Image preview - the first page of the document
46718-ww-1


>> Download 46718-ww-1 documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION                                                                                          46718

            Subject                Change on tool holder, impact bolt, etc.

            For Models             HM1500 (Demolition Hammer)

            Description
1. The impact bolt will be changed from 69mm (2-23/32") to 74mm (2-29/32")
   in length.

                                                                                           69mm (2-23/32") => 74mm (2-29/32")




2. The hole in the tool holder will be changed from 42mm (1-21/32") to 47mm (1-27/32") in depth.
3. The tool holder will be hardened.
4. The flange of the tool holder will be changed from 7mm (9/32") to 13mm (1/2") in thickness.
5. The ring 12 will be discontinued.




                                                                                 Tool holder




           42mm (1-21/32") => 47mm(1-27/32")




                     7mm (9/32") => 13mm (1/2")
                                                                              Ring 12




Interchangeability(I/C)

Item No.            Current part                Q'ty          New part                         Q'ty I/C           Note
              Impact bolt                              Impact bolt
  10                                              1                                             1   No
              322384-9                                 322693-6
              Tool holder                              Tool holder                                           Interchangeable
   7                                              1                                             1   No            as a set
              322514-2                                 322692-8
              Ring 12
  102                                             4
              257182-1


Implementation
From serial No. 8682E
