Image preview - the first page of the document
>> Download 46229-ww-1 documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION 46229
Subject Change on blade clamp, slider, etc.
For Models JR3000 and JR3000V (Recipro Saw)
Description The blade clamp, slider, etc. will be changed as follows.
Current New
Blade clamp Bolt M5x13
Blade clamp Spring pin 2.5-9 Slider
Slider
Pin 3
Interchangeability(I/C)
Item No. Current part Q'ty I/C New part Q'ty I/C Note
Slider Slider
8 1 1 No
163340-8 163357-1
Blade clamp Blade clamp
25 1 1 No
322502-9 313067-2
Spring pin 2.5-9 Interchangeable as a set
64 1
258018-7
Pin 3
67 1
256701-0
Bolt M5x13
69 1
265986-7
Implementation
JR3000 : From serial No. 259312E
JR3000V: From serial No. 1549570E
