Image preview - the first page of the document
>> Download 49865-WW-1 documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION 49865
Subject Changes on Fan110, Fan Housing Complete and Fan Cover
For Models 4014N and 4014NV(Blowers)
Description As described and illustrated below;
1.Fan 110
(1) The vent holes in the fan 110 have been changed in shape as illustrated below.
(2) Ribs have been added for reinforcement.
Current New
Vent hole Rib
Vent hole
Note
As a temporary step, the fan 110 illustrated on the right has Vent hole
been used from May to Oct., 1995.
Fully changed (new type) fan 110 has been used from Nov.,
1995.
2.Fan housing complete and fan cover
Current New
R7mm R14mm
(9/32") (9/16")
R12mm R22mm
(15/32") (7/8")
Interchangeability(I/C)
Item No. Current part Q'ty I/C New part Q'ty Note
Fan 110 Fan 110
1 No 1
241807-7 241888-1
Fan housing complete Fan housing complete
1 No 1 Interchangeable as a set
157464-0 159855-1
Fan cover Fan cover
1 No 1
410482-2 415921-7
Implementation
1.Fan 110
4014N : From serial No.199350E
4014NV : From serial No.36683E
2.Fan housing
4014N : From serial No.204362E
4014NV : From serial No.38812E
Correction
This is a revised version of TEC-111/95.
(1) The material of fan 110 ;
TEC-111/95 : Changed from polycarbonate to polyamide.
TEC-111/95(R) : Remains unchanged.
(2) Full change of fan 110 ;
TEC-111/95 : From Sept.,1995
TEC-111/95(R) : From Nov.,1995
