SHEET   AUDIO LEVEL CONTROLLER
                    AREA CODE 312/328-9000   l   CABLE SHUREMICRO
                                                                                            CIRCUIT DIAGRAM           I




                SHURE
    ITEM                        DESCRIPTION
               PART NO.
    Q1, Q2,
    Q3, Q4      86A327          TRANSISTOR
      Q5       86A325           TRANSISTOR

      Q6       86A329         FET TRANSISTOR
      D1        86A405       GERMANIUM DIODE
  D2, D3, D4    86A403         SILICON DIODE
     T1, T2     51A38          TRANSFORMER

 NOTES:
 1. ALL CAPACITORS IN MFD UNLESS SHOWN
    OTHERWISE AND WORKING VOLTAGES OVER
    100 UNLESS SHOWN.
 2. ALL RESISTORS 10% TOLERANCE.
 3. THE SELECTED RESISTOR IS CHOSEN TO
    ADJUST POINT WHERE REGULATING ACTION
    STARTS TO CORRESPOND TO DISTANCE
    SELECTOR SWITCH SETTINGS.



                                                                         MODEL M62
                                                           AUDIO LEVEL CONTROLLER




AL331 (4-68) 27A514
Copyright 1968, Shure Brothers, Inc.                                                              Printed In U.S.A.
