Image preview - the first page of the document



>> Download 4320-TE documenatation <<

Text preview - extract from the document

T       ECHNICAL INFORMATION
        Models No.             4320
                                                                                                             New Tool


        Description            MAKITA Jig Saw

CONCEPTION AND MAIN APPLICATIONS




                                                                                  179mm
   Based on the existing model #4301SV, the jigsaw having
   the same capacity and function is compacted for size less
   weight and less cost.                                                  68mm




  Specifications                                                                                174mm


        Voltage(V)      Current(A)      Frequency(Hz)          Consumed        Rated            Max.
                                                               power(W)      output(W)        output(W)
           100              3.3              50-60                310           160              250
           115              2.9              50-60                310           160              250
           200              1.7              50-60                310           160              250
           220              1.5              50-60                310           160              250
           230              1.4              50-60                310           160              250
           240              1.4              50-60                310           160              250

    No load speed (stroke/min.)                0-3200
                     Wood(mm)                  50
    Capacity
                     Soft steel plate(mm)      6
    Bevel cutting                              0-45 in left/right
    Net Weight(kg)                             1.3
    Cord length(m)                             2

  Standard equipment
   1.    Circular guide
   2.    Guide rule
   3.    Hex. wrench 3
   4.    Jigsaw blade No.1, No.2, No.3(each 2 pieces)
   5.    Rule holder
   6.    Hex. shank Hd. screw M5X10

   *The 5.and 6.are used for mounting the guide.


  Optional accessories
   Jigsaw blade No.1, No.2, No.3, No.4, No.5, No.6, No.7, No.8, No.9, No.10, No.16, No.17, No.41, No.42


  Features and benefits
   1.The powerful air force generated through the motor turning discharges the cutting chips, thereby cutting portion
     can be easily checked.
   2.The small and light weighing unit can be easily handled.(Overall length : 4320=>174 mm, 4301SV=>190 mm,
     Weight : 4320=>1.3 kg, 4301SV=>1.5 kg)
   3.The non-step variable speed enables the mark-off-line in the beginning of cutting to be adjusted easily.
   4.You can get the desired speed through adjusting the speed change screw.
   5.The transparent protector is mounted for protecting your hands from the saw cutter.
   6.The both MAKITA type and the universal type jigsaw blades can be mounted.

 The standard equipment for the tools shown may differ from country to country.
