Image preview - the first page of the document
>> Download 43893-ww-1 documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION 43893
Subject Change on crank housing
For Models HM1500 and HM1500B (Demolition Hammer)
Description A grease hole will be made in the crank housing as shown below.
Current New
Crank housing
Crank housing
Grease hole
Motor housing
packing
Motor housing
cover
Screw M5x12
Interchangeability(I/C)
Item No. Current part Q'ty New part Q'ty I/C Note
Crank housing Crank housing For all countries and
089 1 1 No
316269-9 159601-2 areas except U.S.A.
Crank housing
089 1 1 No
316269-9 159602-0
099 1
341397-1
100 1
442009-0
101 4
911211-1
Note
The current type part (crank housing) and the new type parts (crank housing, motor housing packing, motor housing cover and
screw M5x12) are interchageable as a set.
Enforcement schedule
HM1500 : From serial No. 4830E
HM1500B : From serial No. 1001E
