Image preview - the first page of the document
45131-ww-1


>> Download 45131-ww-1 documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION                                                                                45131

            Subject               Change on switch

            For Models            M910, M954, M955, 900, 910 and 9514BH (Disc Grinder)

            Note                  This information does not apply to Models 900 and 9514BH for Canada.

            Description           The switch will be changed as follows.

                                                 Current                                           New
         Type                                      ML6A-2                                      SLE6A



        Circuit
                                       1                          2                      1               P



       Dust-proof                                     No                                         Yes



Note
Its configuration and wiring method will remain unchanged.


Interchangeability(I/C)

 Item No.       Current part           Q'ty     I/C      New part                   Q'ty         Note
   24       Switch                         1    <=     Switch                        1
            651505-9                                   651514-8

Note
<= mark indicates that the new type part can be substituted for the current type part.


Implementation
 900 : From serial No. 64542E
 910 : From serial No. 82743E
 9514BH: From serial No. 29441E
 M910, M954 and M955: Discontinued
