Image preview - the first page of the document



>> Download pe15man parametric eq documenatation <<

Text preview - extract from the document

                        OPERATORS MANUAL                                                                           PE 15
                                                                                   PARAMETRIC EQUALIZER




  QUICK START
      If all else fails, read the manual. Yeah, yeah. But nothing is going to fail and you, being one smart cookie, don't need
  to read the stupid manual. But you should read this section just to cover your affairs. So, quickly, here goes.
      The PE 15 has few hidden gotchas. One of these may be the shelving feature of Bands 1 and 5. Remember that
  pulling on the bandwidth (BW) knob causes it to come forward with a positive click, indicating the Shelf Mode is active.
  Use Shelving Bands 1 and 5 like Bass and Treble tone controls, where you want control over the whole top or bottom
  ends of the spectrum.
      Hook-up is simple. The PE 15 accepts all combinations of balanced or unbalanced, XLR,
