Image preview - the first page of the document



>> Download 46462-ww-1 documenatation <<

Text preview - extract from the document

T       ECHNICAL INFORMATION                                                                                        46462

             Subject             Change on gear housing and discontinuance of tool rest

             For Models         9005B, 9006B, 9005BS (Disc Grinder) and PC1100 (Concrete Planer)


            Description         1. The tool rest will be moulded onto the gear housing.

                           Current                                                               New

               Tool rest          Gear housing                                                   Gear housing




2. The screws which secure the bearing box to the gear housing will be changed as follows.

     For Models                               Current                                           New
9005B, 9006B, and 9005BS      Pan head screw M4x14                            Tapping screw CT4x16
PC1000                        Pan head screw M4x22                            Tapping screw CT4x25



Interchangeability(I/C)

 Item No.      Current part               Q'ty I/C     New part                           Q'ty
    3       Gear housing                    1       Gear housing                           1
                                                 No
            156735-2                                159710-7                                           Interchangeable as a set
             Tool rest
    2                                       1
             341680-6
   31       Pan head screw M4x14            4    Yes Tapping screw CT4x16                    4   For 9005B, 9006B and 9005BS
            911121-2                                 266034-5
            Pan head screw M4x22                     Tapping screw CT4x25                         For PC1100
   29                                       4    Yes                                         4
            911141-6                                 266040-0

Note
1. The new type gear housing for replacement has tapped holes in it. So either pan head screw or tapping screw can be used
   to secure the bearing box to the gear housing.
2. The tool rest (Pt. No. 341680-6) has been employed in Models 9005B, 9006B and 9005BS but has not not been employed
   in Model PC1100.

Implementation
 9005B :    From serial No. 921950E
 9005BS:    From serial No. 2101E
 9006B :    From serial No. 65555E
 PC1100:    From serial No. 22566E
