Image preview - the first page of the document

>> Download soundcraft_spirit_e-series_e6_e8_e12_es_technical_data documenatation <<

Text preview - extract from the document

TECHNICAL DATA
INTRODUCTION

E6, E8, E12
6/8/12 mono inputs with 3-band EQ
(swept mid)

2 stereo inputs with 2-band EQ

Rugged chassis design, with rack-mount
capability

2 auxiliary sends, switchable pre or post-
fade

Peak LED on all input channels

Global +48V phantom power

100mm faders throughout

ES
4 mono inputs with 3-band EQ (swept
mid)

10 stereo inputs with 3-band EQ (2 with
RIAA Turntable Equalisation)

Rugged chassis design, with rack-mount
capability

2 auxiliary sends, switchable pre or post-
fade

Peak LED on all input channels

Global +48V phantom power

100mm faders throughout

Issue 1 09/02
ZL0600 (std) 1
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA
TYPICAL EQ CURVES

Issue 1 09/02
2 ZL0600 (std)
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA
MODULES
Mono Input Stereo Input Stereo Input Master Section
Channel Channel Channels (ES)
(E6/8/12) (There are 3 variants)

Note: the Aux
outputs are re-
positioned
slightly on the
ES master
section

Issue 1 09/02
ZL0600 (std) 3
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA
E6/8/12 BLOCK DIAGRAM

Issue 1 09/02
4 ZL0600 (std)
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA
ES BLOCK DIAGRAM

Issue 1 09/02
ZL0600 (std) 5
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA
DIMENSIONS

An E8 Rack Extender (Part #
P-S20001D-01) may be
used to mount the E8 in a
19 rack

An E6 Rack Extender (Part #
P-S20000D-01) may be
used to mount the E6 in a
19 rack

Issue 1 09/02
6 ZL0600 (std)
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA
Architects and Engineers Specifications
Soundcraft Spirit E Series Mixing Console October 2002
The audio mixing console shall be a self-contained unit, complete with input, output and master sections and an integral switched mode power supply
capable of operating under various AC voltage inputs from 90VAC to 240V AC. The audio mixing console shall have 12 (8, 6) mono input channels, two
stereo input channels and a stereo mix master output. It shall be possible to have the audio mixer mounted on a desktop or rack-mounted through optional
rack mounting ears, and shall be of a rugged steel panelled construction. All jack sockets shall be of a metal construction.

The mono input channel shall have the following features: an electronically balanced wide range mic and line input on XLR and 1/4 jack connectors with
continuously variable sensitivity between 60dBu and -5dBu, globally switched 48V phantom power, a 3-band equaliser with shelving HF and LF controls at
12kHz and 60Hz with 15dB of cut or boost, and an MF control continuously variable from 140Hz to 3kHz with a Q of 0.77 and cut or boost of 15dB. Two
auxiliary sends shall be provided, with individual level controls. Each Aux shall be individually globally switchable to be pre-fade or post-fade sends. Routing
to the mix output shall be in stereo via a Pan control with 4.5dB centre-drop, along with Mute and SOLO (PFL) functions. A Peak LED shall warn of signals
within 6dB of clipping. There shall be a pre-EQ insert point on a 1/4 TRS jack, and a 100mm fader shall control the overall channel signal level.

The stereo input channel shall have the following features: Line input connectors on electronically balanced 1/4 jack connectors with input gain continuously
variable from 0 to +22dB. There shall be a two-band equaliser with HF and LF shelving controls at 12kHz and 60Hz with cut or boost of 15dB. Two auxiliary
sends shall be provided, both with individual level controls and feeding a mono sum of the stereo channel to the Aux busses. Each Aux shall be individually
globally switchable to be pre-fade or post-fade sends. Routing to the mix output shall be in stereo via a Balance control, along with Mute and SOLO (PFL)
functions. A Peak LED shall warn of signals within 6dB of clipping, and a 100mm fader shall control the overall channel signal level.

The Master section shall contain the following facilities: a stereo playback input and record output, a stereo mix output, monitor outputs, output metering, a
1/4 headphone output mounted on the console front panel, 2 Aux master outputs, and a global 48V phantom power switch with LED. The Playback inputs
shall be routed to the Mix outputs via a gain control when a PLAYBACK TO MIX button is pressed, and to the monitor outputs when a MONITOR PLAYBACK is
pressed. Ten-segment LED bargraph meters shall be used to display L-R output levels, which shall be replaced by an active SOLO signal. The main stereo mix
output shall be controlled by 100mm faders and fed to electronically balanced XLR connectors. There shall be Mix Inserts on 1/4 jack connectors.

The two Auxiliary Master outputs shall be fed to electronically balanced 1/4 jack connectors. The output level of the 1/4 jack headphone and monitor feeds
shall be variable and may be replaced automatically by any SOLO signal.

