Image preview - the first page of the document
>> Download 446L-TE-AT documenatation <<
Text preview - extract from the document
Modell 446L
Staubsauger Staubklasse 'L'
Pos. *PG Bestell-Nr. Bezeichnung
001 37 W302001397 HAUBE MIT DAEMMUNG
002 21 W302000471 HANDGRIFF
003 11 W909100084 SCHRAUBE M6x140
004 12 W302001372 ABREINIGUNGSKNOPF
005 60 W302000628 ELEKTRONIK
006 61 W302001329 SCHALTKASTEN
007 3 W18274 SENKSCHRAUBE M4x12
008 32 W302000151 STECKDOSE
009 3 W11256 SCHRAUBE EJOT PT 3,5x18
010 12 W909100222 DREHKNOPF
011 8 W9868 O-RING 10
012 40 W302000559 ANSCHLUSSLEITUNG 3x1,5 8,2m
013 18 W302001325 HINWEISSCHILD PUSH AND CLEAN
014 18 W302000230 HINWEISSCHILD WARNUNG L
015 27 W302000231 HINWEISSCHILD SPRACHENSATZ L
016 39 W302000346 TRAEGERPLATTE
017 20 W302000459 BEHAELTERDICHTUNG
018 18 W302000460 FILTERDICHTUNG
019 75 W49594 MOTOR 230/1200W
020 37 W49625 KOHLEBUERSTEN "C"
021 40 W42538 MOTORLAGERRING-SET "C"
022 28 W302000350 MOTORSITZ
023 14 W302000600 DIFFUSOR
024 3 W11253 SCHRAUBE EJOT PT 5x20
025 3 W11256 SCHRAUBE EJOT PT 3,5x18
026 24 W47036 MANSCHETTE CR 55
027 19 W302000348 LUFTFUEHRUNG
028 41 W302001315 FILTERELEMENT
029 22 W302000472 FILTERSTUETZKORB
030 21 W302000341 ABWEISER
031 7 W11565 SCHRAUBE PT 5x18
032 22 W61174 KONTAKTFEDER
033 5 W909100083 DREHFEDER
034 13 W302000344 ABREINIGUNGSKLAPPE
035 52 W302001308 SAUGERBEHAELTER
036 15 W302000349 VERSCHLUSSKLAMMER
037 23 W46298 DOPPELROLLE
038 20 W302000464 ACHSE
039 2 W909100085 SCHRAUBE
040 14 W302000465 RAD
041 9 W47302 KLEMMRING
042 11 W25710 RADKAPPE
043 Z W302000565 FILTERSACK (5 STK.)
044 Z W302001310 SICHERHEITSFOLIENSACK (5 STK.)
045 Z W15325 SAUGSCHLAUCH 27mm ANTISTATISCH
046 13 W302000343 STANGE
