Image preview - the first page of the document
>> Download 4101RH-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. 4101RH
New Tool
Description 125 mm(5") Cutter
CONCEPTION AND MAIN APPLICATIONS
(6-1/8")
158mm
Model 4101RH is sister version of the existing Model 4101R.
Model 4101RH complies with CE- regulation.
Its brief benefits are;
* More endulable and longer life motor
22 (8-3
3m /4
* Equiped with earth leakage breaker
m ")
on power supply cord
(9-1/4")
236mm
Specifications
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
230 4 50/60 860 580 1200
No Load Speed 12000rpm
Dimension of Outer dis. 110mm(4-3/8")~125mm(5")
Digmond wheel Arbor dis. 20mm(3/4)
Insulation class Single
Net weight 2.9kg(6.4lbs)
Power supply cord 3.0m(9.8ft)
Max.cutting capacity
Bevel angle Dianmond wheel:110mm(4-3/8") Dianmond wheel:125mm(5")