The specifications and dimensions of the console shall be as published in the Spirit E Series brochure. The audio mixing console shall be the Soundcraft
Spirit E Series E12 (E6, E8)

Soundcraft Spirit E Series ES Mixing Console October 2002
The audio mixing console shall be a self-contained unit, complete with input, output and master sections and an integral switched mode power supply
capable of operating under various AC voltage inputs from 90VAC to 240V AC. The audio mixing console shall have 10 stereo input channels, four mono input
channels and a stereo mix master output, and be capable of routing 26 input signals to mix. It shall be possible to have the audio mixer mounted on a
desktop or rack-mounted through optional rack mounting ears, and shall be of a rugged steel panelled construction. All jack sockets shall be of a metal
construction.

The stereo input channel shall have the following minimum features: Line input connectors on electronically balanced 1/4 jack connectors with input gain
continuously variable from 0 to +22dB. There shall be a three-band equaliser with HF, MF and LF shelving controls at 12kHz, 600Hz and 60Hz with cut or
boost of 15dB. Two auxiliary sends shall be provided, both with individual level controls and feeding a mono sum of the stereo channel to the Aux busses.
Each Aux shall be individually globally switchable to be pre-fade or post-fade sends. Routing to the mix output shall be in stereo via a Balance control, along
with Mute and SOLO (PFL) functions. A Peak LED shall warn of signals within 6dB of clipping, and a 100mm fader shall control the overall channel signal
level.

At least two of the stereo input channels shall be capable of accepting signals from a record turntable and applying RIAA equalisation and pre-amplification
to that signal. These signals shall be connected via RCA/phono sockets. A signal inserted on the 1/4 jack connectors will override the RCA/phono input.

At least four of the remaining stereo inputs shall feature both RCA/phono and 1/4 jack sockets for line input connections, and be able to switch the selected
incoming signal to be mono. A signal inserted on the 1/4 jack connectors will override the RCA/phono input.

The specifications and dimensions of the console shall be as published in the Spirit E Series brochure. The audio mixing console shall be the Soundcraft
Spirit E Series ES.
Issue 1 09/02
ZL0600 (std) 7
ZL0601 (US)
Copyright Soundcraft E. & O.E.
TECHNICAL DATA

TYPICAL SPECIFICATIONS
Noise (22Hz-22kHz measurement bandwidth)
Mic EIN @ max gain, 150 W source impedance ............................................................................................................ -128dBu
Mix @max, faders down ................................................................................................................................................ <-85dBu
Crosstalk (typ. @ 1kHz)
Channel mute ................................................................................................................................................................. >96dB
Fader cut-off (rel +10 mark) ........................................................................................................................................... >96dB
Aux send pot offness ...................................................................................................................................................... >86dB
Frequency response
Mic/Line input to any output ................................................................................................................ +/- 0.5dB 20Hz 20kHz
THD+Noise
Mic gain 30dB, -30dBu input
Mix out, fader max @ 1kHz ......................................................................................................................................... <0.007 %
Input & output Impedances
Mic input ......................................................................................................................................................................... 2.4kW
Line input ......................................................................................................................................................................... 11kW
Stereo input .................................................................................................................................................................... 100kW
Outputs ............................................................................................................................................................................. 75W
Input & output levels
Mic input max level ....................................................................................................................................................... +17dBu
Line input max level ...................................................................................................................................................... +30dBu
Stereo input max level .................................................................................................................................................. +30dBu
Mix output max level ..................................................................................................................................................... +20dBu
Headphones (@ 200W) ................................................................................................................................................. 300mW
EQ
EQ Bands (Mono input) +/- 15dB
Lo ...................................................................................................................................................................................... 80Hz
Mid (swept) .......................................................................................................................................................... 140Hz 3kHz
Hi .................................................................................................................................................................................... 12kHz
Q .......................................................................................................................................................................................... 1.5
EQ Bands (stereo input) +/- 15dB
Lo ..................................................................................................................................................................................... 80Hz
Mid (ES only) .................................................................................................................................................................. 600Hz
Hi .................................................................................................................................................................................... 12kHz

WEIGHT
E6 .............................................................................................................................................................. 5.75 kg (12.68 lbs)
E8 .............................................................................................................................................................. 6.75 kg (14.88 lbs)
E12/ES ...................................................................................................................................................... 7.75 kg (17.09 lbs)
AVERAGE POWER CONSUMPTION (QUIESCENT)
E6 ............................................................................................................................................................................... 13 Watts
E8 ............................................................................................................................................................................ 14.5 Watts
E12 ............................................................................................................................................................................. 17 Watts
ES ................................................................................................................................................................................... 15.5W
MIN / MAX OPERATING TEMPERATURE (E SERIES FAMILY)
Centigrade / Farenheit ................................................................................................................... 0
