Image preview - the first page of the document
>> Download 440-TE-AT documenatation <<Text preview - extract from the document PARTI DI RICAMBIO
Modello M440 230V~ Cod. 99611B8B
Modello M440 230V~
6
21
1 8 Pos. Descrizione Codice Prezzo
(Cad)
0
2
200 x
ma
W
41
7
3
9 4 23 22
25
11
10
28
5
26 29
27
12
13 14
42
30
16
35
40 31
32
33
38
15
19 34
36
24
37
18
17
39
20
Modello M440 230V~
Pos. Descrizione Codice Prezzo
(Cad)
01 Impugnatura .................................................................. 50310B8B ................
02 Calotta ........................................................................... 50305B8B ................
03 Forcella fermacavo ........................................................ 50335BEN ................
04 Coprimotore .................................................................. 50181B0A ................
05 Silenziatore lungo alla calotta ........................................ 83022B8X ................
06 Cornice + coperchio ...................................................... 80202B8N ................
07 Presa Schuko ................................................................ 80200B8N ................
08 Ghiera per presa ........................................................... 50315BDV ................
09 Morsetto tripolare .......................................................... 80029B0I ................
10 Cavo di alimentazione ................................................... 80017B0N ................
11 Filtro alla griglia ............................................................. 83021B8X ................
12 Guarnizione tonda ......................................................... 70016B8N ................
13 Diaframma ..................................................................... 50104B8V ................
14 Guarnizione tenuta diaframma ...................................... 70057B0N ................
15 Guarnizione inferiore tenuta motore .............................. 70032B0N ................
16 Supporto motore ........................................................... 50179B8B ................
17 Adesivo contenitore ....................................................... 85637B8V ................
18 Cerniera completa ......................................................... 01015B0A ................
19 Contenitore .................................................................... 60027BJA ................
20 Ruota pivottante ............................................................ 30086B0X ................
21 Interruttore bipolare nero con led rosso ........................ 80041BDN ................
22 Interruttore unipolare ..................................................... 80042BDN ................
23 Piastra di chiusura ......................................................... 50300BDV ................
24 Serie cavetti ................................................................... 80101B8V ................
25 Guidacavo ..................................................................... 50338BEN ................
26 Griglia uscita aria .......................................................... 50170B8A ................
27 Silenziatore corto alla calotta ........................................ 83023B8X ................
28 Fermacavo ..................................................................... 50333BEN ................
29 Scheda elettronica integrata .......................................... 80209BDX ................
30 Ammortizzatore superiore motore ................................. 70060B8N ................
31 Motore ED98/1000W/BS/240V~ ................................... 20052B0X ................
32 Anello silenziatore ......................................................... 83020B8X ................
33 Griglia di protezione ...................................................... 50183B0V ................
34 Galleggiante .................................................................. 50077B0V ................
35 Tubetto PVC nero mm. 110 -
